Jeep Wrangler
i407-WRA-JL
7" Restyle In-Dash System
Installation Manual
˜ Model: Wrangler JL 2018-Up
˜ Model: Gladiator JT 2020-Up
* The specified vehicles have been tested and have met compatibility specs at the time of testing. Compatibility is
not guaranteed if the manufacturer has made production changes to the listed vehicles above.
Introduction
˜ Congratulations on purchasing the i407-WRA-JL. This installation manual is designed to take you through
the step-by-step installation of i407-WRA-JL into a 2018-Up Jeep Wrangler JL or Jeep Gladiator JT 2020-
Up. Please familiarize yourself with the owners manual as this is a challenging installation. If you still have
additional questions please call 1-800-TECH-101.
Note
˜ Design and specifications are subject to change without notice for improvement.
To Ensure Safe Use, Always Follow These Precautions
˜ The installation of this product requires specialized skills and experience. This is an installation that is
challenging and time consuming even for installers with experience. A professional installer would typically
take a minimum of 2-3 hours to complete this installation. We recommend that you have the product installed
by an Alpine authorized dealer.
˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual
so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as
a result of failure to follow the instructions in the manuals.
˜ This manual includes a number of symbols that are intended to help you use the product safely, to prevent
harm to you and others, and to protect against damage to property. These symbols and their meanings are
listed below. Make sure you fully understand these symbols before you begin reading the main text.
Explanations of Injury and Damage That May Result from Incorrect Use
Ignoring the content marked by this indication and using the product incorrectly is
Warning
expected to lead to death or serious injury.
Ignoring the content marked by this indication and using the product incorrectly is only
Caution
expected to lead to injury or property damage.
Model
Jeep
Wrangler JL**
Gladiator JT**
** OEM amplified vehicles require the KCX-F200INT (sold separately)
i407-WRA-JL
20210330v1
Jeep Wrangler
˜ 1/22
Year
2018 - Up
2020 - Up
Advertisement
Table of Contents
Related Manuals for Alpine i407-WRA-JL
Summary of Contents for Alpine i407-WRA-JL
- Page 1 ˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as a result of failure to follow the instructions in the manuals.
- Page 2 The installation and wiring of this product re- wheel, gear shift, or the like; or pose a threat quires specialized skills and experience. Have to passengers. Doing so could lead to an ac- the product installed by an Alpine authorized cident or injury. dealer.
-
Page 3: Tools Required
Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 3/22 Tools Required Wire Strippers 8mm Socket 7mm Socket Wire Cutters Extension Ratchet #2 Phillips Screwdriver Torx T20 Panel Removal Tools Digital Multimeter Cordless Power Drill... -
Page 4: Accessory List
Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 4/22 Accessory List iLX-407 Head Unit Dash Kit Mounting Brackets Maestro Module Camera/Preout Harness Main Harness External Bluetooth Mic FM/AM Antenna Adapter USB, HDMI, Aux Interface Chime Speaker Documents OM QR Card Alpine Installation Registration Card... - Page 5 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 5/22 Accessory List Continued Round Head Screws M5#8 (4pcs) Maestro Flashing Cable USB SiriusXM Radio Antenna Adapter Micro To Full Size (only for vehicles with factory SiriusXM) Mini USB To USB For Center USB Power Adapter...
- Page 6 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 6/22 Factory Unit Disassembly Process As a precautionary measure it’s a good idea to Unsnap the 6 clips and loosen the knee panel under mask out the dashboard and panels to prevent the steering wheel using a panel removal tool.
- Page 7 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 7/22 Factory Unit Disassembly Process (Continued) Use #2 Phillips Screwdriver to extract (4) screws Disconnect the harnesses behind the OEM head from head unit. Disconnect and remove the radio. unit. The disconnected harnesses from the previous Open the glove compartment and remove step.
- Page 8 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 8/22 Factory Unit Disassembly Process (Continued) Remove the A pillar by removing the (2) 8mm Loosen the clips around the top panel visor area. screws and unclipping the panel. The screws can be exposed using a panel removal tool.
