Cables To Go ZRC0104C User Manual

Cables to go zrc0104c: user guide.
ZSR0104C Series
Broadband Switch Router User Manual
Page i

   Related Manuals for Cables To Go ZRC0104C

No related manuals

   Summary of Contents for Cables To Go ZRC0104C

  • Page 1

    ZSR0104C Series Broadband Switch Router User Manual Page i...

  • Page 2

    FCC Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 3

    The Specifications of ZSR0104C Series 1 RJ-45 10/100Mbps Ethernet Port 4 RJ-45 10/100Mbps Ethernet Ports Reload Button Reloading Factory Default Settings Client OS Support Win95/98/ME/2000/NT/XP/Mac/ Linux/Unix Configuration User-Friendly Web Configuration Tool Firewall Preventing Hacker’s Scan/Preventing DoS/Service Filter/Stateful Packet Inspection/IP Filter/MAC Filter Network Address Translation DHCP Client Obtaining a Dynamic WAN IP Address from ISP...

  • Page 4: Table Of Contents

    Table of Contents FCC Interference Statement...ii The Specifications of ZSR0104C SERIES... iii Chapter 1 Introduction... 1 1.1 The ZSR0104C SERIES Broadband Switch Router .1 1.2 Physical Features of ZSR0104C SERIES ...1 1.3 Non-Physical Features of ZSR0104C SERIES...1 1.4 Package Checklist...3 1.5 Installation Requirements ...3...

  • Page 5: Table Of Contents

    3.2 Connect Ethernet Hub/Switch to ZSR0104C SERIES 7 3.3 Connect Wireless Access Point to ZSR0104C SERIES 7 3.4 Connect Cable/xDSL Modem to ZSR0104C SERIES7 3.5 Power up ZSR0104C SERIES ...8 Chapter 4 Use Your ZSR0104C SERIES ... 8 4.1 Check the Web Proxy...8 4.2 Wizard Setup...8 A.

  • Page 6: Table Of Contents

    Anti PING and TCP/UDP Echo Attack ...31 Application Filter ...32 URL Filter ...32 6.1 Troubleshooting ...34 Router’s Hardware Failure...35 Failed Connection between ZSR0104C SERIES and Client PC ...35 Failed Connection on ZSR0104C SERIES’s WAN Side ...36 DNS (Domain Name System) Failure ...36 6.2 Forget Password? ...36...

  • Page 7

    Appendix B: Common Port Numbers... 51 Appendix C: Terminology ... 52 Appendix D: Technical Support ... 56 D.1 Hardware Problem ...56 D.2 Software Download...56 D.3 Installation/Application Problem ...56 Page vii...

  • Page 8: Chapter 1 Introduction, The Zsr0104c Series Broadband Switch Router, Physical Features Of Zsr0104c Series

    User’s Manual. 1.1 The ZSR0104C SERIES Broadband Switch Router ZSR0104C SERIES Broadband Switch Router is the ideal router for sharing a single IP address with multiple users, providing firewall security, and accessing WAN with high speed for Home and SOHO (Small Office and Home Office) needs.

  • Page 9

    LAN clients. Therefore the LAN clients “share” the only one WAN IP address, and it is called Broadband Switch. ‧ Firewall ZSR0104C SERIES provides prevents Ping and TCP/UDP Echo Attack, Hacker’s Scan, and Denial of Service (DoS). Also it offers Service Filter and URL Filter (by Keyword). ‧...

  • Page 10: Package Checklist, Installation Requirements, About This User's Manual

    1.4 Package Checklist Please check the package contents of ZSR0104C SERIES to verify that you have received the items below. (Figure 1-1) One ZSR0104C SERIES Broadband Switch Router One Straight-Through Ethernet Cables One AC Power Adapter 7.5V / 0.7 A)

  • Page 11

    concepts of ZSR0104C SERIES. Enjoy your use of ZSR0104C SERIES! Organization of This User’s Manual Chapter 1, Introduction It briefly describes the features of ZSR0104C SERIES. Chapter 2, Get to Know the Hardware It explains the LED and port functions on the front and back panels. Chapter 3, Install Your ZSR0104C SERIES It explains the hardware setup.

