- Page 1 Operator Manual Crest Healthcare Console Junior (CJ) Series Ultrasonic Washer Sales and Service: Crest Ultrasonics Corp. 18 Graphics Dr, Ewing, NJ 08628, USA. Phone: 609-883-4000. www.crest-ultrasonics.com...
- Page 2 System are fully trained in equipment operation and safe use. Personnel working with toxic chemicals and vapors (if applicable) have comprehensive instructions in the washing process, relevant health hazards and methods to detect the escape of toxic materials. Crest Healthcare Console Junior R:1 Introduction...
- Page 3 Only trained personnel should attempt to perform maintenance on the Ultrasonic Cleaning System to avoid personal injury, improper equipment performance, invalidation of the equipment warranty or other costly damage. Crest Healthcare Console Junior R:1 Operator Manual Introduction...
-
Page 4: Table Of Contents
Before Performing Routine Maintenance ......................4-1 Preventive Maintenance Schedule........................4-2 Cleaning Procedures ............................4-3 4.3.1 General ..............................4-3 4.3.2 Monthly Cleaning Procedure ........................4-4 Replacement Parts .............................. 4-5 Troubleshooting ............................5-1 Crest Healthcare Console Junior R:1 Table of Contents Operator Manual... - Page 5 Figure 3-1. Sonic Cleaner Control Panel (Typical) ......................3-2 Figure 3-2. Generator Power Switch ..........................3-4 Figure 3-3. Cycle Start foot pedal ............................3-4 Figure 3-4. Port Flushing kit connections ......................... 3-9 Figure 4-1. Generator Module ............................4-4 Crest Healthcare Console Junior R:1 Table of Contents Operator Manual...
- Page 6 Preventive Maintenance Guide ........................4-2 Table 4-2 Recommended Cleaning Products* ......................4-3 Table 4-3 Replacement Parts ............................4-5 Table 5-1 Troubleshooting Chart - Cleaning Phase of Wash Cycle ............... 5-2 Crest Healthcare Console Junior R:1 Table of Contents Operator Manual...
-
Page 7: Safety Precautions
To avoid slippery floor conditions, immediately wipe up any spilled liquid or condensation. If spills or drippage are detergents or other chemicals, follow safety precautions and handling procedures set forth on detergent or chemical label and/or Material Safety Data Sheet (MSDS). Crest Healthcare Console Junior R:1 Safety Precautions Operating Manual... - Page 8 Failure to remove shipping bracket and hardware from lid counterweights will result in lid and/or unit cabinet damage. REMEMBER – POSSIBLE TIME DELAY: Insufficient clearance space will make repairs more difficult and time-consuming. Refer to the equipment drawing for minimum clearance for service/maintenance access requirements. Crest Healthcare Console Junior R:1 Operating Manual Safety Precautions...
- Page 9 - OR - Attention, Consult Manual for Further Instructions Amperage Rating of the Unit Voltage Rating of Unit Alternating Current Frequency Rating of Unit Power Rating Serial Number of the Unit Crest Healthcare Console Junior R:1 Safety Precautions Operating Manual...
-
Page 10: Important User Information
❑ Ensure all switches are properly installed, adjusted and connected. ❑ Ensure facility power meets requirements listed on nameplate located on front of unit (see S 2.3.2, ECTION LECTRICAL Operator Manual Crest Healthcare Console Junior R:1 Important User Information... -
Page 11: General Description
(utilizing ultrasonic cavitation passing through a detergent-balanced wash solution as described in the previous paragraphs), thoroughly rinse surgical instruments prior to disinfection and sterilization. Crest Healthcare Console Junior R:1 Operator Manual Important User Information... -
Page 12: Technical Specifications
2.3.4 Weight • Sonic Cleaner - 15-gal: 452 lb (205 kg) 20-gal: 545 lb (247 kg) 2.3.5 Seismic Anchorage A Seismic Anchorage System is available for high-risk seismic zones. Crest Healthcare Console Junior R:1 Important User Information Operator Manual... -
Page 13: Environmental Conditions
(e.g ., strong alkaline detergents [pH>12], alcohol rinses and liquid germicides including hypocloric acid [bleach] in the processing of articles in the Ultrasonic Cleaning System Crest Healthcare Console Junior R:1 Operator Manual Important User Information... -
Page 14: Operating Instructions
• Never drop or rest parts directly on chamber bottom or on top of immersible transducers. • Never scratch chamber walls or transducers. This can increase cavitation erosion. Crest Healthcare Console Junior R:1 Operating Instructions Operator Manual... -
Page 15: Controls And Indicators
STOP: Use this pushbutton to immediately halt all Ultrasonic Cleaning System functions. When pressed, facility power is disconnected from system circuits. LID: Use this pushbutton to interrupt cycle and raise lid. Timer(s): Use digital timer to set Wash Cycle Crest Healthcare Console Junior R:1 Operator Manual Operating Instructions... -
Page 16: Other Controls
Generator Power Switch: Use rocker switch to turn generator ON. Generator is located inside Ultrasonic Cleaning System (see Figure 3-2). CYCLE START: Use this foot pedal (touch plate) to start Ultrasonics Cleaning System Wash Cycles (see Figure 3-3). Crest Healthcare Console Junior R:1 Operating Instructions Operator Manual... -
Page 17: Figure 3-2. Generator Power Switch
Generator Power Switch Figure 3-2. Generator Power Switch Sonic Cleaner Console Junior(CJ) Wash Cycle Start Foot Pedal Figure 3-3. CYCLE START Foot Pedals Crest Healthcare Console Junior R:1 Operator Manual Operating Instructions... -
Page 18: Operating Instructions
Properly dispose of empty detergent bottle. Position new detergent bottle and remove shipping cap. Install cap and detergent injector suction tube into detergent bottle. Adjust tube length and tighten cap. Crest Healthcare Console Junior R:1 Operating Instructions Operator Manual... - Page 19 NOTE: Solution in the CLEANING Chamber need not be changed after each cycle. Change solution when it becomes visually dirty, at end of workday or at least every 12 cycles (factory setting). Crest Healthcare Console Junior R:1 Operator Manual Operating Instructions...
