Assembly & Set-Up

Contents of Carton

4
9
7
5
10
10
8
2
Part Number
1 689-00618
2 731-13094
3 731-13095
4 689-00686
5 689-00685
6 710-04995A
7* 747-06963
8* 714-3020
9* 710-3001
10* 712-04065
-* 710-06012A
* Included In Hardware Pack 689-00687
9
8
6
Description
Brush Guard Assembly
Guard, Fascia RH
Guard, Fascia LH
Bracket Assembly, Front RH
Bracket Assembly, Front LH
Screw, 5/16-14 X .750
Pin, 0.500 X 1.70
Internal Cotter Pin
Screw 3/8-16 X .880 GR5
Nut
Fixing Bolt 3/8-16 X .125 GR5
7
1
Qty.
1
1
1
1
1
6
2
2
4
4
4
2
3
3