  • Page 12: Chapter 2 Get To Know The Hardware, Led Indicators

    Chapter 2 Get to Know The Hardware This Chapter explains ZSR0104C SERIES LED and Port functions. 2.1 LED Indicators ZSR0104CP Front Panel ZSR0104C Front Panel Device Indicators Power: The Power LED illuminates whenever ZSR0104C SERIES is powered on. Status: The Status LED will be continuously on when the power is supplied. It takes around 15 seconds to boot.

  • Page 13: Back Panel, Local Lan Ports, Internet Wan Port, Reset Button

    2.2 Back Panel On the back panel, ZSR0104C SERIES has 4 RJ-45 10/100Mbps Ethernet LAN ports, and 1 RJ-45 10/100Mbps Ethernet WAN port. In addition, it has a Reload button and a Power Connector (7.5V 0.7A). (Figure 2-2) ZSR0104CP Rear Panel ZSR0104C Rear Panel 1.

  • Page 14: Power Connector, Chapter 3 Install Your Zsr0104c Series, Connect Client Pc To Zsr0104c Series

    SERIES power adapter into the power outlet. Step 3. It takes around 15 seconds to reset. The Power LED will turn on Green initially. Wait for it becomes Red then release the Reset button. Step 4. Try to connect http://192.168.1.1/ via your Web browser. Use the user name “admin” and the password “admin ”...

  • Page 15: Power Up Zsr0104c Series, Chapter 4 Use Your Zsr0104c Series, Check The Web Proxy

    The WAN and LAN 100 LED will be continuously on when the transmission mode is 100Mbps. It will be off when the transmission mode is in 10Mbps. Please use the correct AC adapter. It may cause damage to the router if An improper AC adapter was used.

  • Page 16

    Step1. Launch a web browser on your client PC connected to ZSR0104C SERIES. Then point the Web browser to http://192.168.1.1 (http://192.168.1.1 is ZSR0104C SERIES default IP address.) If the router IP address was configured with different IP address, use the configured IP address instead of 192.168.1.1. Please make sure your computer IP address is located in the same subnet of the router IP address.

  • Page 17

    Figure 4 –2 First please choose your local time zone to set time for your NAT. If have daylight saving click the checkbox and input the start date and end date. Then click “Next” button. Page 10...

  • Page 18: A. Cable Modem Connection

    You will see 4 options as followed. If Internet access is through the cable modem, Please click the selection button of the “Cable Modem ”. Then click “Next” button. A. Cable Modem Connection Two option fields might be required to enter by some Internet Service Providers. a.

  • Page 19: B. Fixed-ip Xdsl Connection

    The default WAN Setting of ZSR0104C SERIES is Cable Modem Connection without Host Name and MAC Clone If you don’t know the MAC address of your Network Interface Card, follow the steps to obtain the information. The MAC address information might be helpful when you need to use MAC Clone.

  • Page 20: C. Ppp Over Ethernet (pppoe) Connection

    Fixed - IP is a WAN access type provided by some Internet Service Providers. You need to enter the information of IP address, Subnet Mask, Default Gateway, Primary DNS Server, and Secondary DNS Server. C. PPP over Ethernet (PPPoE) Connection If Internet access is through the PPPoE, please click the selection button of The”...

  • Page 21

    Idle Time field: If the Idle Time was specified with non-zero number, ZSR0104C SERIES router disconnects the PPPoE session after there was no data traffic on WAN interface within the specified “Idle Time” minutes. c. Auto-reconnect field: Once there is any outgoing data traffic, the router automatically re-establishes the PPPoE session.

  • Page 22

    Idle Time field: If the Idle Time was specified with non-zero number, ZSR0104C SERIES router disconnects the PPTP session after there was no data traffic on WAN interface within the specified “Idle Time” minutes. b. Auto-reconnect field: Once there is any outgoing data traffic, the router automatically re-establishes the PPTP session.

  • Page 23: Wan Setup Complete, Chapter 5 Advanced Setup Of Zsr0104c Series, Start From Advanced Setting

    IP address, use the configured address. Make sure the computer IP address locates at the same subnet as router address. Press “Enter” key after typing the router IP address. The status menu appears and shows the current system status and all available settings.

  • Page 24

    Click the “Advanced Setup “ (see Figure 4 – 2) and will be displayed, Figure 5 - 1. Step 3. The Router Status screen will show up and tell the current WAN and LAN IP settings of your ZSR0104C SERIES, including IP address, Subnet Mask, Gateway, Primary DNS, and Secondary DNS.

