Temperature Controller
CompoWay/F Driver
1
System Configuration....................................................................................................... 3
2
Selection of External Device ............................................................................................ 7
3
Example of Communication Setting ................................................................................. 8
4
Setup Items .................................................................................................................... 18
5
Cable Diagram ............................................................................................................... 23
6
Supported device ........................................................................................................... 38
7
Device Code and Address Code.................................................................................... 45
8
Error Messages.............................................................................................................. 47
1
OMRON Corporation

Advertisement

loading

Summary of Contents for Omron THERMAC NEO Series

  • Page 1: Table Of Contents

    OMRON Corporation Temperature Controller CompoWay/F Driver System Configuration....................... 3 Selection of External Device .................... 7 Example of Communication Setting ................. 8 Setup Items ........................18 Cable Diagram ....................... 23 Supported device ......................38 Device Code and Address Code..................45 Error Messages......................47...
  • Page 2 Temperature Controller CompoWay/F Driver Introduction This manual describes how to connect the Display and the External Device (target Temperature Controller). In this manual, the connection procedure will be described by following the below sections: System Configuration "1 System Configuration" (page 3) This section shows the types of the External Device and SIO type.
  • Page 3: System Configuration

    Temperature Controller CompoWay/F Driver System Configuration The system configuration in the case when the External Device of OMRON Corporation and the Display are connected is shown. Communi- Cable Series Link I/F SIO Type cation Diagram Settings Cable Setting E5EN- -FLK...
  • Page 4 Temperature Controller CompoWay/F Driver IPC COM Port When connecting IPC with an External Device, the COM port used depends on the series and SIO type. Please refer to the IPC manual for details. Usable port Usable Port Series RS-232C RS-422/485(4 wire) RS-422/485(2 wire) COM1 , COM2,...
  • Page 5 Temperature Controller CompoWay/F Driver When setting up communication between an External Device and the RS-232C/422/485 interface module, use the IPC (RS-232C) or PS5000 (RS-422/485) cable diagrams. However, when using PFXZPBMPR42P2 in a RS-422/485 (4-wire) configuration with no flow control, connect 7.RTS+ and 8.CTS+, and connect 6.RTS- and 9.CTS-.
  • Page 6 Temperature Controller CompoWay/F Driver RS-422/485 (4 wire) DIP Switch Setting Description Reserved (always OFF) SIO type: RS-422/485 Output mode of SD (TXD) data: Always output Terminal resistance (220Ω) insertion to SD (TXD): None Terminal resistance (220Ω) insertion to RD (RXD): None Short-circuit of SDA (TXA) and RDA (RXA): Not available Short-circuit of SDB (TXB) and RDB (RXB): Not available RS (RTS) Auto control mode: Disabled...
  • Page 7: Selection Of External Device

    Enter an integer from 1 to 4 to define the number of Devices/PLCs to connect to the display. PLCs Manufacturer Select the manufacturer of the External Device to connect. Select "OMRON Corporation". Select the External Device model (series) and the connection method. Select "Temp. Controller CompoWay/F".
  • Page 8: Example Of Communication Setting

    Temperature Controller CompoWay/F Driver Example of Communication Setting Examples of communication settings of the Display and the External Device, recommended by Digital Electronics Corp., are shown. Setting Example 1 Setting of GP-Pro EX Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. GP-Pro EX Device/PLC Connection Manual...
  • Page 9 Temperature Controller CompoWay/F Driver Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
  • Page 10 Temperature Controller CompoWay/F Driver Setting Example 2 Setting of GP-Pro EX Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. GP-Pro EX Device/PLC Connection Manual...
  • Page 11 Temperature Controller CompoWay/F Driver Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
  • Page 12 Temperature Controller CompoWay/F Driver Setting Example 3 Setting of GP-Pro EX Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. GP-Pro EX Device/PLC Connection Manual...
  • Page 13 Temperature Controller CompoWay/F Driver Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
  • Page 14 Temperature Controller CompoWay/F Driver Setting Example 4 Setting of GP-Pro EX Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. GP-Pro EX Device/PLC Connection Manual...
  • Page 15 Temperature Controller CompoWay/F Driver Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
  • Page 16 Temperature Controller CompoWay/F Driver Setting Example 5 Setting of GP-Pro EX Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. GP-Pro EX Device/PLC Connection Manual...
  • Page 17 Temperature Controller CompoWay/F Driver Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
  • Page 18: Setup Items

