- Page 1 Hardware Installation Manual AudioCodes Gateway & Session Border Controller Series Mediant™ 3100 SBC & Media Gateway...
- Page 2 Please contact your local recycling authority for disposal of this product. Customer Support Customer technical support and services are provided by AudioCodes or by an authorized AudioCodes Service Partner. For more information on how to buy technical support for AudioCodes products and for contact information, please visit our website at https://www.audiocodes.com/services-support/maintenance-and-support.
- Page 3 Notice Mediant 3100 | Hardware Installation Manual Ethernet port interface cabling must be shielded and routed only indoors (must not exit the building). The device must be connected to a grounded AC power outlet. Use only the AC power cords supplied with the device to connect to the power source.
-
Page 4: Table Of Contents
Content Mediant 3100 | Hardware Installation Manual Table of Contents Introduction Unpacking the Device Physical Description Physical Dimensions and Operating Environment Front Panel Description LED Descriptions PWR LED FAN LED SYS LED TEL LED HA LED Fan Tray Description Rear Panel Description... -
Page 5: Introduction
Mediant 3100 | Hardware Installation Manual Introduction This document provides a hardware description of AudioCodes Mediant 3100 Session Border Controller (SBC) and Media Gateway (hereafter referred to as device) as well as step-by-step instructions on how to install the device. -
Page 6: Unpacking The Device
2 x front-mounting brackets with six screws for 19-inch rack mounting ● 1 x grounding lug ● 1 x serial cable adapter ● 2 x AC power cables Check, retain and process any documents. If there are any damaged or missing items, notify your AudioCodes sales representative. - 2 -... -
Page 7: Physical Description
CHAPTER 3 Physical Description Mediant 3100 | Hardware Installation Manual Physical Description This section provides a physical description of the device. Physical Dimensions and Operating Environment The device's physical dimensions and operating environment are listed in the following table: Table 3-1: Physical Dimensions and Operating Environment... -
Page 8: Led Descriptions
CHAPTER 3 Physical Description Mediant 3100 | Hardware Installation Manual Item # Label Description PWR, FAN, SYS, Front-panel LEDs. For more information, see TEL, BITS, HA Descriptions below. Note: The BITS LED is currently not used. Reset pinhole button for resetting the device and... -
Page 9: Sys Led
CHAPTER 3 Physical Description Mediant 3100 | Hardware Installation Manual Table 3-4: FAN LED Description Color State Description Green The Fan Tray module is operating normally. One or more fans of the Fan Tray module are faulty. The Fan Tray module is not receiving power. -
Page 10: Ha Led
CHAPTER 3 Physical Description Mediant 3100 | Hardware Installation Manual HA LED The HA LED indicates High-Availability (HA) status, as described in the following table. HA will be supported only from a specific 7.4 software version. For more information, refer to the Release Notes. - Page 11 CHAPTER 3 Physical Description Mediant 3100 | Hardware Installation Manual When installing the chassis, make sure that there is sufficient front and rear clearance for proper airflow into and out of the chassis. Figure 3-3: Fan Tray Module Figure 3-4: Fan Tray Cover...
-
Page 12: Rear Panel Description
CHAPTER 3 Physical Description Mediant 3100 | Hardware Installation Manual During system operation, the inner ambient temperature is continuously monitored. Upon excessive temperature conditions, SNMP Temperature Alarm generated (acBoardTemperatureAlarm). Upon a speed degradation or full stop of any fan, an SNMP Fan Alarm (acFanTrayAlarm) is generated. -
Page 13: Ac Power Supply Module Description
CHAPTER 3 Physical Description Mediant 3100 | Hardware Installation Manual Item # Label Description information, see Grounding and Surge Protection on page 12. AC Power Supply Module Description The device can accept up to two extractable AC Power Supply modules. These power supplies are of load-sharing type connected in 1+1 topology, therefore allowing power redundancy. -
Page 14: 19-Inch Rack Mounting
CHAPTER 4 19-Inch Rack Mounting Mediant 3100 | Hardware Installation Manual 19-Inch Rack Mounting The device is designed to be mounted in a standard 19-inch rack. This is done by placing it on a shelf (not supplied) in a 19-inch rack and then securing it to the rack's posts, using the front- mounting brackets (supplied). - Page 15 CHAPTER 4 19-Inch Rack Mounting Mediant 3100 | Hardware Installation Manual Figure 4-1: Attaching Mounting Brackets to Chassis Lift the chassis onto the shelf that you installed in the 19-inch rack (see Step 1). Align the holes of the chassis' mounting brackets with the holes of the rack posts, as shown in the following figure.