  • Page 25: Administration

    5.3 Time Click the “System/Time” button, will see the Figure 5-3 If you want to assign the timeserver, enter the IP address then click “Apply” button to save. If sntp server gets time from network, the system time will display now time, else time is NULL. Local time means the pc’s time, you can also set the pc’s time for system time.

  • Page 26: Change Administrator's User Name And Password, Wan Side Administration

    Click the check mark of the “Allow administration from WAN side with port” to enable the remote access the NAT router. You can change the HTTP server default port number, 80, to any number in the range 1 to 65535 if it is desired or the port 80 of a virtual server is enabled.

  • Page 27: Firmware Upgrade

    • The network connection from the computer to the NAT router, which is targeted for the firmware upgrade. To make a local network connection, user can plug one end of Ethernet cable into the computer’s Ethernet port and the other end of cable to the NAT router’s one of four LAN ports.

  • Page 28

    Through the “Choose file” menu, locate the latest router firmware and open it. For example, the latest firmware file, zonet_2004.bin, is located and opened, the file name will appear at the entry of the firmware file name. Step 3. Click the “Apply” icon from the firmware upgrade page After clicking the “Apply”...

  • Page 29: Reset

    If click the “OK”, will appear firmware upgrade programming page, please wait for 35 seconds, the Nat will restart. When the firmware update is in process, please do not plug out the power adapter of ZSR0104C SERIES. The sudden disconnection of power supply may damage the flash hardware and cause the malfunction of ZSR0104C SERIES.

  • Page 30: Dynamic Dns (domain Name System)

    button on the confirmation page to make the ZSR0104C SERIES reboot. (See Figure 5 - 6) Figure 5 – 5 Figure 5 – 6 After clicking the OK button, Please remember: use 192.168.1.1 to access web page after reboot”. 5.7 Dynamic DNS (Domain Name System) If ZSR0104C SERIES acquired its WAN IP address via the DHCP or PPPoE schemes, its IP address is likely different from previous one after ZSR0104C SERIES is rebooted or PPPoE session is re-established.

  • Page 31

    Step 1. Select DDNS service provider. ZSR0104C SERIES supports two DDNS service providers, www.dyndns.org. Browse the DDNS service provider’s web page and register a new account there. Your DDNS service provider will provide you the account ID and password. Step 2. Go through the DDNS settings in ZSR0104C SERIES DDNS section. Select one DDNS service provider, and fill in the necessary information form DDNS service provider such as ID, password, and related settings etc.

  • Page 32: Dhcp Server, Dhcp Definition, Dhcp Server In Lan

    If dyndns.org was selected, User Name, Password and Host Name are mandatory; Enable Wildcard, Mail Exchanger and Backup MX are optional. Step 3. Update the IP address. When WAN public IP address changes, ZSR0104C SERIES will automatically inform your DDNS service provider the new IP address, or you can force the IP address update by clicking the Update button.

  • Page 33: Dhcp Client In Lan

    receive the same LAN IP address, when ZSR0104C SERIES assigns IP addresses in the next time. The Pool Range of Assigned IP Address When DHCP is enabled, you can assign a group of LAN IP addresses. The group is called as “the pool.”...

  • Page 34: Virtual Server (port Forwarding)

    5. DHCP Client List When DHCP is enabled. Will see how many DHCP clients get IP address form the NAT. If you want to enable DHCP in your PC, refer to A.1 Enable DHCP in Your PC in Appendix A: Configure TCP/IP in Your PC.

  • Page 35

    As illustrated as above, when ZSR0104C SERIES obtains traffic of Port 21 from the Internet, it will forward it to the FTP server with LAN IP address 192.168.1.2. If ZSR0104C SERIES receives traffic of Port 80, it will re-direct it to the Web server with LAN IP 192.168.0.3. To enable Virtual server, enter the port number to specify the service type, and the server’s LAN IP address for the traffic destination.

  • Page 36: Firewall, Dmz Host Configuration

    You can set up your personal computer or network-ready device to be a public or local DMZ hosts. In general, Internet applications use only one unique port and can pass through a NAT Router by enabling Virtual Server. However, some special applications need to implement multiple ports, port ranges, dynamically assigned ports, and special protocols. ZSR0104C SERIES can support the transparent pass-through of these special applications, such as FTP, NetMeeting/H.323, MSN Messenger, etc.

