BINA TONE " e820 System "
User Guide - Back Page
Aus Ver 1, Jan, 05
U
G
SER
UIDE
e820 Syste
Digital Cordless Telephone
with Caller Display
and Answering
Machine
THIS EQUIPMENT IS NOT DE
MAKING EMERGENCY TELE
WHEN THE POWER FAILS. A
ARRANGEMENTS SHOULD
ACCESS TO DIAL EMERGEN
Before operating th
please read these instructi
BINA TONE " e820 System "
User Guide - Front Page
1)White background and blac
2)Material: 100lb Double face
3) Size: 105mm(w) x 148mm

Advertisement

Table of Contents
loading

Related Manuals for Binatone e820

Summary of Contents for Binatone e820

  • Page 1 ACCESS TO DIAL EMERGEN Before operating th Aus Ver 1, Jan, 05 please read these instructi BINA TONE “ e820 System ” BINA TONE “ e820 System ” User Guide - Front Page User Guide - Back Page 1)White background and blac...
  • Page 2 If you need help … The Binatone service Line is available from 9.00 am to 5.00 pm, Monday to Friday, on 1300 768 112 Calls are charged at Local Call rate.
  • Page 3 Before you can use the handset to make calls you w button to switch Press the charge the batteries, as described on pages 6 and 7 the handset on Please read the notes on pages 3 and 4 before you E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:45:41...
  • Page 4 When this shows ‘nearly empty’ ( ), put the handset onto Battery the base unit or charger pod as soon as possible, to charge the charge batteries. While the batteries are being charged, this symbol level blinks. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:11...

  • Page 5: Table Of Contents

    Call waiting function To de-register a handset 23 To select a base unit 23 Memory dialling To register to a different brand of To store a number base unit 24 To make a memory call 13 E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:11...
  • Page 6 Keys to press during remote operation 34 Switching on remotely 34 Customising your handset General points 35 Auto-answer 35 Ringer volume and melody 36 Key tone 36 Direct Call 37 To clear all memories 38 E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:11...

  • Page 7: Read These Notes First

    Other solid structures, like walls, may reduce the signal strength. Mains power IMPORTANT — The e820 base unit and charger pod connection must be used with the mains adapter supplied with the unit. Using any other adapter will result in non- compliance with EN60950, and will invalidate any approval given to this apparatus.

  • Page 8: Battery Safety

    4 — otherwise, one or more of them may not ring and/or answer calls correctly. The e820 has a REN of 1, and most other telephones have a REN of 1 unless marked otherwise.

  • Page 9: Installation And Set-Up

    If you have one or more charger pods … Plug the mains adapter into a 230 V AC, 50 Hz mains socket, with the switch on the socket set to OFF See the note on page 4 Switch on at the mains socket(s) E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:13...
  • Page 10 Make sure the mains socket is switched on if you want to use the phone — it will not work NOTE: the charger pod does not have without electrical power a connection to the telephone line. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:16...

  • Page 11: Before You Start

    (base unit only); then pull it out by the unplugged cables. NEVER use your e820 outdoors during a thunderstorm — unplug the base unit from the telephone line and the mains socket when there are storms in your area.

  • Page 12: Switching On And Off

    When you don’t need to use the handset (for example, overnight or when you go out), replace it on the base unit or charger pod, to keep the batteries charged E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:16...

  • Page 13: Making And Answering Calls

    ˆ Press the button There are three volume levels, shown by bars on the right-hand side of the display. After you end your call, the earpiece volume will stay at the level you have set. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:16...

  • Page 14: Last Number Redial (Lnr)

    Numbers you’ve dialled more than once will be stored only once. Each time you dial a number, it clears the oldest one from the LNR memories; so you don’t need to clear numbers manually unless you want to. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:16...

  • Page 15: Using The Base Unit's Speakerphone

    Please ensure your call waiting function is on, otherwise please contact your service provider for availability. Call waiting To answer call waiting, simply pree R then 2 To return to your first caller, press R then 1 E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:16...

  • Page 16: Memory Dialling

    Press the PHONE/OK button Chain dialling You can store part of a number (for example, the long- distance dialling code) in memory, and use any com- bination of memory and manual dialling to make a call. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:17...
  • Page 17 Press and hold the HANG UP/C button until you hear a tone and the number disappears from the display; OR press and hold the HANG UP/C button for 5 seconds to clear all 20 memories E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:17...

  • Page 18: To Use The Notebook

    The display shows a free memory location. ‡ ˆ You can press the button to select a different free location if you wish (only free locations are displayed). Press the PHONE/OK button to store the number E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:17...

  • Page 19: Caller Display

    The e820 will store the numbers of the last 10 callers (whether or not you answered the call) so you can call them back later. When all 10 Caller Display memories are full, the next incoming number will overwrite the oldest one.

