Page 1 Keep the CD-ROM in a convenient place so you can use it quickly if you need to. Please visit us at http://solutions.brother.com where you can get product support, the latest driver updates and utilities, and answers to frequently asked questions (FAQs) and technical questions.
Page 2 Compilation and publication notice Under the supervision of Brother Industries Ltd., this manual has been compiled and published, covering the latest product’s descriptions and specifications. The contents of this manual and the specifications of this product are subject to change without notice.
Page 3: Important Note
In Europe If you have any comments or suggestions, please write to us at: In USA Printer Customer Support Brother International Corporation 26250 Enterprise Ct. # 250 Lake Forest, CA 92630 In Canada Brother International Corporation (Canada), Ltd. - Marketing Dept.
Page 4: Table Of Contents
Configuring your printer for a wireless network ...23 Using the SecureEasySetup™ software to configure your printer for a wireless network...23 Using the Brother automatic installer application on the CD-ROM to configure your wireless network printer ...28 Using the Setup Wizard from the control panel ...28 Changing the print server settings ...35...
Page 5 Specifying a different URL...105 Other sources of information ...105 Network printing from Macintosh Overview...106 How to select the printer driver (TCP/IP) ...106 ® using the Brother automatic installer ® using the Brother automatic installer ® : basic TCP/IP Peer-to-Peer printing ®...
Page 6 Control panel setup Overview...108 Changing the print server settings using the control panel LAN menu...109 Control panel LAN menu table and default factory settings ...109 Wired menu options...111 WLAN menu options (HL-4070CDW only) ...113 Printing the Printer Settings Page...116 How to print the Printer Settings Page ...116 Restoring the network settings to factory default...117 Disabling the APIPA protocol...118 Driver Deployment Wizard (Windows...
Page 7 Using APIPA to configure the IP address...161 Using ARP to configure the IP address ...161 Using the Telnet console to configure the IP address ...162 Using the Brother Web BRAdmin server software for IIS* to configure the IP address ...163 Appendix B Print server specifications...164 Ethernet wired network...164...
Page 8: Introduction
IEEE 802.11b/g Wireless Ethernet (TCP/IP) is available HL-4070CDW only. BRAdmin Professional is available as a download from http://solutions.brother.com To use the Brother printer through a network, you need to configure the print server, and set up the computers you use.
Page 9: Network Function Features
Management utility BRAdmin Light BRAdmin Light is a utility for initial setup of Brother network connected devices. This utility can search for Brother products on your network, view the status and configure basic network settings, such as IP address. The BRAdmin Light utility is available for Windows ®...
Page 10: Types Of Network Connection
Each computer must use the TCP/IP Protocol. The Brother printer needs to have an appropriate IP address configuration. If you are using routers, the Gateway address must be configured on the computers and the Brother printer. The Brother printer can also communicate with Macintosh...
Page 11 In a larger network, we recommend a Network Shared printing environment. The “server” or the “print server” must use the TCP/IP print protocol. The Brother printer needs to have an appropriate IP address configuration unless the printer is connected via the parallel or USB interface at the server.
Page 12: Wireless Network Connection Example (Hl-4070Cdw)
This type of network has a central access point at the heart of the network. The access point can also act as a bridge or a gateway to a wired network. When the Brother wireless printer (your printer) is part of this network, it receives all print jobs via an access point.
Page 13 This type of network has a central access point at the heart of the network. The access point is connected to a computer which is not wireless capable with the Ethenet cable. When the Brother wireless printer (your printer) is a part of this network, it receives all print jobs via an access point.
Page 14: Protocols
IP address from the range 169.254.1.0 to 169.254.254.255. DNS client The Brother print server supports the Domain Name Service (DNS) client function. This function allows the print server to communicate with other devices by using its DNS name.
Page 15 The Simple Network Management Protocol (SNMP) is used to manage network devices including computers, printers and terminals in a TCP/IP network. Web server (HTTP) The Brother print server is equipped with a web server that allows you to monitor its status or change some of its configuration settings. Note We recommend Microsoft Internet Explorer 6.0...
Page 16: Configuring Your Printer For A Network With An Ethernet Cable Connection Overview
Note If you do not wish to, or are unable to use the automatic installer or any of Brother’s software tools, you can also use the printer’s control panel to change network settings. For more information, see Control...
Page 17: Ip Addresses, Subnet Masks And Gateways
APIPA, see Using APIPA to configure the IP address on page 161. If the APIPA protocol is disabled, the IP address of a Brother print server is 192.0.0.192. However, you can easily change this IP address number to match with the IP address details of your network. For information on how to change the IP address, see Setting the IP address and subnet mask on page 12.
Page 18: Subnet Mask
Subnet mask Subnet masks restrict network communication. Example: Computer 1 can talk to Computer 2 • Computer 1 IP Address:192.168.1.2 Subnet Mask:255.255.255.0 • Computer 2 IP Address:192.168.1.3 Subnet Mask:255.255.255.0 Note 0 denotes that there is no limit to communication at this part of the address. In the above example, we can communicate with anything that has an IP address that begins with 192.168.1.X.
Page 19: Setting The Ip Address And Subnet Mask
2003 and Mac OS Note • Please use the BRAdmin Light utility version that was supplied on the CD-ROM with your Brother product. You can also download the latest version of BRAdmin Light utility from http://solutions.brother.com • If you require more advanced printer management, use the latest version of BRAdmin Professional utility that is available as a download from http://solutions.brother.com This utility is only available for Windows...
Page 20 Choose Static from Boot Method. Enter the IP address, Subnet Mask and Gateway (if needed) of your print server. ® Windows Click OK. With the correctly programmed IP address, you will see the Brother print server in the device list. Configuring your printer for a network with an Ethernet cable connection ® Macintosh ®...
