READ THIS SHEET FIRST
READ THIS SHEET FIRST
Thank you for purchasing the imageCLASS MP730.
To get your machine ready for use, please follow the instructions in this Set-Up Sheet
before referring to any other documentation.
IMPORTANT
NOTE
• For information on the components included with your machine and system requirements,
refer to pp.1-1, 1-2, of the Quick Reference Guide.
• When installing the software in Windows 2000/XP, you must log on as Administrator or
have Administrator privileges.
• If you have previously installed an earlier version of the MultiPASS Suite software (version
4.4 or earlier), you must remove it before installing this version. For details on removing the
software, refer to the documentation of the previous version.

Install the software.

1
Turn on your computer.
2
On your computer, quit any open applications, including virus checkers.
3
Insert the Canon MP730/700 Setup CD-ROM into your
disk drive.
When the [MP Setup] screen on the right is displayed,
perform steps 1 and 2 in order.
CAUTION
• Do not perform step 3 on the last page until you reach
it after performing all the other instructions before it.
If this screen is not displayed, on the Windows desktop, double-click [My Computer]
(Windows XP: Click [Start], then click [My Computer]). Open the CD-ROM icon, then
double-click [setup (setup.exe)].
Set-Up Sheet
Set-Up Sheet
• DO NOT connect the USB cable before installing the software.

Advertisement

Table of Contents
loading

Related Manuals for Canon imageCLASS MP730

Summary of Contents for Canon imageCLASS MP730

  • Page 1: Install The Software

    Set-Up Sheet Set-Up Sheet READ THIS SHEET FIRST READ THIS SHEET FIRST Thank you for purchasing the imageCLASS MP730. To get your machine ready for use, please follow the instructions in this Set-Up Sheet before referring to any other documentation. IMPORTANT NOTE •...
  • Page 2 ● STEP1: Install MP Drivers In the [MP Setup] screen, click [Install MP Drivers]. Follow the on-screen instructions. If you need to restart your computer, the following screen is displayed. [Yes, I want to restart my computer now.] is selected. (Click [Finish] to restart your computer. Do not remove the CD-ROM at this stage.) Click [Finish].

  • Page 3: Assemble The Machine

    Assemble the machine. Attach the multi-purpose tray. Attach the paper output tray until an audible click is heard. Connect the telephone line and any necessary external device. You can connect an external device (telephone or answering machine) if necessary. Connect the telephone line cord to the wall jack.

  • Page 4: Connect The Power Cord

    Connect the power cord. IMPORTANT • Before turning on the power, make sure the document cover A is closed. Plug the power When you connect the cord into a socket. machine, the above messages should appear in the LCD. • If nothing appears in the LCD, press [ON/OFF (1 sec.)] to turn on the machine.

  • Page 5: Install The Printhead

    Install the printhead. Press [Open] q and lift up the scanning unit w. Remove the printhead from its packaging, then remove the orange protective cap A. Raise the lock lever C, then gently slide the printhead into the holder. Lower the lock lever. IMPORTANT •...

  • Page 6: Install The Ink Tanks

    Install the ink tanks. Start with the yellow ink tank. Pull the orange tape in the direction of the arrow and remove the plastic wrapper so you can see the air hole A. Turn the ink tank over so that the protective cap B is facing up. Then hold the ink tank as shown below and remove the protective cap B.

  • Page 7: Align The Printhead

    Align the printhead. NOTE • If you are installing the software, you can also align the printhead from the software. For details, refer to the Software Guide. When the LCD A displays the following, press [OK]. A L I G N P R I N T H E A D P R E S S O K K E Y The machine will print a horizontal pattern, and the LCD will display: C H A N G E H V A L U E...
  • Page 8 To read the manual on the CD-ROM, click [View User’s Manual] on the [MP Setup] screen. CAUTION • For Windows 2000, the machine may not be able to be set as the default printer. If that happens, refer to Setting the default printer in the Software Guide. Congratulations! You have now completed your machine setup.
