Blodgett 951 Base Specifications

MODEL 951
Deck Oven
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Legs:
7" (178mm) stainless steel legs
27-1/2" (699mm) stainless steel legs
Flexible gas hose with quick disconnect and
restraining device:
36" (914 mm)
48" (1219mm)
Casters
Stainless steel crown angle trim
Vent kit
Double or triple connector for stacking
Ultra Rokite shelves, 1-1/2" (38.1mm) thick
(pizza type shelf)
Steam jets
OPTIONS AND ACCESSORIES
(AT NO ADDITIONAL CHARGE)
FDTH 300° to 650° temperature thermostat
Centigrade dial, 100°C to 300°C
Project
Item No.
Quantity
Ovens consist of basic sections and are a complete and separate unit
capable of operating alone or in combination.
All data is shown per oven section, unless otherwise indicated.
Refer to operator manual specification chart for listed model name.
EXTERIOR CONSTRUCTION
INTERIOR CONSTRUCTION
OPERATION

STANDARD FEATURES

* For all international markets, contact your local distributor.
BLODGETT OVEN COMPANY
www.blodgett.com
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
Full angle iron frame
Stainless steel front, top, sides and back
Counterbalanced doors with concealed hinges
Heavy chrome plated tubular steel door handle
27-1/2" (699mm) black powder coated legs (for single units)
7" (178mm) black powder coated legs (for double units)
Burner doors open easily for ignition, cleaning or adjustment, without
removal of any fastenings
Vitreous fiber insulation at top, back, sides, bottom and doors
42" x 32" x 12" (1067mm x 813mm x 305mm)
oven compartment interior
Aluminized steel baking compartment liner
Aluminized steel combustion chamber
Steel deck supported by an angle iron frame
12 gauge (3.02mm) press-formed, reinforced and flanged aluminized steel
deck
Free-floating, easily removable duplex-tube burner
Removable fixed orifices on main and pilot burner
Main gas valve, temperature control valve and safety pilot valve fully within
section body and are accessible through a covered and ventilated compart-
ment in front.
Air mixers with adjustable air shutters and locking device
Liquid pressure thermostat with temperature control range of
200°F (93°C) to 500°F (288°C)
Steel oven deck
Fahrenheit dial 200°F to 500°F
Two year oven parts and one year labor warranty*
Five year limited oven door warranty*
