Blueant X5 Quick Start Manual

Quick Start Guide

Inside the package
One X5 Stereo Bluetooth Headset
One Voice Enabled Audio Streamer
One Detachable Microphone
One set of Foam Speaker Covers
One 3.5mm Audio lead
One 3.5mm Y-Cable Audio Lead
Two USB Cables
One AC Charger
One X5 User Guide
One X5 Quick Start Guide.
Function / Button matrix
X5 Functions
Turn Headset ON
Pairing Headset
Pick Up
Hang Up (profile dependent)
Last Call Redial / Voice Dialing
(depending on phone)
Volume Up
Volume Down
Remote Control Functions
Play
Pause
Stop
Next Song
Previous Song
Streamer Functions
Turn Audio Streamer ON
Turn Audio Streamer OFF
Pairing Audio Streamer
Reconnect with Headset
Switch from Stereo to Voice
Switch from Voice to Stereo
Pairing the X5 to the Audio Streamer
1. Mount the batteries. Insert the small end of a USB cable into the USB port on the X5 and plug the
large end into a computer USB port. Do the same for the Audio Streamer (or use the AC
charger). Charge the X5 and Audio Streamer for 2 hours before use.
2. On the Headset, press & hold ON/OFF and Vol Up buttons for about 5 seconds. Led flashes blue to red.
3. On the Audio Streamer, press & hold the ON/OFF button for about 5 seconds. Led will flash blue to red.
4. At this point the two devices will automatically pair and connect with each other.
5. To connect with your computer, insert the single black plug of the Y-Cable into the jack input of
the Audio Streamer. On the Y end, insert the red plug into the microphone input of your computer
and insert the black plug into the Stereo output of your computer.
6. At this stage, the connection between Headset and Audio Streamer is in stereo mode. Open an
audio program on your computer and play a song. To increase volume, Short Click the Vol Up
button. To decrease, Short Click the Vol Down button. Also you may need to adjust volume levels
of the computer Soundcard.
7. To use with a VOIP program, e.g. Skype, MSN Messenger...etc, insert the detachable USB
Microphone into the USB port of the Headset. Next, switch from Stereo to Voice mode by clicking
the ON/OFF button on the X5 once.
8. Open the program and use its interface to control the call. To switch back to Stereo music mode
after ending a Voice call, click MFB button of the X5 Headset once.
9. If you have been listening to music via stereo mode, then on an incoming VOIP call, you will hear
the bell tone intermingled with the sound of music. To switch to Voice mode, first stop or pause the
music on the computer and then click ON/OFF button of the Headset once to enter into Voice mode.
10. When using different audio sources, e.g. Mp3 player, iPod, TV...etc, plug one end of the stereo
3.5mm cable into the Audio Streamer, and the other end into your audio device. Music plays
through the Headset.
Button Time Conditions / Status
On/OFF 3 sec
ON/OFF & Vol Up 3 sec
MFB Click
MFB or ON/OFF Click
MFB 3 sec
Vol Up Click
Vol Down Click
(AVRCP compatible devices only)
MFB Click While Stopped or Paused
MFB Click
ON/OFF Click
Vol Up 1 sec
Vol Down 1 sec
Button Time Conditions / Status
ON/OFF 3 sec
ON/OFF 3 sec
ON/OFF 5 sec
ON/OFF 3 sec
ON/OFF Click
MFB Click
Vol Up
Headset Off
LED
Headset Off
To Telephone
MFB
During a call
Standby
During Communication
During Communication
While Playing
While Playing
While Playing
While Playing
Streamer Off
Streamer On
Streamer Off
Streamer Off
While Playing
While in voice mode
Quick Start Guide
ON/OFF
Vol Down
USB Port
Battery Pack
Battery Ejector Button
Audio Connector
(3.5mm Stereo Jack)
LED
Neckband
ON/OFF