Page 21: Using The Control Panel To Configure Your Printer For A Network
Using the control panel to configure your printer for a network You can configure your network printer using the control panel LAN menu on the LCD display. See Control panel setup on page 108. Using other methods to configure your printer for a network You can configure your network printer using other methods.
Page 22: Changing The Print Server Settings
® For Mac OS X 10.2.4 or greater users Double-click Macintosh HD (Startup Disk) / Library / Printers / Brother / Utilities / BRAdmin Light.jar file. Select the print server which you want to change the settings. Select Network Configuration from the Control menu.
Page 23 Type http://printer_ip_address/ into your browser. (Where printer_ip_address is the IP address or the print server name) For example: http://192.168.1.2/ (if the printer’s IP address is 192.168.1.2.) Note If you have edited the hosts file on your computer or are using a Domain Name System, you can also enter the DNS name of the print server.
Page 24: Configuring Your Printer For A Wireless Network (For Hl-4070Cdw)
This type of network has a central access point at the heart of the network. The access point can also act as a bridge or a gateway to a wired network. When your Brother wireless printer is part of this network, it receives all print jobs via the access point.
Page 25 This type of network does not have a central access point. Each wireless client communicates directly with each other. When the Brother wireless printer (your printer) is part of this network, it receives all print jobs directly from the computer sending the print data.
Page 26: Confirm Your Network Environment
Confirm your network environment The setup process will be different depending on your network environment Configuration using SecureEasySetup™. If your wireless access point (A) supports SecureEasySetup™, you do not need to use a computer to configure the printer. The access point (router) and your printer can automatically negotiate using the SecureEasySetup™...
Page 27: Wireless Network Terms And Concepts
(how the device identifies itself to the network) and encryption (how the data is encrypted as it is sent on the network). If you do not correctly specify these options when you are configuring your Brother wireless device, it will not be able to connect to the wireless network. Therefore care must be taken when configuring these options.
Page 28 LEAP (Light Extensible Authentication Protocol) has been developed by Cisco Systems, Inc. which uses user ID and password for authentication. Encryption methods Encryption is used to secure the data that is sent over the wireless network. The Brother printer supports the following encryption methods: None No encryption method is used.
Page 29 Network Key There are some rules for each security method: Open system/Shared key with WEP This key is a 64-bit or 128-bit value that must be entered in an ASCII or hexadecimal format. 64 (40) bit ASCII: 64 (40) bit hexadecimal: 128 (104) bit ASCII: 128 (104) bit hexadecimal: WPA-PSK/WPA2-PSK and TKIP or AES...
Page 30: Configuring Your Printer For A Wireless Network
Using the SecureEasySetup™ software to configure your printer for a wireless network The SecureEasySetup™ software of Broadcom Corporation is an easy way to configure your Brother device to your wireless network settings. By pushing a button on the wireless router or access point, you can complete setup and secure the wireless network.
Page 31 Press OK to move to the next menu level. WLAN TCP/IP Press the + or - button to select Setup WLAN. WLAN Setup WLAN Press OK to move to the next level. Setup WLAN Setup Wizard Press the + or - button to select SecureEasySetup. Setup WLAN SecureEasySetup Press OK.
Page 32 Click Install Printer Driver. Note Choose the Install Printer Driver icon for your region. Click Wireless Network users. Note For Windows Vista™, when the User Account Control screen appears, click Allow. Configuring your printer for a wireless network (For HL-4070CDW)
Page 33 Choose Driver Install Only, and then click Next. Go to Installing the printer driver on page 64, for the rest of the instructions. ® For Macintosh users ® Turn on your Macintosh Put the supplied CD-ROM into your CD-ROM drive. Double-click the HL4040_4050_4070 icon on your desktop.
Page 34 Click Wireless Network users. Choose Driver Install Only, and then click Next. Go to Installing the printer driver on page 91, for the rest of the instructions. Configuring your printer for a wireless network (For HL-4070CDW)
Page 35: Using The Brother Automatic Installer Application On The Cd-Rom To Configure Your Wireless Network Printer
Using the Brother automatic installer application on the CD-ROM to configure your wireless network printer We recommend that you use the Brother automatic installer application on the CD-ROM we have provided with the printer. For installation, see Wireless configuration for Windows installer application on page 37 or Wireless configuration for Macintosh application on page 67.
Page 36 If the displayed SSID you selected is in ad-hoc mode, go to step p. If you want to add a new SSID, go to step l. Select SSID&Set Brother Note If your access point is set to not broadcast the SSID, you will have to manually add the SSID name. Go to step l.
Page 37 Select the Authentication method using the + or - button, and press OK. If you select Open System, go to step p. If you select Shared Key, go to step q. If you select WPA/WPA2-PSK, go to step t. If you select LEAP, go to step u. Auth.
Page 38 The following will be displayed. To apply the wireless settings, select Yes and press OK. Go to x. To cancel, select No and press OK. Go to k. Apply Settings? The printer starts to connect the wireless device you have selected. Connecting WLAN If your connection to the wireless network is connected successfully, the display shows Connected for 2 seconds and configuration is completed.
Page 39 Click Wireless Network users. Note For Windows Vista™, when the User Account Control screen appears, click Allow. Choose Driver Install Only, and then click Next. Go to Installing the printer driver on page 64, for the rest of the instructions. Configuring your printer for a wireless network (For HL-4070CDW)
Page 40 ® For Macintosh users ® Turn on your Macintosh Put the supplied CD-ROM into your CD-ROM drive. Double-click the HL4040_4050_4070 icon on your desktop. Double-click the Start Here icon. Select your printer and the language. Click Install Printer Driver. Click Wireless Network users. Configuring your printer for a wireless network (For HL-4070CDW)
Page 41 Choose Driver Install Only, and then click Next. Go to Installing the printer driver on page 91, for the rest of the instructions. Configuring your printer for a wireless network (For HL-4070CDW)
Page 42: Changing The Print Server Settings
Once you have configured your printer for a wireless network, you can change the wireless settings using the BRAdmin Professional utility or the control panel on the front of the Brother printer. Using the BRAdmin Professional utility to change print server settings (for ®...