-
Page 16: Cabling The Device
CHAPTER 5 Cabling the Device Mediant 3100 | Hardware Installation Manual Cabling the Device This section describes how to cable the device. Grounding and Surge Protection The device must be earthed at all times to a stable local earth reference. A grounding lug is... -
Page 17: Connecting Ethernet Interfaces
CHAPTER 5 Cabling the Device Mediant 3100 | Hardware Installation Manual Attach the grounding lug to the chassis, as shown in the following figure, making sure that the spring washer is located between the screw head and the lug. Figure 5-1: Attaching Grounding Lug to Chassis Connect the other end of the grounding wire to the building's protective earth. -
Page 18: Ethernet Leds
CHAPTER 5 Cabling the Device Mediant 3100 | Hardware Installation Manual ■ Connector Pinouts: Table 5-1: RJ-45 Connector Pinouts for Ethernet Ports Signal Name Ethernet signal pair Ethernet signal pair Ethernet signal pair Ethernet signal pair Shield Chassis ground ➢ To connect the Ethernet interfaces:... -
Page 19: Connecting E1/T1 Trunks
CHAPTER 5 Cabling the Device Mediant 3100 | Hardware Installation Manual Table 5-2: Ethernet LEDs Description Color State Description Green Ethernet link established. Flashing Data is being received or transmitted. No Ethernet link. Connecting E1/T1 Trunks The device provides 32 RJ-45 ports for connecting up to 32 E1/T1 trunks for ISDN PRI interfaces. -
Page 20: Connecting The Serial Interface To A Computer
CHAPTER 5 Cabling the Device Mediant 3100 | Hardware Installation Manual Connecting the Serial Interface to a Computer The device provides an RS-232 serial interface port on the front panel, which you can use to access its command-line interface (CLI) for serial communication. - Page 21 CHAPTER 5 Cabling the Device Mediant 3100 | Hardware Installation Manual RJ-45 DB-9 Female Data (RXD) Internally used Not used Internally used Not used Receive Data (RXD) Transmit Data (TXD) Ground (GND) Ground (GND) Internally used Not used ➢ To connect the serial interface port to a computer: Connect the RJ-45 connector, at one end of the cable, to the device's serial port (labeled CONSOLE), located on the chassis' front panel.
-
Page 22: Connecting A Usb Storage Device
CHAPTER 5 Cabling the Device Mediant 3100 | Hardware Installation Manual Figure 5-5: Connecting Serial Interface Connect the DB-9 connector, at the other end of the cable, to a COM RS-232 communication port on your PC. Connecting a USB Storage Device The device supports USB storage capabilities, using an external USB hard drive or flash disk (disk on key) connected to the device's USB port. -
Page 23: Connecting To Ac Power Supply
CHAPTER 5 Cabling the Device Mediant 3100 | Hardware Installation Manual Figure 5-6: Connecting USB Storage Device Only a single USB storage (formatted to FAT/FAT32) operation is supported at any given time. Connecting to AC Power Supply The device provides two hot-swappable Power Supply modules for load-sharing and power redundancy in case of failure in one of the modules. -
Page 24: Power Supply Led
CHAPTER 5 Cabling the Device Mediant 3100 | Hardware Installation Manual ● Use only a certified 3-conductor power cord, utilizing 18 AWG or 1 mm wires, and no longer than 4.5 meters (14.8 ft). ● If a failure occurs in any one of the Power Supply modules, replace the module immediately. - Page 25 CHAPTER 5 Cabling the Device Mediant 3100 | Hardware Installation Manual Table 5-5: Power Supply Module LED Description Color State Description Green The DC power output is good. Amber Flashing The Power Supply module is not operating properly. Indicates one of the following: An internal power supply malfunction .
-
Page 26: Hardware Maintenance
CHAPTER 6 Hardware Maintenance Mediant 3100 | Hardware Installation Manual Hardware Maintenance The device is designed as a modular chassis and allows you to order certain parts as a Field Replacement Unit (FRU). This section describes the procedures for replacing these parts. - Page 27 CHAPTER 6 Hardware Maintenance Mediant 3100 | Hardware Installation Manual Remove the Fan Tray module: Loosen the four flat-head, spring-loaded captive screws (see #1 in following figure) securing the Fan Tray module to the chassis, using a flat-head or Phillips screwdriver.
-
Page 28: Replacing The Air Filter
The device's components may be damaged due to a dirty or blocked air filter. ● Replace the air filter only with an air filter purchased from AudioCodes. ● Before removing the air filter, make sure that you have the replacement air filter on hand so that you can replace it immediately. - Page 29 CHAPTER 6 Hardware Maintenance Mediant 3100 | Hardware Installation Manual Figure 6-2: Removing Fan Tray Cover on Front Panel Remove the Air Filter cover, located on the inside of the Fan Tray cover, by removing the two flat-head, spring-loaded captive screws located on either side of the Air Filter cover,...
-
Page 30: Replacing Power Supply Modules
CHAPTER 6 Hardware Maintenance Mediant 3100 | Hardware Installation Manual Figure 6-4: Removing Air Filter from Air Filter Cover Insert the new filter into the enclosure of the Air Filter cover. Attach the Air Filter cover to the Fan Tray cover, by using the two spring-loaded captive screws (see the figure in Step 2). - Page 31 CHAPTER 6 Hardware Maintenance Mediant 3100 | Hardware Installation Manual Figure 6-5: Handle and Release Latch on Power Supply Module Place your other hand under the faulty Power Supply module for support and then slide the module completely out of the chassis. Avoid touching the top of the module as it may be hot from being in the chassis. ...
- Page 32 CHAPTER 6 Hardware Maintenance Mediant 3100 | Hardware Installation Manual This page is intentionally left blank. - 28 -...