  • Page 37

    illustrated Then you will be able to communicate with your friend via NetMeeting. Besides, the other LAN clients behind ZSR0104C SERIES are still protected by its firewall, and the traffic initiated from the Internet is denied to access these LAN clients To activate Local DMZ Host, please check the Enable item and assign the LAN IP address of the LAN host.

  • Page 38: Anti Ping And Tcp/udp Echo Attack

    To enable Public DMZ Host, check Enable below Public DMZ Host and enter the public IP address of the device you want to assign as the Public DMZ Host. Then click the button Apply to make your settings take effect. The server in the Public DMZ is not protected by ZSR0104C SERIES firewall.

  • Page 39: Url Filter

    3. URL Filter If you want to restrict your LAN clients from accessing certain websites, enter the keywords of the websites in the blank. ZSR0104C SERIES will examine the packet information when receiving the packet with port 80 from the WAN. If it finds the listed keywords, it will drop the packet and LAN clients cannot obtain the information from the website.

  • Page 40

    Checked this item, the LAN client can access to the following services. For example, forwarding port 21.The LAN client only can access ftp in the Internet. Please refer to Appendix B: Common Port Numbers. 5. MAC Filter A. Disable Checked this item, the LAN client can access to Internet. B.

  • Page 41: Troubleshooting

    PC, the possible reasons could be as followed. Please check them in the following sequence. Router’s Hardware Failure. Failed Connection between ZSR0104C SERIES and Client PCs. Failed Connection on the ZSR0104C SERIES WAN Side.

  • Page 42: Router's Hardware Failure, Failed Connection Between Zsr0104c Series And Client Pc

    Please refer to the solution for each reason and solve your problem. If the problem persists, please contact our authorized distributor or dealer for technical support. 1. Router’s Hardware Failure Solution: 1. Make sure the Power adapter is securely plugged into a power outlet and Power LED is 2.

  • Page 43: Failed Connection On Zsr0104c Series's Wan Side, Dns (domain Name System) Failure, Forget Password

    3. Failed Connection on ZSR0104C SERIES WAN Side Solution: 1. Check if the WAN link/act LED is continuously on or flashing. 2. Verify that your WAN access type and the corresponding information are the same as the datasheet provided by your Internet Service Provider. 4.

  • Page 44: Appendix A, A.1 Disable Web Proxy

    Appendix A: A.1 Disable Web Proxy When the Web Proxy is disabled, your Web browser can obtain information from ZSR0104C SERIES without the Web Proxy block. This section is divided into 4 parts as followed, “Disable Web Proxy for Windows 95/98/ME/2000/NT,” “Disable Web Proxy for Windows XP,” “Disable Web Proxy for Mac,”...

  • Page 45

    Step 2. Click the Connections tab. Press the LAN Settings... button. (Figure A -22) Step 3. Verify the item “Use a proxy server” is not checked. Then click the OK button to close each the Internet Options window. (Figure A-23) Figure A–22 Figure A–23 Page 38...

  • Page 46

    D. B. Netscape Step 1. Open Netscape and click the Stop button. Choose Edit and then click Preferences... A Preferences window will pop up. (Figure A-24) Step 2. In Category, find Proxies under the advanced item. (Figure A-25) Figure A–24 Figure A–25 Page 39...

  • Page 47: For Windows Xp

    Step 3. Check Direct connection to the Internet. Then click the OK button. (Figure A-26) 2. For Windows XP If you use Windows XP, follow the steps to disable Web Proxy in your Web browser. A. Internet Explorer Step 1. Open Internet Explorer and click the Stop button. Choose Tools and then click Internet Options.

  • Page 48

    Step 2. Click the Connections tab. Press the LAN Settings... button. (Figure A-28) Step 3. Verify that the item Use a proxy server for your LAN is unchecked. Then click the OK button to close each the Internet Options window. (Figure A-29) Figure A–28 Figure A–29 Page 41...

  • Page 49

    B. Netscape Step 1. Open Netscape and click the Stop button. Choose Edit and then click Preferences... A Preferences window will pop up. (Figure A-30) Step 2. Choose Proxies under the advanced item. (Figure A-31) Figure A–30 Figure A–31 Page 42...

  • Page 50: For Unix/linux

    Step 3. Check Direct connection to the Internet. Then click the OK button. (Figure A-32) 3. For MAC The instructions are based on Mac OS 8.5. It is similar to Mac OS 7.x and above. Follow the steps to disable the Web Proxy. G.