Page 43: Using The Control Panel To Change Print Server Settings
Using the control panel to change print server settings You can configure and change the print server settings using the control panel LAN menu. See Control panel setup on page 108. Using Web Based Management (web browser) to change print server settings A standard web browser can be used to change your print server settings using the HTTP (Hyper Text Transfer Protocol).
Page 44: Wireless Configuration For Windows Using The Brother Automatic Installer Application
Wireless configuration for Windows using the Brother automatic installer application Configuration with an access point that supports SecureEasySetup™ Note • If you are going to connect the printer to your network, we recommend that you contact your system administrator prior to installation.
Page 45 Click Wireless Network users. Note For Windows Vista™, when the User Account Control screen appears, click Allow. Choose Wireless Setup and Driver Install or Wireless Setup Only, and then click Next. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 46 Next. Confirm the on-screen message and click Next. Refer to the instruction manual that came with your access point to use the SecureEasySetup™ mode of your access point. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 47 Connecting WLAN, Connected or Connection NG. Connecting WLAN is displayed when the print server is trying to make connections to your router or access point. Wait till either Connected or Connection NG is displayed. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 48 Check the box after you confirm that you have completed the wireless settings, and then click Next. Go to Installing the printer driver on page 64. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 49: Configuration In Infrastructure Mode
Press OK to move to the next menu level. Wired Press the + or - button to select WLAN. WLAN Press OK to move to the next level. WLAN TCP/IP ® Wireless configuration for Windows using the Brother automatic installer application...
Page 50: Configure The Wireless Settings
Put the supplied CD-ROM into your CD-ROM drive. The opening screen will appear automatically. Select your printer and the language. Click Install Printer Driver. Note Choose the Install Printer Driver icon for your region. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 51 Click Wireless Network users. Note For Windows Vista™, when the User Account Control screen appears, click Allow. Choose Wireless Setup and Driver Install or Wireless Setup Only, and then click Next. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 52 Read the Important Notice and check the box after you confirm this setting, and then click Next. Choose Manual and then click Next. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 53 Choose I’m not able to connect my device to my access point with a network cable and then click Next. Go to j. Connect the Brother wireless device to your access point using a network cable and click Next. Go to n. ®...
Page 54 Next. Go to k. Check the box after you confirm that you have completed the wireless settings, and then click Next. Go to Installing the printer driver on page 64. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 55 Check the box after you confirm these settings, and then click Next. ® Wireless configuration for Windows using the Brother automatic installer application Record the current wireless computer settings...
Page 56 Check the Wireless Network Connection status. It may take a few minutes to change from 0.0.0.0 to 169.254.x.x IP address to be shown on screen (where x.x. are numbers between 1 and 254). ® Wireless configuration for Windows using the Brother automatic installer application...
Page 57 • If the list is blank, check that the access point has power and is broadcasting the SSID, and then see if the printer and the access point are within range for wireless communication. Then, click Refresh. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 58 If your network is configured for Authentication and Encryption, the following screen will appear. When configuring your Brother wireless printer, you must ensure that it is configured to match the Authentication and Encryption settings of your existing wireless network. Choose the Authentication Method and Encryption Mode from the pull-downs in each setting box.
Page 59 Follow the on-screen instructions. For the users connected with a network cable for configuration: Disconnect the network cable between your access point (hub or router) and the printer, and click Next. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 60 ® Wireless configuration for Windows using the Brother automatic installer application For the users connected without a network cable for configuration: Using the information you recorded in l, return the wireless settings of your computer back to their original settings. Check the box if you confirm this step, and then click Next or Finish.
Page 61: Configuration In Ad-Hoc Mode
Press OK to move to the next menu level. Wired Press the + or - button to select WLAN. WLAN Press OK to move to the next level. WLAN TCP/IP ® Wireless configuration for Windows using the Brother automatic installer application...
Page 62: Configure The Wireless Settings
Put the supplied CD-ROM into your CD-ROM drive. The opening screen will appear automatically. Select your printer and the language. Click Install Printer Driver. Note Choose the Install Printer Driver icon for your region. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 63 Click Wireless Network users. Note For Windows Vista™, when the User Account Control screen appears, click Allow. Choose Wireless Setup and Driver Install or Wireless Setup Only, and then click Next. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 64 Read the Important Notice and check the box after you confirm this setting, and then click Next. Choose Manual and then click Next. Choose I’m not able to connect my device to my access point with a network cable and then click Next. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 65 Authentication method: (Open system / Shared key / WPA/WPA2-PSK / LEAP) Encryption: (None / WEP / WPA / TKIP / AES/ CKIP) Encryption key: ® Wireless configuration for Windows using the Brother automatic installer application Record the current wireless computer settings...
Page 66 Select and right click Wireless Network Connection. Click View Available Wireless Networks. You can see the SSID of the wireless printer in the list. Select SETUP and click Connect. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 67 Next. Note • If the list is blank, check if the printer is within range for wireless communication. Then, click Refresh. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 68 If your network is configured for Authentication and Encryption, the following screen will appear. When configuring your Brother wireless printer, you must ensure that it is configured to match the Authentication and Encryption settings of your existing wireless network. Choose the Authentication Method and Encryption Mode from the pull-downs in each setting box.
