computer. The VCP device drivers must be installed on the host PC prior to establishing
communications with the VC707 board.
The USB Connector Pin Assignments and Signal Definitions between J17 and U44 are
listed in
Table 1-19: USB Connector J17 Pin Assignments and Signal Definitions
USB Connector (J17)
Pin Name
1 VBUS USB_UART_VBUS
2 D_N USB_D_N
3 D_P USB_D_P
4 GND USB_UART_GND
Table 1-20
Table 1-20: FPGA to UART Connections
FPGA (U1)
Pin Function Direction
AR34 RTS
AT32 CTS
AU36 TX
AU33 RX
Refer to the Silicon Labs website for technical information on the CP2103GM and the VCP
drivers

HDMI Video Output

[Figure
The VC707 board provides a High-Definition Multimedia Interface (HDMI™) video
output using the Analog Devices ADV7511KSTZ-P HDMI transmitter (U48). The HDMI
output is provided on a Molex 500254-1927 HDMI type-A connector (P2). The ADV7511 is
wired to support 1080P 60 Hz YCbCr and RGB video modes through 36-bit input data
mapping.
The VC707 board supports the following HDMI device interfaces:
•
•
•
•
•
•
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
Table 1-19.
Net Name
+5V VBUS Powered
Bidirectional differential serial data (N-side)
Bidirectional differential serial data (P-side)
Signal ground
shows the USB connections between the FPGA and the UART.
IOSTANDARD
Output LVCMOS18
Input LVCMOS18
Output LVCMOS18
Input LVCMOS18
[Ref 19].
1-2, callout 18]
36 data lines
Independent VSYNC, HSYNC
Single-ended input CLK
Interrupt Out Pin to FPGA
2
I C
SPDIF
www.xilinx.com
Description
Schematic Net
Name
Pin
USB_CTS 22
USB_RTS 23
USB_RX 24
USB_TX 25
Feature Descriptions
CP2103GM (U44)
Pin Name
7 REGIN
8 VBUS
4 D –
3 D +
2 GND1
29 CNR_GND
CP2013 Device (U12)
Function Direction
CTS Input
RTS Output
RXD Input
TXD Output
