STIHL FSA 135 R
Instruction Manual

Advertisement

Table of Contents
loading

Related Manuals for Stihl FSA 135 R

Summary of Contents for Stihl FSA 135 R

  • Page 1 STIHL FSA 135 R Instruction Manual...

  • Page 3: Table Of Contents

    English Contents 7.6 Removing and Installing Metal Cutting Introduction ......... 2 Attachment.

  • Page 4: Introduction

    This user manual 20.2 STIHL AP battery ........29 is intended to help you use your STIHL product safely and in 20.3 Sound Values and Vibration Values .

  • Page 5: Symbols Used With Warnings In The Text

    – User instructions for AP belt bag with connecting cable – Safety notes and precautions for STIHL AP battery – Instruction manual for STIHL AL 101, 300, 500 chargers Brushcutter and Battery – Safety information for STIHL batteries and products with built-in batteries: www.stihl.com/safety-data-...

  • Page 6: Deflectors And Cutting Attachments

    3 Overview 2 Battery compartment 17 Screw plug The battery compartment holds the battery. The screw plug closes the filler opening for STIHL gear grease. 3 Cover 18 LEDs The cover is the placeholder for a Smart Connector 2 A.

  • Page 7: Icons

    English 4 Safety Precautions 3 Brush knife This icon shows the rated speed of the cutting Cuts brushwood. attachment. 4 Line Limiting Blade Trims surplus mowing line to correct length. Guaranteed sound power level in accordance with Directive 2000/14/EC in dB(A) for the 5 Skirt purpose of comparing the sound emissions of Extends universal deflector for use with a mowing head.
  • Page 8 English 4 Safety Precautions 4.1.2 Deflector for mowing heads Wear work gloves. Meanings of warning signs and labels on the deflector for mowing heads: Use this deflector for mowing heads. Observe the safety notices on kickback and take the necessary precautions. Do not use this deflector for grass cutting blades.

  • Page 9: Intended Use

    Use this deflector for shredder blades. ► Use the brushcutter with a STIHL AP battery or a STIHL AR battery. ￭ Using the brushcutter or the battery for purposes for which they were not designed may result in serious or fatal injuries and damage to property.

  • Page 10: Clothing And Equipment

    ► Wear robust footwear. ► If you are using a metal cutting attachment: ► If you have any queries: Contact a STIHL servicing Wear steel-toed safety boots. dealer for assistance. Clothing and equipment ►...

  • Page 11: Work Area And Surroundings

    ► Do not leave the battery unattended. mounted. ► Make sure that children cannot play with the battery. – Genuine STIHL accessories for this brushcutter are fitted. – The accessories are correctly attached. ￭ The battery is not protected against all ambient conditions.
  • Page 12 ► Replace worn or damaged labels. ► Observe and remain inside the wear limits. ► If you have any doubts, be sure to consult a STIHL ► If you have any doubts, be sure to consult a STIHL dealer.

  • Page 13: Operation

    ► If the battery emits an unusual odour or smoke: do not ► Observe and remain inside the wear limits. use the battery and keep it away from flammable ► If you have any doubts, be sure to consult a STIHL materials. dealer.

  • Page 14: Reactive Forces

    This can result in serious injuries and damage to property. ► Stop work, remove the battery and contact your STIHL servicing dealer for assistance. ￭ Trimmer vibrations may occur during operation.

  • Page 15: Transporting

    English 4 Safety Precautions Transporting 4.10 Storing 4.9.1 Brushcutter 4.10.1 Brushcutter WARNING WARNING ￭ The gear housing can get hot during operation. There is a ￭ Children are not aware of and cannot assess the dangers risk of burn injuries. of a brushcutter and can be seriously injured.

  • Page 16: Cleaning, Maintenance And Repair

    ► If you are using a universal deflector together with a ► If the brushcutter, the deflector or the battery require mowing head: Fit the skirt and line limiting blade, servicing or repairs, contact your STIHL dealer for @ 7.4.1. assistance.

  • Page 17: Charging The Battery, Leds

    ► Check the controls, @ 11.1. 0-20% ► If 3 LEDs flash red while you are checking the controls: Remove the battery and contact your STIHL dealer for assistance. The brushcutter has a malfunction. ► If you cannot carry out this work: Do not use your ►...

  • Page 18: Mounting The Barrier Bar

    English 7 Assembling the Trimmer ► Insert screws (8) and tighten. Mounting and Removing the Deflector 7.3.1 Mounting the guard ► Switch off the brushcutter and remove the battery. ► Fit the clamp (4) in the loop handle (3). ► Place the loop handle (3) with clamp (4) on the shaft (5). ►...