Page 69 Cancel. Note If you want to manually enter the IP address settings of your printer, click Change IP Address and enter the necessary IP address settings for your network. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 70 (The settings shown on this screen are for example only. Your settings will not be the same.) You have completed the wireless setup. If you chose to install the printer driver in step e, Go to Installing the printer driver on page 64. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 71: Installing The Printer Driver
If you encounter this failure, please go to step 1 and setup the wireless connection again. The driver installation starts. When the License Agreement window appears, click Yes if you agree to the License Agreement. Choose Standard Installation, and then click Next. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 72 Contact your administrator if you do not know the printer's IP address or node name. Choose your printer, and then click Next. Note If your printer takes a long time (about 1 minute) to appear on the list, click Refresh. ® Wireless configuration for Windows using the Brother automatic installer application...
Page 73 ® Wireless configuration for Windows using the Brother automatic installer application Click Finish. Note • If you want to register your product on-line, check On-Line Registration. • If you do not want to set your printer as Default printer, uncheck Set as Default Printer.
Page 74: Wireless Configuration For Macintosh Using The Brother Automatic Installer Application
Wireless configuration for Macintosh using the Brother automatic installer application Configuration with an access point that supports SecureEasySetup™ Note If you are going to connect the printer to your network, we recommend that you contact your system administrator prior to installation.
Page 75 Choose Wireless Setup and Driver Install or Wireless Setup Only, and then click Next. Read the Important Notice and check the box after you confirm this setting, and then click Next. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 76 Select ab or OK Machine Info. Press the + or - button to select LAN. Select ab or OK Press OK to move to the next menu level. Wired ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 77 Try starting from a again. If the same message is displayed again, reset the print server back to the default factory settings and try again. Note If the LCD shows Connection NG, please try again. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 78 Check the box after you confirm that you have completed the wireless settings, and then click Next. Go to Installing the printer driver on page 91. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 79: Configuration In Infrastructure Mode
Press the + or - button to select WLAN. WLAN Press OK to move to the next level. WLAN TCP/IP Press the + or - button to select WLAN Enable. WLAN WLAN Enable ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 80: Configure The Wireless Settings
Put the supplied CD-ROM into your CD-ROM drive. Double-click the HL4040_4050_4070 icon on your desktop. Double-click the Start Here icon. Select your printer and the language. Click Install Printer Driver. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 81 Choose Wireless Setup and Driver Install or Wireless Setup Only, and then click Next. Read the Important Notice and check the box after you confirm this setting, and then click Next. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 82 Choose I’m able to temporarily connect my device to my access point with a network cable and then click Next. Go to i. If you do not have a network cable or cannot temporarily connect the Brother wireless device to your access point: Choose I’m not able to connect my device to my access point with a network cable and then...
Page 83 Connect the Brother wireless device to your access point using a network cable and click Next. Go to n. If you choose This computer has wireless capability., check I am using an access point in infrastructure mode, and then click Next. Go to l.
Page 84 Authentication method: (Open system / Shared key / WPA/WPA2-PSK / LEAP) Encryption: (None / WEP / WPA / TKIP / AES/ CKIP) Encryption key: ® Wireless configuration for Macintosh using the Brother automatic installer application Record the current wireless computer settings...
Page 85 You can temporarily change the wireless settings on your computer, following the steps below: Click the AirPort status icon and select Open Internet Connect... Click the Network tab to see the available wireless devices. You can see the Brother wireless print server in the Network option. Select SETUP.
Page 86 Follow the on-screen instructions for entering the Name (SSID) and the Channel number. If your network is not configured for Authentication and Encryption, the following screen will appear. To continue configuration, click OK and go to r. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 87 If your network is configured for Authentication and Encryption, the following screen will appear. When configuring your Brother wireless printer, you must ensure that it is configured to match the Authentication and Encryption settings of your existing wireless network. Choose the Authentication Method and Encryption Mode from the pull-downs in each setting box.
Page 88 ® Wireless configuration for Macintosh using the Brother automatic installer application Follow the on-screen instructions. For the users connected with a network cable for configuration: Disconnect the network cable between your access point (hub or router) and the printer, and click Next.
Page 89: Configuration In Ad-Hoc Mode
Press the + or - button to select WLAN. WLAN Press OK to move to the next level. WLAN TCP/IP Press the + or - button to select WLAN Enable. WLAN WLAN Enable ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 90: Configure The Wireless Settings
Put the supplied CD-ROM into your CD-ROM drive. Double-click the HL4040_4050_4070 icon on your desktop. Double-click the Start Here icon. Select your printer and the language. Click Install Printer Driver. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 91 Choose Wireless Setup and Driver Install or Wireless Setup Only, and then click Next. Read the Important Notice and check the box after you confirm this setting, and then click Next. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 92 Choose I’m not able to connect my device to my access point with a network cable and then click Next. Choose This computer has wireless capability., and make sure I am using an access point in infrastructure mode is not checked. Click Next. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 93 You can temporarily change the wireless settings on your computer, following the steps below: Click the AirPort status icon and select Open Internet Connect... ® Wireless configuration for Macintosh using the Brother automatic installer application Record the current wireless computer settings...
Page 94 Click the Network tab to see the available wireless devices. You can see the Brother wireless print server in the Network option. Select SETUP. Your wireless network is connected successfully. Choose the printer you wish to configure, and click Next. If the list is blank, check if the printer is powered on, and then click Refresh.
Page 95 If your network is configured for Authentication and Encryption, the following screen will appear. When configuring your Brother wireless printer, you must ensure that it is configured to match the Authentication and Encryption settings of your existing wireless network. Choose the Authentication Method and Encryption Mode from the pull-downs in each setting box.
