ASSEMBLY AND OPERATING INSTRUCTIONS
SAVE THIS MANUAL FOR FUTURE REFERENCE
NOTICE TO INSTALLER:
LEAVE THESE INSTRUCTIONS
WITH THE GRILL OWNER FOR
FUTURE REFERENCE.
OWNER'S MANUAL
Gas Porcelain
Outdoor Grill
WARNING
HAZARDOUS EXPLOSION MAY
RESULT IF THESE WARNINGS AND
INSTRUCTIONS ARE IGNORED. READ
AND FOLLOW ALL WARNINGS AND
INSTRUCTIONS IN THIS MANUAL TO
AVOID PERSONAL INJURY, INCLUDING
DEATH OR PROPERTY DAMAGE.
Advertisement
Table of Contents
Related Manuals for Brinkmann ProSeries 2200
Summary of Contents for Brinkmann ProSeries 2200
- Page 1 OWNER’S MANUAL ASSEMBLY AND OPERATING INSTRUCTIONS SAVE THIS MANUAL FOR FUTURE REFERENCE NOTICE TO INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE GRILL OWNER FOR FUTURE REFERENCE. Gas Porcelain Outdoor Grill WARNING HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS AND INSTRUCTIONS ARE IGNORED. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS MANUAL TO AVOID PERSONAL INJURY, INCLUDING...
-
Page 3: For Your Safety
IMPORTANT SAFETY WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR GRILL. - Page 4 Never use natural gas in a unit designed for liquid propane gas. • Never use charcoal briquets or lighter fluid in a gas grill. • Leak test all connections before first use, even if grill was purchased fully assembled and after each tank refill.
-
Page 5: Installation Information
DO NOT connect to a cylinder that uses any other type of valve connection device. CYLINDER SPECIFICATIONS: When purchasing or exchanging a cylinder for your gas grill, it must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S. Department of Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339 Cylinders, Spheres and Tubes for Transportation of Dangerous Goods;... - Page 6 The cylinder must also be equipped with: • A shut-off valve terminating in a Type 1 gas cylinder valve outlet. • A Type 1 valve that prevents gas flow until a positive seal is obtained. • An arrangement for vapor withdrawal. •...
-
Page 7: Filling The Lp Gas Cylinder
240°F to 300°F (115°C to 150°C). If this should happen, remove the entire regulator assembly and dispose of properly. A replacement regulator assembly can be purchased by contacting Brinkmann at 1-800-527-0717. The cause of the excessive heat should be determined and corrected before using your grill again. - Page 8 Visually inspect the hose assembly prior to each use for evidence of damage, excess wear, or deterioration. If found, replace the assembly before using your grill. Only the Brinkmann supplied replacement should be used. CONNECTING HOSE AND REGULATOR TO AN LP GAS CYLINDER •...
-
Page 9: Leak Testing
LEAK TESTING: To prevent fire or explosion hazard: • DO NOT smoke or permit ignition sources in the area while conducting a leak test. • Perform test OUTDOORS only in a well ventilated area. • Never perform a leak test with a match or open flame. •... -
Page 10: Pre-Start Checklist
Inspect the gas supply hose for burns, chaffing, kinks, and proper routing before each use. If it is evident there is excessive abrasion or wear, or the hose is cut, it must be replaced prior the grill being used. Replace with hose and regulator, Model No. 155-2200-0, which can be obtained by contacting Brinkmann at 1-800-527-0717. -
Page 11: Lighting Instructions
LIGHTING INSTRUCTIONS: Follow the instructions exactly. 1. OPEN THE GRILL LID before attempting to light a burner so that fumes do not accumulate inside the grill. An explosion could occur if grill lid is down. 2. Check that all burner control knobs and the cylinder valve are turned to the OFF position. 3. -
Page 12: Turning Off The Grill
CONTROLLING FLARE-UPS: • Flare-ups are a part of cooking meats on a gas grill. This adds to the unique flavor of cooking on a gas grill. Excessive flare-ups can over-cook your food and cause a dangerous situation for you and your grill. -
Page 13: Indirect Cooking
(unlit) side of the grill. ROTISSERIE COOKING: • Your grill was pre-drilled from factory to include mounting holes for a Brinkmann rotisserie (sold separately). Do not use a rotisserie not specifically manufactured for this grill. • Read and follow all instructions provided with the rotisserie. Save instructions for future reference. -
Page 14: Transporting And Storage
• If storing the grill outdoors, cover the grill with a grill cover for protection from the weather. A grill cover can be purchased by contacting: The Brinkmann Corporation at 1-800-527-0717. CLEANING AND MAINTENANCE: • Keep grill area clear and free from combustible materials, gasoline or other flammable vapors and liquids. -
Page 15: Cooking Grills