-
Page 20: Wash Cycle
POSSIBLE EQUIPMENT DAMAGE: • Never drop or rest parts directly on chamber bottom or on top of immersible transducers. • Never scratch chamber walls or transducers. This can increase cavitation erosion. Crest Healthcare Console Junior R:1 Operating Instructions Operator Manual... -
Page 21: Draining Cleaning Chamber
Reverse Port Flush Tubing is available for open lumen end of instrument. This permits sonic, port flushing action to flow from instrument end of device. A variety of tubing sizes is provided. Crest Healthcare Console Junior R:1 Operator Manual Operating Instructions... - Page 22 Connect Fitting on underside of lid. Position instruments as follows: a. Position up to Ten instruments into Instrument Tray and connect Luer-Lock of Instrument Tubing to instrument luer- lock connecting port. Crest Healthcare Console Junior R:1 Operating Instructions Operator Manual...
- Page 23 LEANING ROCEDURES damage delicate components. Press MAIN POWER pushbutton ON. Press CYCLE START foot pedal to close lid(s). Once tray elevator lowers and top closes, press MAIN POWER pushbutton OFF. 3-10 Crest Healthcare Console Junior R:1 Operator Manual Operating Instructions...
-
Page 24: Routine Maintenance
Contact Crest regarding service options. • Regularly scheduled preventive maintenance, in addition to the faithful performance of routine maintenance described within this manual, is required for safe and reliable operation of this equipment. Crest Healthcare Console Junior R:1 Routine Maintenance Operator Manual... -
Page 25: Preventive Maintenance Schedule
Install any panel or cover removed during inspection. Every inspection Every inspection Inspect work area and unit to ensure removal of all materials used during inspection 2.8 Test unit operation. Every inspection Crest Healthcare Console Junior R:1 Operator Manual Routine Maintenance... -
Page 26: Cleaning Procedures
Do not use Stain Remover Cream (which is mildly acidic) to stainless-steel abrasive cleaners on painted surfaces. However, it contains a very fine abrasive and should surfaces. NOT be used on painted surfaces. Crest Healthcare Console Junior R:1 Routine Maintenance Operator Manual... -
Page 27: Monthly Cleaning Procedure
Carefully remove generator module. Using a fine brush or canned air, carefully remove any dust from the components. Ensure module properly mates with cabinet connector. Generator Module Figure 4-1. Generator Module Crest Healthcare Console Junior R:1 Operator Manual Routine Maintenance... -
Page 28: Replacement Parts
Fuse, 2 Amp ABC 1007058 Fuse, 5 Amp ABC 1007059 1007061 Fuse, 25 Amp ABC Lens, Amber 1013305 Lens, Clear 1013301 1013100 Light, Red Indicator Strainer, Wash Tank 3078016 Tray, Instrument 3017057 Crest Healthcare Console Junior R:1 Operator Manual Routine Maintenance... -
Page 29: Troubleshooting
• Lock building electrical supply disconnect switch and console master power Switch to OFF before checking or replacing any parts. Electrical shock can cause serious injury. Crest Healthcare Console Junior R:1 Troubleshooting Operator Manual... - Page 30 1. Faulty power cord connection – correct. pushbutton is pressed. 2. Chamber strainer plugged – clean. 3. “Y” strainer plugged – clean. 4. Call Crest Healthcare. * * Service charges may be incurred. Consult your warranty for details. Crest Healthcare Console Junior R:1 Operator Manual Troubleshooting...