  • Page 20: To Return A Call

    The display shows the first free memory ‡ ˆ location. You can press the button to select a different free location if you wish (only free locations are displayed). Press the PHONE/OK button to store the number E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:17...

  • Page 21: Using An Multi-Hanndset System

    Composite Default screen Using a multi-handset system If you have an e820 multi-handset system, you already have up to six handsets registered to your base unit. You can register additional handsets — altogether, up to six handsets per base unit. With two or more...

  • Page 22: To Answer An Intercom Call

    You can press the HANG UP/C to transfer the outside call before the other handset answers your intercom call. If the user hasn’t answered after 30 seconds, the outside call will come back to you and your handset will ring. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:17...

  • Page 23: To Shuttle Between Two Calls

    Press the # (HASH) button to bring in the outside call (If the other user does not answer after step 1, you can get back to the outside call by pressing Ø /INT button for one second.) E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:17...

  • Page 24: New Call Tone

    Press the HANDSET LOCATOR button on the base unit u Handsets ring for up to 30 seconds. To stop the ringing before this time: Press the HANDSET LOCATOR button again OR press any button on any handset E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:17...

  • Page 25: Handset Registration

    The handset beeps to confirm registration. To register Follow the steps above, but key in a new base unit your handset number (2, 3 or 4) sfter 16 at step 2. to a new base unit E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:17...

  • Page 26: To De-Register A Handset

    Base units are numbered 1 to 4. If you select 0, your handset will automatically select the base unit that gives the strongest connection. Press the PHONE/OK button to confirm E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:18...

  • Page 27: To Register To A Different Brand Of Base Unit

    Your e820 can be registered to any GAP-compatible a different base unit; or your can register other GAP-compatible brand of base handsets to your e820 base unit. But we do not unit guarantee that all features or display messages will be available using other manufacturers’ equipment.

  • Page 28: Answering Machine Buttons And Lights

    Press to stop recording or playback. volume during playback. Underneath — RING button Press to set the number of rings before the machine answers a call. RING CODE button CODE Press to set your remote security code. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:20...

  • Page 29: Setting Up The Answering Machine

    The machine tells you the day and time you have set. If you want to change the setting, just repeat steps 1 to 7 To check the To check the day and time any time: clock Briefly press the CLOCK button E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:20...

  • Page 30: Outgoing Messages (Ogms)

    Setting up the answering machine Outgoing An OGM is what callers hear when the machine messages answers. The e820 has two OGMs; it is supplied with (OGMs) pre-recorded messages, but you can record your own versions: OGM1 — this invites callers to leave a message. The default is “Sorry —...

  • Page 31: To Record Ogm2

    Press the RING button again to confirm the number of rings you have set You can check the number of rings at any time by briefly pressing the RING button. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:20...

  • Page 32: Using The Answering Machine

    ‘beep’ Record your memo, speaking clearly from about 15 cm (6 inches) from the base unit’s microphone As soon as you have finished speaking, press the ON–OFF/STOP button to stop recording E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:20...

  • Page 33: To Play Back Your Messages

    Repeat/Rewind To repeat the current message, press the REWIND (OGM) button briefly To replay the previous message, press the REWIND button twice Skip/Fast Forward To skip to the next message, press the FORWARD (MEMO) button E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:20...

  • Page 34: To Intercept A Call

    If you hear the answering machine recording a call message, you can intercept the call and speak to the caller, by EITHER: pressing the PHONE button on the e820 handset; OR pressing the SPEAKERPHONE button on the e820 base unit; OR lifting the handset of any other phone connected to the same line.

  • Page 35: To Delete Messages

    If necessary, briefly press the ON–OFF/STOP button to switch to the OGM you want to delete Briefly press the OGM (REWIND) button to play the message While the message is playing, press the DELETE button E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:21...

  • Page 36: Remote Operation

    After about 2½ minutes playback, the machine will pause and you’ll hear a tone (short ‘beeps’). To continue playback, press any key within 10 seconds. If you don’t press a key, your call will be cut off. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:21...

  • Page 37: Keys To Press During Remote

    10 rings. To switch it on remotely: When you hear your outgoing message, press When you hear ‘Security code’ then a ‘beep’, key in your remote security code Press to switch on E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:21...

  • Page 38: Customising Your Handset

    Composite Default screen Customising your handset General points You can customise the settings of your e820 handset, using a menu which is shown on the handset’s display. Please note that: If you don’t press any button for about 25 seconds, the handset will time out and the display will return to standby mode.

  • Page 39: Ringer Volume And Melody

    ‘beep’ tone. You can turn these tones off if you prefer. Press the PROG button then 1 1 3 ‡ ˆ Use the buttons to set: 0 for key tone off 1 for key tone on Press the PHONE/OK button to confirm E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:21...

