Power Supply

The Following Power Line requirement should be monitored one week before Installation. We
recommend that a Drantez model 605-3 Power line Monitor with options 101 to be used
Table 3-6
Voltage Range
Line Frequency
Power Transients
Decaying Oscillation
3-6-2-2

Facility Power Socket

A separate power outlet with a 5 amp circuit breaker for 120/220 VAC is recommended. The specific
power receptacle used depends on the country's power line standards.
This receptacle should have International Electro technical Commission (IEC) approval, or
equivalent
3-6-2-3 Storage & Operation Requirements
The LOGIQ™ 100 PRO is shipped in a single container excluding probes. Shipping weight is
approximately 12 kgs. Table 3-7 Table provides a summary of temperature, atmospheric pressure,
and humidity tolerances for shipping, installation and operation:
Table 3-7 Storage & Operation Requirements
Temperature (Deg.C)
Atmospheric Pressure
Non- Condensing
3-6-3

Optional Peripherals

LOGIQ™ 100 PRO peripherals and accessories can be properly connected using the connectors
on the rear panel of the LOGIQ™ 100 PRO system.
External Optional Peripherals
•
•
•
•