Page 96 Cancel. Note If you want to manually enter the IP address settings of your printer, click Change IP Address and enter the necessary IP address settings for your network. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 97 (The settings shown on this screen are for example only. Your settings will not be the same.) You have completed the wireless setup. If you chose to install the printer driver in step e, Go to Installing the printer driver on page 91. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 98: Installing The Printer Driver
For Mac OS X 10.2.4 to 10.2.8 users: Go to step c. The Brother software will search for the Brother printer. During this time the following screen will appear. Note • If more than one printer is available, the following list appears. Choose the printer you wish to connect, and then click OK.
Page 99 When this screen appears, click OK. ® For Mac OS X 10.3 or greater users: Setup is now complete. When this screen appears, click Add. Make the following selection. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 100 (MAC address) will be displayed after the model name. Click Print Center, then Quit Print Center. ® For Mac OS X 10.2.4 to 10.2.8 users: Setup is now complete. ® Wireless configuration for Macintosh using the Brother automatic installer application...
Page 101: Network Printing From Windows : Basic Tcp/Ip Peer-To-Peer Printing
• Verify the host computer and print server are either on the same subnet, or that the router is properly configured to pass data between the two devices. • The default password for Brother print servers is access. ® : basic...
Page 102: Configuring The Standard Tcp/Ip Port
Configuring the standard TCP/IP port Printer driver not yet installed For Windows Vista™ Click the Start button, Control Panel, Hardware and Sound, and then Printers. Click Add a printer. Select Add a local printer. You must now select the correct Network printing port. Select Create a new port and select Standard TCP/IP Port from the pull-down window, then click Next.
Page 103 ® For Windows 2000/XP and Windows Server ® For Windows XP and Windows Server ® For Windows 2000: Click the Start button, select Settings and then Printers. ® For Windows XP and Windows Server ® For Windows 2000: Double click the Add Printer icon to start the Add Printer Wizard. Click Next when you see the Welcome to the Add Printer Wizard screen.
Page 104: Printer Driver Already Installed
Printer driver already installed If you have already installed the printer driver and wish to configure it for network printing, follow these steps: For Windows Vista™: Click the Start button, Control Panel, Hardware and Sound, and then Printers. ® For Windows XP and Windows Server Click the Start button and select Printers and Faxes windows.
Page 105: Network Printing From Windows Netbios Peer-To-Peer Printing
NetBIOS Peer-to-Peer printing Overview Brother print server range supports SMB (Server Message Block). This means that just like regular Windows computer's, Brother printers can appear in your network neighborhood. The main advantage of NetBIOS printing is that you are able to print from legacy DOS applications that are running on computer's that are ®...
Page 106: Print Server Configuration For Windows ® 2000/Xp, Windows Vista™ And Windows Server ® 2003
The print server does not care if your network consists of a Workgroup or a Domain, the only thing you must tell it is the name of the workgroup or domain. The Brother print server automatically has a default workgroup/domain name of WORKGROUP. If you need to change name, you can configure the Brother print server to recognize this.
Page 107 Select NetBIOS tab. Enter a workgroup/domain name. Note Because of the way that Microsoft the network neighborhood. You will also find that the print server may take several minutes to disappear from the network neighborhood even if the printer is switched off. This is a feature of Microsoft and domain based networks.
Page 108: Internet Printing For Windows
• Verify the host computer and print server are either on the same subnet, or that the router is properly configured to pass data between the two devices. • The default password for Brother print servers is access. • This print server also supports the IPPS printing, see Printing documents securely using IPPS on page 129.
Page 109 If your printer is not in the list of supported printers, click Have Disk. You will then be asked to insert the driver disk. Click Browse and select the appropriate Brother printer driver that is contained in the CD-ROM or in the network share. Click Open.
Page 110: For Windows ® 2000/Xp And Windows Server ® 2003
® For Windows 2000/XP and Windows Server ® For Windows XP and Windows Server ® For Windows 2000: Click the Start button, select Settings and then Printers. ® For Windows XP and Windows Server ® For Windows 2000: Double click the Add Printer icon to start the Add Printer Wizard. Click Next when you see the Welcome to the Add Printer Wizard screen.
Page 111 Click Continue Anyway to continue with the installation. Click OK when you see the Insert Disk screen. Click Browse and select the appropriate Brother printer driver that is contained in the CD-ROM or in the network share. Click Open.
Page 112: Specifying A Different Url
Specifying a different URL Please note that there are several possible entries that you can enter for the URL field. http://printer_ip_address:631/ipp This is the default URL and we recommend that you use this URL. Please note the Get More Info option will not display any printer data.
Page 113: Network Printing From Macintosh
Network printing from Macintosh Overview This chapter explains how to configure the BR-Script 3 (PostScript on a Network. The BR-Script 3 printer driver is available for HL-4050CDN and HL-4070CDW. How to select the printer driver (TCP/IP) Turn the power of the printer ON.
Page 114 • When specifying the Queue Name, use the value brnxxxxxx_p1_at for a wired network or brwxxxxxx_p1_at for a wireless network (where xxxxxx are the last 6 digits of the Ethernet address). From the Print Using pull-down list select your model. For example, select Brother HL-4050CDN BR-Script3. ® (Mac OS X 10.2.4 to 10.3.x)
Page 115: Control Panel Setup
Control panel setup Overview With the control panel you can do the following: Change the print server settings See Changing the print server settings using the control panel LAN menu on page 109. Print the Printer Settings Page See Printing the Printer Settings Page on page 116 for information on how to print the Printer Settings Page. Restore the network settings to factory default See Restoring the network settings to factory default on page 117 for information on how to restore the network settings to factory default.