  • Page 19: Fitting And Removing The Skirt

    English 7 Assembling the Trimmer Fitting and Removing the Skirt Mounting and Removing the Mowing Head 7.4.1 Fitting the Skirt 7.5.1 Mounting the Mowing Head ► Switch off the brushcutter and remove the battery. ► Switch off the brushcutter and remove the battery. ►...

  • Page 20: Removing And Installing Metal Cutting

    English 8 Adjusting Trimmer for User Removing and Installing Metal Cutting ► Rotate the metal cutting attachment (4) counterclockwise until the stop pin (7) engages in position. Attachment The shaft (6) is now blocked. 7.6.1 Mounting the Metal Cutting Attachment ►...

  • Page 21: Fitting And Adjusting The Carrying System

    English 8 Adjusting Trimmer for User Balancing the Brushcutter ► Move the loop handle (1) to the required position and check that the following conditions are met: – The bump guard (3) fits between the loop handle (1) and carrying ring. –...

  • Page 22: Removing And Fitting The Battery

    English 9 Removing and Fitting the Battery ► Loosen the screw (3). ► Press both locking levers (1). The battery (2) is released and can be removed. ► Move the carrying ring (2) up or down the shaft until a correct balanced position is reached.

  • Page 23: Switching Off

    ► Wait for the cutting attachment to come to a standstill. ► If the cutting attachment continues to rotate: Remove the 11.2 Testing the Battery battery and contact your STIHL servicing dealer. ► Press button on battery. The trimmer has a malfunction.

  • Page 24: Setting The Performance Level

    English 12 Operating the Trimmer ► Connect the carrying ring (2) to the carabiner (1). The selected power level affects the battery’s runtime. The lower the power level, the longer the runtime. If you are using a mowing head: ► Hold the brushcutter firmly with one hand on the control ►...

  • Page 25: Adjusting Nylon Line

    English 13 After Finishing Work Automatic feed will not take place if the mowing lines are shorter than 25 mm. ► Switch off the brushcutter and remove the battery. ► Depress the spool (1) on the mowing head and hold it depressed.

  • Page 26: Transporting

    ► Carry the brushcutter in one hand properly balanced by the shaft, with the cutting attachment behind you. STIHL recommends that you store the battery with a charge between 40 % and 60 % (2 LEDs glow green). Transporting the brushcutter in the car ►...

  • Page 27: Cleaning The Air Filter

    ► Insert and tighten down the screw (1) firmly. ► Remove the screw plug (2). ► If no grease can be seen on the end of the screw plug (2): ► Screw the tube (1) of STIHL gear grease into the filler 16.4 Cleaning the Battery hole.

  • Page 28: Sharpening And Balancing A Metal Cutting

    STIHL recommends you have metal cutting attachments resharpened and balanced by a STIHL servicing dealer. ► Sharpen the metal cutting attachment as described in the instructions and on the packaging supplied with the cutting attachment you are using.

  • Page 29: Troubleshooting

    ► Recharge the battery fully as described in the User not start when green. battery is too low. Manual for the STIHL AL 101, 300, 500 chargers. switched on. 1 LED emits red The battery is too warm or ► Remove the battery.
  • Page 30 The runtime of the The battery is not fully ► Recharge the battery fully as described in the User brushcutter is too charged. Manual for the STIHL AL 101, 300, 500 chargers. short. The battery life has been ► Replace battery. exceeded.

  • Page 31: Specifications

    20 Specifications Using with a metal cutting attachment – Sound pressure level L measured as specified in 20.1 STIHL FSA 135 R Brushcutters EN 50636-2-91: 80 dB(A) – Permitted batteries: – Sound power level L measured according to EN 50636- –...

  • Page 32: And Carrying Systems

    – AutoCut 25-2 mowing head – Universal deflector system with skirt and line – AutoCut C 26-2 mowing head – STIHL AR battery with the support limiting blade cushion – DuroCut 20-2 mowing head – Battery belt with attached “AP belt –...

  • Page 33: Spare Parts And Accessories

    STIHL accessories. – model: FSA 135 R – serial number: FA01 STIHL recommends the use of original STIHL spare parts and accessories. conforms to the relevant provisions of Directives Despite ongoing market observation, STIHL is unable to...
  • Page 34 English 24 EC Declaration of Conformity The technical documents are stored at ANDREAS STIHL AG & Co. KG Produktzulassung. The year of manufacture, country of manufacture and serial number are specified on the rating plate of the brushcutter. Waiblingen, 01.09.2020 ANDREAS STIHL AG &...
  • Page 36 0458-662-0121-A englisch www.stihl.com *04586620121A* 0458-662-0121-A...