  • Page 40: Direct Call

    0 for Direct Call off 1 for Direct Call on Press the PHONE/OK button to confirm While Direct Call is turned on, the display shows the Direct Call number. You can answer calls as normal. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:21...

  • Page 41: To Clear All Memories

    Indirect Network off (see page 44) auto-answer select base unit automatic (best connection) Press the PROG button then 1 0 Press the PHONE/OK button to confirm E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:21...

  • Page 42: Customising Your Base Unit

    Default screen Customising your base unit General points You can customise the settings of your e820 base unit, using a menu which is shown on the handset’s display. Please note that: If you don’t press any button for about 25 seconds, the handset will time out and the display will return to standby mode.

  • Page 43: Ringer Volume And Melody

    You can bar certain types of call — no outside calls, or no international calls. When either kind of call barring is turned on, you may not be able to make a call, and you may see a ‘key’ symbol on the display. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:22...
  • Page 44 Press the PROG button then 2 2 2 Key in the handset number (1 to 6) ‡ ˆ Press 0 then use the button to set: 0 for call barring OFF 1 for call barring ON Press the PHONE/OK button to confirm E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:22...

  • Page 45: Date And Time

    020303 for 2 March 2003. Press the PHONE/OK button to confirm Key in the time as a four-digit number …for example, 0830 for 8:30 am, 1406 for 2:06 pm. Press the PHONE/OK button to confirm E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:22...

  • Page 46: To Clear All Caller Display Memories

    Caller Display memories empty Indirect Network codes none (see page 44) Press the PROG button then 2 0 Press the PHONE/OK button to confirm E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:22...

  • Page 47: Indirect Network

    To route calls over the alternative network, you need to key in the access code each time you make a call. Your e820 can do this automatically when you dial a long- distance or international number (beginning with 0), either manually or from memory.
  • Page 48 Note — for Indirect Network to work, you must dial the phone number (or select it from memory, LNR memory or Caller Display memory) before you press the PHONE/OK button for an outside line. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:22...

  • Page 49: Troubleshooting

    All manuals and user guides at all-guides.com Color profile: Generic CMYK printer profile Composite Default screen Troubleshooting The e820 must be serviced by trained engineers. NEVER attempt any repairs or adjustments yourself — you could make the problem worse and invalidate the Warranty. ALWAYS check...
  • Page 50 — not just for charging the batteries. Make sure you’re using the telephone line cable that was supplied with your e820. Other telephone line cables might not work. Check that the total REN value of all equipment connected to your telephone line is no more than 4 (see page 3).
  • Page 51 Check the Battery Level symbol on the display. If it is I’m on a call.” low, recharge the batteries. “When I try to If you’re using a e820 Twin system, or have extra make a call, I handsets registered to your base unit, check that hear Busy another handset isn’t already in use on a call.
  • Page 52 Dispose of used batteries safely — never burn them, they are low.” or put them where they could get punctured. DON’T use non-rechargeable batteries in your e820 — they may burst, causing damage. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:23...
  • Page 53 When making a call, you must dial the number (or select the number from memory, LNR memory or Caller Display memory) before you press the PHONE/OK button for an outside line. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:23...
  • Page 54 Redial/CDS/P button for a pause between the access code and the number. You can also set up your e820 so that it automatically inserts a 2-second pause after you dial the outside line access code, as follows:...

  • Page 55: Warranty

    Troubleshooting If the fault persists … Disconnect all other instruments connected to the same line as the e820 and see whether you can make a call. Disconnect the base unit from the telephone line and plug a different phone into the master telephone socket.
  • Page 56 All manuals and user guides at all-guides.com Color profile: Generic CMYK printer profile Composite Default screen E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:23...

  • Page 57: Technical Details

    Pause length (using the Redial/CDS button): 3 seconds. Signalling type: DTMF (dual-tone multifrequency), also called tone dialling. Network connection This equipment is intended to be used in Australia only. Operation on other countries’ PSTN termination points cannot be guaranteed. E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:23...

  • Page 58: Index

    41 21–22 types of call, 42 Caller Display, 16–17 Indirect Network, 44–45 checking records, 16 ‘local’ dialling codes, 45 deleting records, 17, 43 network access code, 44 returning calls, 17 turning on and off, 45 E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:23...
  • Page 59 28 volume control ‘Out of range’ warning, 8 base unit speakerphone, outgoing messages, 27–28, handset’s earpiece, 10 paging handsets, 21 pause, 51, 54 PBX compatibility, 54 playback of messages, 30 problems, 46–52 E:\Binatone2004\e820\e820_UK_03.vp 15 November 2004 11:48:23...
