Blodgett SC-10DS Specifications

SC-DS
Convection Steamer on an
Cabinet Base Operating on Direct Steam
SC-6DS shown
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
36" (914 mm) wide cabinet base for SC-6DS and
SC-10DS
Stainless steel frame
Stainless steel rear panel
Spray and rinse assembly
Ball float trap
Load compensating timer
Correctional package
One year extended warranty
CAPACITY
Model SB-6DS is comprised of two 3 pan compartments
Model SB-10DS is comprised of two 5 pan compartments
Model SB-16DS is comprised of two 8 pan compartments
Project
Item No.
Quantity
STEAMER EXTERIOR CONSTRUCTION
CABINET BASE CONSTRUCTION
OPERATION
STANDARD FEATURES
*
www.blodgett.com
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
Model SC-6DS (6 pan convection steamer operating on direct steam)
Model SC-10DS (10 pan convection steamer operating on direct steam)
Model SC-16DS (16 pan convection steamer operating on direct steam)
304 #4 finish stainless steel
Welded stainless steel door with removable inner stainless steel liner
Full perimeter door gasket
Positive lock and seam mechanism with spring release on door
Stainless steel control housing
One piece welded 316 stainless steel cooking chamber
Coved corners
Stainless steel pan supports
Stainless steel drip trough integrally connected to drain
24" (610 mm) wide cabinet base for SC-6DS and SC-10DS
36" (914 mm) wide cabinet base for SC-16DS
Full perimeter painted angle iron frame
Reinforced steamer mountings
Stainless steel exterior
Hinged door(s) with magnetic latch
6" (152 mm) stainless steel legs with adjustable bullet feet on front and
adjustable flanged feet on rear for securing to floor
Pressureless steam operation
Separate controls for each compartment
Controls accessible through removable side panel
On/off power switch with indicator light
Ready indicator light
Cooking indicator light
60 minute electric timer with audible alarm to signal end of cook cycle
Steam flow to the cooking chamber is cut off when the door is opened
during the cooking cycle and reactivated when the door is closed
115 VAC, 1 phase, 60 Hz for controls
Electromechanical controls
Steam condensing drain
One year parts and labor steamer warranty*
Five year limited steamer door warranty*
For all international markets, contact your local distributor.
BLODGETT