Page 116: Changing The Print Server Settings Using The Control Panel Lan Menu
The LAN menu selections of the control panel allow you to set up the Brother printer for your network configuration. Press any of the Menu buttons (+, -, OK or Back), and press the + or - button to move forward or backward through the menus until LAN is displayed.
Page 117 (HL-4070CDW) See (HL-4040CN / HL-4050CDN) on page 109 for the HL-4040CN / HL-4050CDN LAN menu table. Level one Level two Level three Wired TCP/IP Ethernet Set to Default Wired Enable WLAN TCP/IP Setup WLAN Level four Options BOOT Method Auto*, Static, RARP, BOOTP, DHCP IP Address [000-255].[000-255].[000-255].[000-...
Page 118: Wired Menu Options
• RARP The Brother print server IP address can be configured using the Reverse ARP (RARP) facility on your host computer. For more information on RARP, see Using RARP to configure the IP address on page 160.
Page 119 • BOOTP BOOTP is an alternative to rarp that has the advantage of allowing configuration of the subnet mask and gateway. For more information on BOOTP, see Using BOOTP to configure the IP address on page 159. • DHCP Dynamic Host Configuration Protocol (DHCP) is one of several automated mechanisms for IP address allocation.
Page 120: Wlan Menu Options (Hl-4070Cdw Only)
IPv6 This printer is compatible with IPv6, the next generation internet protocol. If you want to use the IPv6 protocol, visit http://solutions.brother.com for more information. Ethernet Ethernet link mode. Auto allows the print server to operate in 100BASE-TX full or half duplex, or in 10BASE-T full or half duplex mode by auto negotiation.
Page 121 WLAN Status Status This field displays the current wireless network status; Active (11b), Active (11g), Wired LAN Active, WLAN OFF or Connection NG. Press the + or - button to select LAN. Press OK. Press the + or - button to select WLAN. Press OK. Press the + or - button to select WLAN Status.
Page 122 SSID This field displays the current wireless network SSID. Press the + or - button to select LAN. Press OK. Press the + or - button to select WLAN. Press OK. Press the + or - button to select WLAN Status. Press OK. Press the + or - button to select SSID.
Page 123: Printing The Printer Settings Page
Printing the Printer Settings Page Note Node name: Node name appears in the Printer Settings Page. The default Node name of the network card in the printer is “BRNxxxxxx” for a wired network and "BRWxxxxxx" for a wireless network (where “xxxxxx”...
Page 124: Restoring The Network Settings To Factory Default
Restoring the network settings to factory default If you wish to reset the print server back to its default factory settings (resetting all information such as the password and IP address information), please follow these steps: Make sure that the power cord is plugged in. Turn on the printer and wait until the printer is in the Ready state.
Page 125: Disabling The Apipa Protocol
Press any of the Menu buttons (+, -, OK or Back) to take the printer off line. Press the + or - button to select LAN, and press OK. For HL-4040CN / HL-4050CDN users: Go to stepf For HL-4070CDW users: Go to step e Press + or - button to select Wired or WLAN that you want to change, and press OK.
Page 126: Driver Deployment Wizard (Windows ® Only)
Driver Deployment Wizard (Windows only) Overview The Driver Deployment Wizard software can be used to ease the installation or even automate the installation of a locally connected or network connected printers. The Driver Deployment Wizard can also be used to create self running executable files which when run on a remote PC, completely automate the installation of a printer driver.
Page 127: Network Shared
Network Shared The device is connected to a network and a central print queue is used to manage all print jobs. Windows Windows Windows 1 Network Shared 2 Print server 3 Network printer 4 TCP/IP, USB or Parallel (where available) 5 Client Computer Local Printer (USB, LPT1) The device is connected to the computer using a parallel or USB cable.
Page 128: How To Install The Driver Deployment Wizard Software
How to install the Driver Deployment Wizard software Put the supplied CD-ROM into your CD-ROM drive. The opening screen will appear automatically. Select your model and the language. Then click Install Other Drivers or Utilities. Select the Driver Deployment Wizard installation program. Note For Windows Vista™, when the User Account Control screen appears, click Continue.
Page 129: Using The Driver Deployment Wizard Software
Choose your connection type to the printer that you want to print to. Choose the option you require, and follow the on-screen instructions. If you choose Brother Peer-to-Peer Network Printer, the following screen is displayed. Setting the IP Address If the printer does not have an IP address, the Wizard will allow you to change the IP address by selecting the printer from the list and by selecting the Configure IP option.
Page 130 Check Yes if you want to install the Interactive Help feature and then click Next. A summary screen will appear. Confirm the settings of the driver. Creating an executable file The Driver Deployment Wizard software can also be used to create self running .EXE files. These self-running .EXE files can be saved to the network, copied to a CD-ROM, a floppy disc or even E-mailed to another user.
Page 131: Security Features
Security features Overview In today’s world there are many security threats to your network and the data that travels over it. Your Brother printer employs some of the latest network security and encryption protocols available today. These network features can be integrated into your overall network security plan to help protect your data and prevent unauthorized access to the printer.
Page 132: Security Protocols
The printing protocol that the Internet Printing Protocol (IPP Version 1.0) uses SSL. Security methods for E-mail notification The Brother print server supports the following security methods for E-mail notification. Note How to configure the settings of security methods, see Using Web Based Management (web browser) to change the print server settings on page 15.
Page 133: Configuring The Protocol Settings
Configuring the protocol settings You can enable or disable the each protocol and security method using Web Based Management (web browser). Note We recommend Microsoft Internet Explorer 6.0 ® Safari™ 1.0 for Macintosh . Please also make sure that JavaScript and Cookie are always enabled in whichever browser you use.