BURNER ASSEMBLY/MAINTENANCE • Although your burners are constructed of cast iron, they may rust as a result of the extreme heat and acids from cooking foods. Regularly inspect the burners for cracks, abnormal holes, and other signs of corrosion damage. If found, replace the burner. •... -
Page 16: Troubleshooting
Reconnect grill to cylinder and light grill. See section on Connection to the LP Cylinder. 1. Excess grease build-up causing grease fires. 2. Damaged or faulty regulator. Replace with Brinkmann parts. 3. Cook on a lower temperature setting. -
Page 17: Helpful Hints
• To protect your grill from excessive rust, the unit must be kept clean and covered at all times when not in use. A grill cover may be ordered directly from Brinkmann by calling 1-800-468-5252 or 1-800-527-0717. • Wash cooking grills and heat shields with hot, soapy water, rinse well and dry. Lightly coat cooking grill with vegetable oil or vegetable oil spray. -
Page 18: Assembly Instructions
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT. The following provided tools are required to assemble this Brinkmann Pro Series 2200 Grill: • Flathead Screwdriver • Hex Nut Wrench... - Page 19 FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 1-800-527-0717. (Proof of purchase will be required.) Inspect contents of the box to ensure all parts are included and undamaged.
- Page 20 PARTS BAG CONTENTS Make sure you have all items listed under PARTS LIST and PARTS BAG CONTENTS before you begin the installation process. Your Parts Bag will include: Qty. M8 X 15mm bolts M6 X 12mm bolts AA /1.5V Alkaline battery Large Star Washers Small Star Washers Wheel axle bolts...
- Page 21 Locking Caster Tire Hubcap Wheel axle bolt Choose a good, cleared assembly area and get a friend to help you put your grill together. Lay cardboard down to protect grill finish and assembly area. Step 1 With the help of a friend, turn the preassembled cart over.
- Page 22 Step 4 Snap wheel hub caps onto the outside of wheels as illustrated. Step 5 With the help of a friend, turn the cart to its upright position. Step 6 Attach tank heat shield to heat shield plate using one #8 self-tapping screw.
- Page 23 Heat Shield Plate Heat Shield Plate Grease Cup Heat Shield Plate Step 7 Attach heat shield plate to back panel using two M6 X 12mm bolts with small star washers. Step 8 Attach heat shield plate to front panel using three #8 self-tapping screws.
- Page 24 Note: When performing Step 10, Lift grill body from front and rear panels to avoid injury to hands and fingers. Be sure to pass hose/regulator assembly above cart frame crossbar. Step 10 With the help of a friend, place grill body assembly on preassembled cart frame.
- Page 25 Step 11 Attach left side table assembly to left side of cart frame assembly. Slide side table assembly onto preattached shoulder bolts. Attach two M8 X 15 mm bolts with large star washers as illustrated and secure. Step 12 Attach right side table assembly to right side of cart frame assembly.
- Page 26 Step 13 Attach the hose heat shield to the right side of the cart frame using two #8 self-tapping screws. Step 14 Insert grease tray into opening on backside of grill. Make sure to slide tray onto tracks as illustrated. Tank Heat Shield Grease Tray...
- Page 27 Igniter Cap Battery Step 15 Warming Rack Place the porcelain coated heat tents on lower level of grill body assembly directly above burners. Cooking Grills Porcelain Heat Tents Step 16 Place porcelain cast iron cooking grills on support ribs directly above porcelain heat tents.
- Page 28 ProSeries 2200 (Assembled)
- Page 29 RIB RACK Chrome-plated rack can greatly increase the cooking capacity of your grill. Holds ribs, chicken halves, potatoes and corn vertically to triple cooking capacity. Allows smoke, steam and heat to penetrate food evenly. 812-3310-0 MEATLOAF BASKET The unique basket weave prevents meatloaf from falling through the grill while allowing smoke, steam and heat to flow into the food.
- Page 30 Restaurant-style aluminum fry pan with nickel plated wire straining basket is an essential tool for frying fish, chicken, french fries, onion rings and more. Strainer basket holder helps drain excess oil. Use outdoors with the Brinkmann Backyard Kitchen and avoid the mess and odor of frying indoors.
- Page 32 • This warranty does not cover surface scratches, rust or heat damage to the finish, which is considered normal wear. • The Brinkmann Corporation may elect to repair or replace damaged units covered by the terms of this warranty. • This warranty extends to the original purchaser only and is not transferable or assignable to subsequent purchasers.
