STUDER INNOTEC Sinewave inverter SI SERIES User's and Installer's Handbook STUDER INNOTEC Rue des Casernes 57 CH-1950 Sion Tel : ++41 (0)27 205 60 80 Fax: ++41 (0)27 205 60 88 info@studer-innotec.com www.studer-innotec.com User manual SI V3.0 E...
Due to obvious safety reasons, the inverter is not automatically reactivated after a failure (overload, short circuit,…). Product presentation The inverters of the SI series are presented fully equipped, with battery cables, 230V cable and the user's handbook SI V3.0 E...
STUDER INNOTEC Assembly Location The place where the inverter is to be mounted should meet the following requirements : Out of reach of non authorised persons. In a dry place with no condensation. No inflammable material in the same room.
STUDER INNOTEC Adjustments (Not automatic with Twinpower version) Standby Level (1) The activation of the inverter, when working in automatic mode, is dictated by the detection of a load. With this function, it is possible to adjust the minimum load detected between 0,3 and 20 Watts.
We do not accept any responsibility for any violation of patent rights or other third person rights resulting from the use of the inverter. STUDER INNOTEC reserves the right to modify their products without previous notice. CE- declaration of conformity SI V3.0 E...
STUDER INNOTEC Wiring diagram for SI 600 - 800 S (Solar charge regulator) User manual SI V3.0 E...
Page 9
STUDER INNOTEC Option SI performance 3-phased Three SI inverters can be connected together to build a 3-phased grid. They have to be equipped with the PE option. Working Two ways of working are possible with the SI performance : 1) Working alone One SI inverter can be used alone.
STUDER INNOTEC Technical data Model SI Input voltage (Unom) [V] Nominal power [W] « Standby » current [mA] Power « ON » no load [W] Power « ON » no load [W] TWINPOWER system Maximum efficiency [%] Length L x 124 (H) x 215 (W) [mm]...