    Temperature Controller CompoWay/F Driver Setup Items Set communication settings of the Display with GP-Pro Ex or in offline mode of the Display. The setting of each parameter must be identical to that of External Device. "3 Example of Communication Setting" (page 8) Setup Items in GP-Pro EX Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
  • Page 19 Temperature Controller CompoWay/F Driver Setup Items Setup Description Use an integer from 1 to 127 to enter the time (s) for which the Display waits for the Timeout response from the External Device. In case of no response from the External Device, use an integer from 0 to 255 to enter how Retry many times the Display retransmits the command.
  • Page 20 Temperature Controller CompoWay/F Driver Settings in Offline Mode • Refer to the Maintenance/Troubleshooting guide for information on how to enter offline mode or about the operation. Maintenance/Troubleshooting Guide "Offline Mode" • The number of the setup items to be displayed for 1 page in the offline mode depends on the Display in use.
  • Page 21 Temperature Controller CompoWay/F Driver Setup Items Setup Description Use an integer from 1 to 127 to enter the time (s) for which the Display waits for the Timeout response from the External Device. In case of no response from the External Device, use an integer from 0 to 255 to enter how Retry many times the Display retransmits the command.
  • Page 22 Temperature Controller CompoWay/F Driver Option To display the setting screen, touch [Device/PLC Settings] from [Peripheral Settings]. Touch the External Device you want to set from the displayed list, and touch [Option]. Setup Items Setup Description Switches RI/VCC of the 9th pin. RI/VCC It is necessary to change RI/5V by changeover switch of IPC when connect with IPC.
  • Page 23: Cable Diagram

    Temperature Controller CompoWay/F Driver Cable Diagram The cable diagram shown below may be different from the cable diagram recommended by OMRON Corporation. Please be assured there is no operational problem in applying the cable diagram shown in this manual. •...
  • Page 24 Temperature Controller CompoWay/F Driver Cable Diagram 1 Display Cable Remarks (Connection Port) GP3000 (COM1) GP4000 (COM1) SP5000 (COM1/2) SP-5B00 (COM1) ST3000 (COM1) User-created cable Cable length: 15m or less ST6000 (COM1) LT3000 (COM1) PC/AT GP-4105 (COM1) GP-4115T (COM1) User-created cable Cable length: 15m or less GP-4115T3 (COM1) LT-4*01TM (COM1)
  • Page 25 Temperature Controller CompoWay/F Driver Display side External Device side Terminal block Shield Terminal block Signal name Signal name RD(RXD) Display SD(TXD) ER(DTR) DR(DSR) RS(RTS) CS(CTS) External Device side Terminal block Signal name Display Number Name Notes RJ45 RS-232C Cable (5m) by Pro-face PFXZLMCBRJR21 GP-Pro EX Device/PLC Connection Manual...
  • Page 26 Temperature Controller CompoWay/F Driver Cable Diagram 2 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face GP3000 (COM1) CA3-ADPCOM-01 AGP-3302B (COM2) GP-4*01TM (COM1) Terminal block conversion adapter by Pro-face Cable length: GP-Rear Module CA3-ADPTRM-01 500m or less (COM1) ST3000 (COM2) User-created cable...
  • Page 27 Temperature Controller CompoWay/F Driver All GP3000 models except GP-3200 series and AGP-3302B Only the COM port which can communicate by RS-422/485 (2 wire) can be used. (Except PE-4000B, PS5000) IPC COM Port (page 4) Except GP-4203T All GP4000 models except GP-4100 series, GP-4*01TM, GP-Rear Module, GP-4201T and GP-4*03T Except SP-5B00 Except ST-6200 When using a Terminal Block Conversion Adapter (CA3-ADPTRM-01) instead of the RS-422 Terminal Block...
  • Page 28 Temperature Controller CompoWay/F Driver • 1:1 Connection Display side Shield D-Sub 9 Pin (socket) Termination resistance Signal name External Device side 120Ω (1/2W) Terminal block Termination resistance Signal name 120Ω (1/2W) Display B(+) A(-) Shell • 1:n Connection Display side Shield D-Sub 9 Pin (socket) Termination...
  • Page 29 Temperature Controller CompoWay/F Driver • 1:1 Connection Shield Termination resistance Signal name External Device side 120Ω (1/2W) Terminal block Termination resistance Display Signal name CA4-ADPONL-01 120Ω (1/2W) B(+) A(-) CA3-ADPTRM-01 User-created cable • 1:n Connection Shield Termination resistance Signal name External Device side External Device side 120Ω...
  • Page 30 Temperature Controller CompoWay/F Driver • 1:1 Connection D-Sub 9 Pin (plug) Shield Signal name Termination resistance TERMRX External Device side 120Ω (1/2W) Terminal block Termination Display resistance Signal name CA4-ADPONL-01 120Ω (1/2W) B(+) A(-) TERMTX Shell User-created cable • 1:n Connection D-Sub 9 pin (plug) Shield Termination...
  • Page 31 Temperature Controller CompoWay/F Driver • 1:1 Connection External Device side Shield Terminal block Termination Termination resistance resistance Signal name Signal name 120Ω (1/2W) 120Ω (1/2W) B(+) Display A(-) CA3-ADPCOM-01 CA3-ADPTRM-01 User-created cable • 1: n connection External Device side External Device side Terminal block Terminal block Shield...
  • Page 32 Temperature Controller CompoWay/F Driver • 1:1 Connection Display side External Device side D-Sub 9 Pin (socket) Shield Terminal block Termination Termination resistance resistance Signal name Signal name 120Ω (1/2W) 120Ω (1/2W) DATA+ B(+) DATA- A(-) Display GND (SG) Shell • 1:n Connection Display side External Device side...
  • Page 33 Temperature Controller CompoWay/F Driver • 1:1 Connection Display side Terminal block Shield Signal name Termination External Device side resistance*1 Terminal block Termination resistance Signal name 120Ω Display B(+) A(-) • 1:n Connection Display side Terminal block Shield Termination Signal name External Device side External Device side resistance*1...
  • Page 34 Temperature Controller CompoWay/F Driver • 1:1 Connection External Device side Display side Shield Terminal block plug D-sub 9 pin ( Termination Termination resistance resistance Signal name Signal name 120Ω (1/2W) 120Ω (1/2W) B(+) LINE(+) A(-) LINE(-) Display GND(SG) RS(RTS) Shell •...
  • Page 35 Temperature Controller CompoWay/F Driver • 1:1 Connection Shield Termination resistance Signal name External Device side 120Ω (1/2W) Terminal block Termination resistance Display Signal name 120Ω (1/2W) B(+) A(-) PFXZCBADTM1 User-created cable • 1: n connection Shield Termination resistance Signal name External Device side External Device side 120Ω...
  • Page 36 Temperature Controller CompoWay/F Driver • 1:1 Connection External Device side Terminal block Termination resistance Signal name Display 120Ω (1/2W) B(+) A(-) • 1:n Connection Termination External Device side External Device side resistance Terminal block Terminal block Shield Termination 220Ω (1/4W) resistance Signal name Signal name...
  • Page 37 Temperature Controller CompoWay/F Driver • 1:1 Connection Display side External Device side D-Sub 9 Pin (socket) Shield Terminal block Termination Termination resistance resistance Signal name Signal name 120Ω (1/2W) 120Ω (1/2W) DATA+ B(+) DATA- A(-) Display Shell • 1:n Connection Display side External Device side External Device side...
  • Page 38: Supported Device