  • Page 51: A.2 Verify Ip Settings, For Window 95/98/me,

    Verify IP settings in your client computer to make sure the network is working and learn your client PC’s LAN IP address and your ZSR0104C SERIES Router’s IP address. This section is divided into 5 parts, including “Verify IP Settings for Windows 95/98/ME,” “Verify IP Settings for Windows 2000/NT 4.0,”...

  • Page 52

    Step 2. Run the WINIPCFG command. (Figure A-34) Step 3. To release the previous IP settings in your computer, choose your network interface card in the menu. Then click the Release button. (Figure A-35) Step 4. To obtain new IP settings from WPD –140, click the Renew button. As listed below, the IP address is your client computer’s LAN IP address, and the Default Gateway is ZSR0104C SERIES IP address.

  • Page 53: For Windows 2000 /nt

    2. For Windows 2000 /NT If you use Windows 2000 or NT, follow the steps to verify the IP settings in your client PC. The steps and screenshots here are based on Windows 2000. It is similar to the other Windows Operating System.

  • Page 54

    Step 3. To release the previous IP settings in your computer, run the command “ipconfig / release.” (Figure A-39) Step 4. To obtain new IP settings from WPD –140, run “ipconfig / renew.” As listed below, the IP address is your client computer’s LAN IP address, and the Default Gateway is ZSR0104C SERIES IP address.

  • Page 55

    3. For Windows XP If you use Windows XP, follow the steps to verify the IP settings in your client computer. Step 1. Go through the path “Start→Run.”(Figure A-41) Step 2. Enter command and press the OK button. (Figure A-42) Step 3.

  • Page 56

    Step 4. To obtain new IP settings from WPD –140, run “ipconfig / renew.” As listed below, the IP address is your client computer’s LAN IP address, and the Default Gateway is ZSR0104C SERIES IP address. Make sure that your IP Address is 192.168.1.xxx (xxx ranges from 2 to 254), your Subnet Mask is 255.255.255.0, and your Default Gateway is 192.168.1.1.

  • Page 57

    “route –n”, the IP address of your Default Gateway will be displayed. It means your router’s IP address. Make sure that your IP address is 192.168.1.xxx (xxx ranges from 2 to 254), your Subnet Mask is 255.255.255.0, and your Default gateway is 192.168.1.1. These values confirm that your ZSR0104C SERIES is functioning.

  • Page 58: Appendix B: Common Port Numbers

    Appendix B: Common Port Numbers Port Number Service Name Echo Systat Chargen 20 (21) TELNET SMTP Time TACACS 67(68) BOOTP TFTP Gopher Finger HTTP(WEB) Kerberos POP2 POP3 AUTH SQLServ News/NNTP 137(138)(139) NetBIOS-ns, NetBIOS-dgm, NetBIOS-ssn IMAP2 161(162) SNMP (SNMPT RAP) IMAP3 LDAP HTTPS SYSLOG...

  • Page 59: Appendix C: Terminology

    ‧ DMZ (De-Militarized Zone) It allows LAN clients behind a NAT Router to be totally exposed and accessible to the WAN side in order to run special applications or set up a server. ‧...

  • Page 60

    It is a kind of TCP/IP protocol that sends the error message, the control message, and the information messages to a network device. For instance, a router uses ICMP to notify the sender that its destination node is not available. A ping utility can send ICMP echo request to verify the existence of an IP address, too.

  • Page 61

    ‧ Port It is a pathway of network device, such as a switch or a router. It can make connection between the LAN and the WAN via the network device. ‧...

  • Page 62

    ‧ RJ-45 Connector It is a connector that connects Ethernet devices via an Ethernet cable. ‧ Router It is a network device that divides a large network into small sub-networks, and that transmits packets with a routing table. ‧ Server A server is the computer that enables its clients to access files stored in it, to make printing, and to communicate within the same Ethernet network.

  • Page 63: D.1 Hardware Problem, D.2 Software Download, D.3 Installation/application Problem

    ‧ Virtual Server (Port Forwarding) A NAT Router can function as a Virtual Server that can forward the service packet specified with a port number to the LAN host specified by the LAN IP address. In other words, ZSR0104C SERIES can open the port for the service with specified port number and then “forward”...