-
Page 9: Installation Instructions
Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 9/22 Installation Instructions Mount the microphone next to the rear view mirror Run the Bluetooth microphone cable down the A and run the cable behind the factory panels. Route pillar along the OEM wiring. Route as shown on the as shown on the diagram on page 12. - Page 10 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 10/22 Installation Instructions (Continued) If the vehicle has an OEM amplifier the KCX- Connect the camera interface module to the violet F200INT will need to be purchased separately. or red factory camera plug and put it in right side This has 30”...
- Page 11 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 11/22 Installation Instructions (Continued) Plug in the OEM USB and the USB from the box WARNING: There are 2 factory micro USB plugs to the power adapter. The adaptor needs to be in the dash behind the media center. One is black plugged into the BLACK micro usb.
-
Page 12: Component Locations
Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 12/22 Component Locations IMPORTANT: Follow the recommended component location shown below. Failure to do so, will result in poor GPS performance. Add-on Microphone OEM Camera Module SAT-Radio Tuner (Sold Separately) OBDII Gateway iDatalink Maestro Module... - Page 13 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 13/22 Connecting A SiriusXM Module (Sold Separately) There is no way to integrate the factory SiriusXM tuner. Once the radio is removed, the factory SiriusXM is removed. As the title states, SiriusXM requires a tuner sold separately. This diagram shows how to integrate the antenna connection.
- Page 14 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 14/22 i407-WRA-JL Wiring Diagram Continued To Vehicle Connectors Power Antenna Antenna AMPLIFIED VEHICLES Speaker (Green) (White) 52-pin Connector WARNING! Only 2 connections are necessary for the OEM ampli ed system. Front (White) connects to Front (White) from tuner.
- Page 15 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 15/22 i407-WRA-JL Wiring Diagram Continued Reset Button Black Used Used 10-Pin Chime 18-Pin Optional SiriusXM Tuner (Sold Seperately) iDatalink MAESTRO Module SiriusXM connect Chime Speaker 3-Pin 4-Pin 10-Pin 3-Pin 4-Pin Black Used Blue Used Main Harness...
- Page 16 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 16/22 i407-WRA-JL Wire Descriptions Vehicle Antenna CAN Interface Connector (included) To Interface Box USB extension cable (included) To USB ash drive, iPhone or Android smartphone Microphone (included) VIDEO IN To drive recorder, DVD player, etc.
- Page 17 USB Third party adapters may power source to be installed not work in the vehicle. i407-WRA-JL HDMI Usage With An Android Phone iLX-407 Source Unit VIDEO IN/OUT iLX-407 Source Unit HDMI IN Do not use the head unit’s USB to power HDMI devices.
- Page 18 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 18/22 Wire Harness Pin Outs CAN I/F Radio I/O Radio Main Red 22AWG Blue 22AWG 9 10 Blue 22AWG Red 20AWG 9 10 Black 22AWG Blue/White 22AWG White 22AWG Blue/White 22AWG Orange/White 22AWG Yellow/Blue 22AWG...
- Page 19 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 19/22 Steering Wheel Configuration Off Hook Voice On Hook Volume Up Source Seek Up Volume Down Preset Up Seek Down Button Press Once Press And Hold Seek Up Track + None Seek Down Track -...
- Page 20 ˜ 20/22 Set Up Guide Turn the vehicle’s Ignition switch to ACC. Turn ON the i407-WRA-JL by pressing any key. With the vehicle parked, engage the parking brake, release the parking brake and engage the parking brake again. If a rear camera is present, turn it ON in the settings menu. (HOME/SETTINGS/CAMERA/REAR CAMERA/ CAMERA SELECT/REAR/OK).
-
Page 21: Troubleshooting Guide
HDMI. Do not plug into the USB from the Alpine Didn’t plug USB power into a 2A head unit. A third party USB adapter will source. need to be used that is 2A. - Page 22 Jeep Wrangler i407-WRA-JL 20210330v1 ˜ 22/22 Troubleshooting Guide Continued Only the front speakers are on SXM Tuner has not been activated. Activate SXM Tuner. for SXM Radio. Check the USB connection behind Loose or disconnected USB cable. the headunit. Use the cable supplied with the...