    Available variable area range varies depending on the using Temperature Controller. Refer to the manual of OMRON Temperature Controller for setting. When you write the bit address, the Display reads the word address corresponding to that of the External Device first.
  • Page 39 Temperature Controller CompoWay/F Driver Command Related information Command comment Device address code Soft reset A0006 Setting area 1 transfer A0007 Protect level transfer A0008 00: Auto mode Auto/Manual A0009 01: Manual mode 00: Default value Initialize settings A000B 01: Value for default value setting service 00: Reset Program start A0011...
  • Page 40 Temperature Controller CompoWay/F Driver THERMAC R (E5AR/E5ER) This address can be specified as system data area. Device Bit Address Word Address 32bit Remarks C00000.00-C00002.31 C00000-C00002 C00004.00-C00005.31 C00004-C00005 C00100.00-C00102.31 C00100-C00102 C00104.00-C00105.31 C00104-C00105 *2*3 Double Word Device C00200.00-C00202.31 C00200-C00202 C00204.00-C00205.31 C00204-C00205 C00300.00-C00302.31 C00300-C00302 C00304.00-C00305.31 C00304-C00305...
  • Page 41 Available variable area range varies depending on the using Temperature Controller. Refer to the manual of OMRON Temperature Controller for setting. When you write the bit address, the Display reads the word address corresponding to that of the External Device first.
  • Page 42 Temperature Controller CompoWay/F Driver Related information Command Higher Command comment Device address code Lower byte byte 0 to 3, F 0: Run Run/Stop A0001 1: Stop 0 to 3, F 0 to 7: Bank 0 to 7 Bank switch A0002 0: Currently selected PIDset 0 to 3, F AT execute...
  • Page 43 Available variable area range varies depending on the using Temperature Controller. Refer to the manual of OMRON Temperature Controller for setting. When you write the bit address, the Display reads the word address corresponding to that of the External Device first.
  • Page 44 Temperature Controller CompoWay/F Driver Command Related information Command comment Device address code “00”: Cancel CH1 AT “01”: Execute CH1 AT “10”: Cancel CH2 AT ATexecute/cancel A0003 “11”: Execute CH2 AT “F0”: Cancel CH1, CH2 AT “F1”: ExeculteCH1, CH2 AT “00” or “10”: Backup Write mode A0004 “01”...
  • Page 45: Device Code And Address Code

    Temperature Controller CompoWay/F Driver Device Code and Address Code Use device code and address code when you select "Device & Address" for the address type in data displays. THERMAC NEO (E5AN/E5EN/E5CN/E5GN) Device Code Device Device Name Address Code (HEX) 0080 Word Address Variable Areas 0081...
  • Page 46 Temperature Controller CompoWay/F Driver In-Panel NEO Device Code Device Device Name Address Code (HEX) 0080 Word Address 0081 Word Address Variable Areas 0082 Word Address 0084 Word Address 0086 Word Address Operation command 0000 Word Address GP-Pro EX Device/PLC Connection Manual...
  • Page 47: Error Messages

    Temperature Controller CompoWay/F Driver Error Messages Error messages are displayed on the screen of Display as follows: "No. : Device Name: Error Message(Error Occurrence Area)". Each description is shown below. Item Description Error No. Name of External Device where error occurs. Name of External Device is a title of Device Name External Device set with GP-Pro EX.((Initial value[PLC1]) Error Message...
  • Page 48 Temperature Controller CompoWay/F Driver GP-Pro EX Device/PLC Connection Manual...
