quick guide
variostring 120
swiss made power

Advertisement

loading

Related Manuals for Studer variostring 120

Summary of Contents for Studer variostring 120

  • Page 1 120 swiss made power...
  • Page 2 Herzlichen Glückwunsch ! designed and assembled Wir freuen uns, dass Sie sich für eines High-Tech-Gerät entschieden haben, by studer in Switzerland welches bei der Energie-management Ihrer Anlage entscheidende Rolle spielen wird. Der variostring (vs) ist ein MPPT-Solarladegerät. Wenn an Batterien und Photovoltaikmodule angeschlossen wird, lädt der vs die Batterien optimal nach.

  • Page 3: General Information

    Studer disclaims all responsibility and liability for damage, costs or losses resulting from an installation that does not comply with the instructions, a faulty operation or inadequate maintenance. The use of studer equipment is in any case under the responsibility of the customer.

  • Page 4: Mounting And Installation

    Mounting and installation Storage and content Fixing and dimensions 60°C 256mm -20°C min. 200mm min. 50mm Mounting place min. 200mm The batteries should only be installed by qualified personnel. 7.5kg 322mm 133mm...
  • Page 5 Wiring PV connection 5’ HIGH VOLTAGE • 2.5-6mm cable, Sunclix connector Protection device (PV side) • Switching device, max solar current : 2 x 13A (independent) / 1 x 26A (parallel) / 1 x 13A (serial) RTC battery • Overvoltage protection, SPD : 2 x 600Vdc (independent) / 1 x 600Vdc (parallel) / 1 x 900Vdc (series) remote entry INPUT 0-600Voc / 900Voc (series)
  • Page 6 Multi units and power up Display Display system on – the device is off Dual isolated string MPPT solar charger controller blink – error, check the manual Status Charge [A] Error Charge on – bulk Night 1x – floating 2x – absorption Floating 1x 3x - equalization Absorption 2x...

  • Page 7: Technical Data

    Configuring the variostring Technical data DIP switches Battery voltage (check manual) Lead-acid • Configure charge auto Series profile according to manufacturer Independent Parallel Lithium (comm BMS, xcom CAN) off • Check compatibility list and xcom CAN manual Spare 5-6 Others : NiCd, NiFe, Redox flow, Activate DIP saltwater, etc.

  • Page 8: Maintenance And Recycling

    Maintenance and recycling Maintenance and recycling Except for the periodic check of the connections (tightening, general condition), the variostring does not require any particular maintenance. To dispose of this product, please use the service for the collection of electrical waste and observe all obligations in force in the place of purchase.
  • Page 9 Serial Number : Installed by : Date : Signature : Call our specialists +41 27 205 60 80 or visit studer-innotec.com/support Studer Innotec SA rue des Casernes 57 1950 Sion, Switzerland info@studer-innotec.com 4O92 © All rights reserved Studer Innnotec SA – V1.0...
