Telex Vega IP-1616 Brochure

Vega's Model IP-1616
The IP-1616 is a eight-line full-
featured desktop control console
designed with VoIP Technology for
use with conventional radio
systems. The IP-1616 is a self-
contained dual processor based
console that does not require CEB
or under the desk CPU equipment.
The IP-1616 can be easily con-
nected to any internal Ethernet
network by connecting a standard
10/100 baseT cable to the back of
the unit and assigning it an address,
thus allowing for an unlimited
number of IP-1616 consoles to have
full control and functionality over
the system.
To program the IP-1616 console
you simply connect to the Ethernet
port on the back of the console and
use your favorite Web Browser on
your computer.
1-800-752-7560
Unlike analog circuits any number
of consoles can be put in parallel
without causing loading issues.
The IP-1616 console has the
capability of controlling a cross-
patch between two or all eight of
its eight-lines. The dispatcher can
communicate with the cross-patch
group or operate on the other
unused channels.
Its four-line Liquid Crystal Display
provides channel alpha/numeric
indication and features a 12/24-
hour clock and audio-level display.
The IP-1616 comes with many
standard features such as F1-F16
function tones, Four Alert tones,
TX-ALL, RX-ALL, DTMF Key-
pad, Two Auxiliary buttons, RX
and TX Block, Parallel update,
8601 East Cornhusker Highway, Lincoln, NE 68507
E-mail: vega@telex.com
VoIP
Radio / Telephone
Crosspatch Control
•Police and Fire Departments
•Utility and Energy Companies
•Railroads and Airline Industries
•US Forestry and BLM Agencies
DTMF Select Call per line, Paging
(2-tone, DTMF and Manual entry),
Instant call recorder allows you to
retrieve the last 4 minutes of either
select or unselect TX and RX
audio, Group select and VoIP con-
nection. Summed recorder outputs
for selected and unselected audio.
The IP-1616 console is compatible
with Vega's other VoIP products
such as the C-6200, IP-223, and
C-Soft. Through these platforms
Motorola, M/A Com, Daniels,
Kenwood, and other tone or direct
connected radios can be remotely
controlled. The migration path cre-
ated with our VoIP products allows
users to make a gradual move to the
benefits of the VoIP world.