Page 134: Managing Your Network Printer Securely
Managing your network printer securely To manage your network printer securely, you need to use the management utilities with security protocols. Secure Management using Web Based Management (web browser) To use the HTTPS protocol, the following printer settings are required. A certificate and private key must be installed in the printer.
Page 135: Secure Management Using Bradmin Professional (For Windows ® )
To use the BRAdmin Professional utility securely, you need to follow the points below. We strongly recommend to use the latest version of the BRAdmin Professional utility or Web BRAdmin that are available as a download from http://solutions.brother.com If you use an older version of BRAdmin to manage your brother devices the user authentication will not be secure.
Page 136: Printing Documents Securely Using Ipps
Printing documents securely using IPPS To print documents securely over the internet, you can use the IPPS protocol. Note • Communication using IPPS cannot prevent unauthorized access to the printer server. ® • IPPS is available for Windows To use the IPPS protocol, the following printer settings are required. A certificate and private key must be installed in the printer.
Page 137: Using E-Mail Notification With User Authentication
Using E-mail notification with user authentication To use the E-mail notification function via secure SMTP server that requires a user authentication, you need to use POP before SMTP or SMTP-AUTH method. These methods prevent an unauthorized user from accessing the mail server. You can use Web Based Management (web browser), BRAdmin Professional and Web BRAdmin to configure these settings.
Page 138 You can configure the POP3/SMTP settings on this page. Note • If you can use both POP before SMTP and SMTP-AUTH, we recommend choosing SMTP-AUTH. • If you choose POP before SMTP for the SMTP Server Authentication Method, you need to configure POP3 settings.
Page 139: Creating And Installing A Certificate
Creating and installing a certificate The Brother print server allows you to use SSL/TLS communication by configuring a certificate and corresponding private key. This print server supports two certification methods. A self-signed certificate and a certificate that is issued by a CA (Certificate Authority).
Page 140 Enter a user name and a password. The User Name is admin and the default Password is access. Click OK. Click Configure Certificate. You can configure the certificate settings from the screen below. Note • The functions that are grayed and unlinked indicate they are not available. •...
Page 141: Creating And Installing Self-Signed Certificate
Creating and installing self-signed certificate How to create and install a self-signed certificate Click Create Self-Signed Certificate on the Configure Certificate page. Enter a Common Name and a Valid Date, then click Submit. Note • The length of the Common Name is less than 64 bytes. Enter an identifier such as an IP address, host name or domain name to use when accessing this printer through SSL/TLS communication.
Page 142 How to install the self-signed certificate on your computer Note The following steps are for Microsoft Internet Explorer. If you use another web browser, follow the help text of the web browser itself. For Windows Vista™ users that have administrator rights Click Start and All Programs.
Page 143 Type https://printer_ip_address/ into your browser to access your printer. (Where printer_ip_address is the IP address or the print server name) Then, click Continue to this website (not recommended). Click Certificate Error, and then click View certificates. For the rest of the instructions, follow the steps from d on page 143.
Page 144 For Windows Vista™ users that do not have administrator rights Click Start and All Programs. Right click Internet Explorer, and then click Run as administrator. Choose the Administrator that you want to install with and enter the administrator password, and then click OK.
Page 145 Type https://printer_ip_address/ into your browser to access your printer. (Where printer_ip_address is the IP address or the print server name) Then, click Continue to this website (not recommended). Click Certificate Error, and then click View certificates. Choose the Details tab, and then click Copy to File... Security features...
Page 146 Click Next. Make sure that DER encoded binary X.509 (.CER) is chosen, and then click Next. Click Browse... Security features...
Page 147 Click Browse Folders. Choose a folder you want to save the certificate file in and enter a file name, and then click Save. Note If you choose Desktop, the certificate file is saved to the Desktop of Administrator that you chose. Click Next.
Page 148 Click Finish. Click OK. Click OK. Security features...
Page 149 Open the folder that you saved the certificate file in k and double-click the certificate file. For the rest of the instructions, follow the steps from d on page 143. ® For Windows 2000/XP and Windows Server Start your web browser. Type https://printer_ip_address/ into your browser to access your printer.
Page 150 Click Install Certificate… from the General tab. When the Certificate Import Wizard appears, click Next. Choose Place all certificates in the following store and then, click Browse... Security features...
Page 151 Choose Trusted Root Certification Authorities and then, click OK. Click Next. Click Finish. Security features...
Page 152 Click Yes, if the fingerprint (thumbprint) is correct. Note The fingerprint (thumbprint) is printed on the Printer Settings Page. To learn how to print the Printer Settings Page, see Printing the Printer Settings Page on page 116. Click OK. Now the self-signed certificate is installed on your computer, and SSL/TLS communication is available. Security features...
Page 153: Creating Csr And Installing A Certificate
• If you are using Enterprise root CA of Windows Server CertificateTemplate when creating the certificate. For more information, visit us at http://solutions.brother.com How to install the certificate to your printer When you receive the certificate from a CA, follow the steps below to install it into the print server.
Page 154 Now the certificate is created successfully. Check the box on the left of each function you want to disable, and then click OK. Note • We recommend disabling the Telnet, FTP, TFTP protocols and the network management with older versions of BRAdmin for secure communication.
Page 155: Import And Export The Certificate And Private Key
Import and export the certificate and private key How to import the certificate and private key Click Import Certificate and Private Key on the Configure Certificate page. Specify the file that you want to import. Enter the password if the file is encrypted, and then click Submit. Now the certificate and private key are imported successfully.
Page 156 How to export the certificate and private key Click Export Certificate and Private Key on the Configure Certificate page. Enter the password if you want to encrypt the file. Note If a blank password is used, the output is not encrypted. Enter the password again for confirmation, and then click Submit.
Page 157: Troubleshooting
Overview This chapter explains how to resolve typical network problems you may encounter when using the Brother network printer. If, after reading this chapter, you are unable to resolve your problem, please visit the Brother Solutions Center at: http://solutions.brother.com This chapter is divided into the following sections:...
Page 158: General Problems
If the box is selected, click the box to remove the check. Then, click Once your firewall is disabled, try reinstalling the Brother software package. For instructions on how to install from the CD-ROM, use the Quick Setup Guide we have provided with the printer.
Page 159 In this case, you will need to disable the Firewall on your computer whenever you install the network drivers. Note After the Brother software package is installed, enable again your Firewall. For instructions on how to re- enable your Firewall software, refer to your User’s Guide or contact the Firewall software manufacturer. ®...
Page 160: Network Print Software Installation Problems
Make sure that the printer is powered on, is on-line and ready to print. Check to see if there is any LED activity. Brother print servers have two LEDs on the back panel of the printer. The upper green LED shows Link/Activity (Received/Transmit) status. The lower orange LED shows Speed status.
Page 161 Where ipaddress is the print server IP address (note that in some instances it can take up to two minutes for the print server to load its IP address after setting the IP address). If you have tried a to d above and it does not work, then reset the print server back to the default factory settings and try from the initial setup again.
Page 162: Printing Problems
Printing problems Print job is not printed Make sure the status and configuration of the print server. Check following: Make sure that the printer is powered on, is on-line and ready to print. Print the Printer Settings Page of the printer and check if the settings such as IP address settings are correct for your network.
Page 163: Protocol-Specific Troubleshooting
This will then force Windows 2000/XP, Windows Vista™ and Windows Server communicate with the Brother print server. Web Based Management (web browser) troubleshooting (TCP/IP) If you cannot connect to the print server using your web browser it may be worth checking the Proxy Settings of your browser.
Page 164: Wireless Network Troubleshooting
Wireless network troubleshooting Wireless setup problems The Brother print server is not found during setup using the automatic installer application on the CD-ROM. Make sure that the printer is powered on, is on-line and ready to print. Move your computer closer to the Brother printer and try again.
Page 165: Wireless Connection Problem
Wireless connection problem The wireless network connection is sometimes disabled. The wireless network connection status is affected by the environment where the Brother printer and other wireless devices are located. The following conditions may cause connection problems: A concrete or metal framed wall is installed between the Brother printer and the access point.
Page 166: A Appendix A
Appendix A Using services A service is a resource that can be accessed by computers that wish to print to the Brother print server. The Brother print server provides the following predefined services (do a SHOW SERVICE command in the Brother print server remote console to see a list of available services): Enter HELP at the command prompt for a list of supported commands.
Page 167: Using Rarp To Configure The Ip Address
For AT&T UNIX -based systems, type: ps -ef | grep -v grep | grep rarpd The Brother print server will get the IP address from the rarp daemon when the printer is powered on. Appendix A ® systems also have template ®...
Page 168: Using Apipa To Configure The Ip Address
For more information, see Disabling the APIPA protocol on page 118. If the APIPA protocol is disabled, the IP address of a Brother print server is 192.0.0.192. However, you can easily change this IP address number to match with the IP address details of your network.
Page 169: Using The Telnet Console To Configure The Ip Address
(web browser), Telnet (using the SET IP ADDRESS command) or factory reset the print server (which will then allow you to use the ARP command again). Using the Telnet console to configure the IP address You can also use the Telnet command to change the IP address. Telnet is an effective method to change the printer’s IP address.
Page 170: Using The Brother Web Bradmin Server Software For Iis* To Configure The Ip Address
Java. Please note this software is not included on the CD-ROM that was supplied with your Brother product. Please visit http://solutions.brother.com to learn more about this software and to download it.
Page 171: B Appendix B
Network type 10/100BASE-TX Ethernet network Network printing Windows printing Mac OS If you want to use the IPv6 protocol, visit http://solutions.brother.com for more information. ® ® 2000/XP, Windows XP Professional x64 Edition, Windows Vista™, ® 2003, 2003 x64 Edition, Mac OS...
Page 172: Ethernet Wireless Network
Data rates IEEE 802.11b/g wireless Network printing Windows printing Mac OS If you want to use the IPv6 protocol, visit http://solutions.brother.com for more information. ® ® 2000/XP, Windows XP Professional x64 Edition, Windows Vista™, ® 2003, 2003 x64 Edition, Mac OS...
Page 173: Computer Requirements
BRAdmin Professional Windows Windows Windows Server Web BRAdmin Windows NT Windows Windows Server BRAdmin Professional and Web BRAdmin are available as a download from http://solutions.brother.com Processor Minimum Speed ® ® Intel Pentium or equivalent AMD Opteron™ AMD Athlon™ 64 ®...
Page 174: C Appendix C
Appendix C Open Source Licensing Remarks Open SSL statements OpenSSL License Copyright © 1998-2005 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 1.
Page 175 Appendix C Original SSLeay License Copyright © 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved. This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL. This library is free for commercial and non-commercial use as long as the following conditions are aheared to.
Page 176 ARP ... 161 Authentication ... 20 BINARY_P1 ... 159 BOOTP ...7 BRAdmin Light ... 2 BRAdmin Professional ...2 Brother Solutions Center ... 2 CA ...124 Certificate ... 124 Channels ... 20 CKIP ... 21 Computer requirements ... 166 Control panel ... 108 CSR ...124...
Page 177 Public key cryptosystem ... 124 RARP ...7 RFC 1001 ...10 Router ... 11 SecureEasySetup ... 19 Security method ... 125 Security protocol ... 125 Security term ... 124 Self-signed certificate ...132 Server Message Block ... 98 Service ... 159 Setup Wizard ... 28 Shared key ...
