Summary of Contents for Ryobi RGS18X15
- Page 1 ORIGINAL INSTRUCTIONS Grass Shears and Shrubber RGS18X15 RGS1822Li25 OGS1820...
- Page 2 Important! It is essential that you read the instructions in this manual before assembling, operating, and maintaining the product. Subject to technical modification.
-
Page 3: Intended Use
Safety, performance, and dependability have been given shock. top priority in the design of your compact hedge trimmer ■ If operating a power tool in a damp location is and grass shears. unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of INTENDED USE electric shock. -
Page 4: Hedge Trimmer Safety Warnings
other condition that may affect the power tool’s PREPARATION operation. If damaged, have the power tool repaired ■ nspect the product before use. Replace damaged before use. Many accidents are caused by poorly parts. maintained power tools. ■ Clear the area to be cut before each use. Remove all ■... -
Page 5: Transportation And Storage
the cable may be hidden in shrubs and can be ■ Fit the blade sheath when the product is not in use. accidentally cut by the blade. ■ Never douse or squirt the product with water or any ■ Check the hedge for foreign objects, such as wire other liquid. -
Page 6: Maintenance
Injuries may be caused, or aggravated, by prolonged BATTERY PROTECTION FEATURES use of a tool. When using any tool for prolonged periods, RYOBI 18V lithium-ion batteries are designed with features ensure you take regular breaks. that protect the lithium-ion cells and maximise battery life. If... -
Page 7: Symbols On The Product
WHAT’S IN THE BOX Waste electrical products should not See page 6 be disposed of with household waste. Please recycle where facilities exist. RGS18X15 / RGS1822Li25 / OGS1820 Check with your local authority or retailer ■ Grass shears x 1 for recycling advice. - Page 8 WHAT’S IN THE BOX RGS18X15 *Kit includes battery and charger.
- Page 9 WHAT’S IN THE BOX RGS1822Li25 *Kit includes battery and charger.
- Page 10 WHAT’S IN THE BOX OGS1820 *Battery and charger are sold separately.
-
Page 11: Know Your Product
7. Shrubber hedge blade 2. Blade post 8. Grass shears blade sheath 3. Charger 9. Grass shears blade 4. Battery latch button 10. ON/OFF trigger 5. Battery pack 11. Trigger lock out button 6. Shrubber hedge blade cover 12. Rear handle RGS18X15 RGS1822Li25... -
Page 12: Getting Started
GETTING STARTED Always wear safety goggles or safety glasses with side Attach the blade to the blade connection point. Fasten the shields when operating the product. Failure to do so could blade by twisting the blade securing knob clockwise. result in objects being thrown into your eyes resulting in possible serious injury. - Page 13 GETTING STARTED Remove the grass shears blade cover. Remove the shrubber hedge blade cover.
- Page 14 OVERVIEW Grass Shears Operation Changing blades p.14 p.16 Storage Maintenance p.18 p.20...
- Page 15 OVERVIEW Compact Hedge Trimmer Operation Changing blades p.15 p.17 Maintenance p.19...
-
Page 16: Operation
OPERATION OPERATING THE GRASS SHEARS CAUTION: Avoid rocks and small boulders when using the product. WARNING: Keep hands away from the blades at all times. 1. Install the battery pack until the latches snap into place. Make sure that the battery pack is securely attached before using the product. - Page 17 OPERATION OPERATING THE COMPACT HEDGE TRIMMER WARNING: Keep hands away from the blades at all times. 1. Install the battery pack until the latches snap into place. Make sure that the battery pack is securely attached before using the product. Press the trigger lock out button and squeeze the ON/OFF trigger.
- Page 18 OPERATION CHANGING THE BLADES 1. Press and hold the latch to release the battery pack. 2. Install the grass shears blade sheath. 3. Twist the blade securing knob counter clockwise, and remove the grass shears blade from the blade connection point. 4.
- Page 19 OPERATION CHANGING THE BLADES 1. Press and hold the latch to release the battery pack. 2. Install the compact hedge trimmer blade sheath. 3. Twist the blade securing knob counter clockwise and remove the shrubber hedge blade from the blade connection point.
-
Page 20: Maintenance
MAINTENANCE CLEANING THE GRASS SHEARS 1. Press and hold the latch to release the battery pack. 2. Clean the debris from the blades with a stiff brush. Clean the body and handles of the product with a soft, dry cloth after each use. - Page 21 MAINTENANCE CLEANING THE SHRUBBER HEDGE BLADE 1. Press and hold the latch to release the battery pack. 2. Clean the debris from the blades with a stiff brush. Clean the body and handles of the product with a soft, dry cloth after each use.
- Page 22 STORAGE STORING THE GRASS SHEARS AND COMPACT HEDGE TRIMMER 1. Press and hold the latch to release the battery pack. 2. Install the grass shears / compact hedge trimmer blade sheath. 3. Twist the blade securing knob counter clockwise and remove the grass shears / shrubber hedge blade from the blade post.
- Page 23 STORAGE 4. Replace the blade securing knob on the blade connection point and twist clockwise. 5. Store the product in a cool, dry, and well-ventilated place that is inaccessible to children and away from sources of ignition.
-
Page 24: Product Specifications
PRODUCT SPECIFICATIONS BATTERY AND CHARGER Compact Hedge Trimmer And Grass Shears Model RGS18X15 RGS1822Li25 OGS1820 Model RGS18X15 / RGS1822Li25 / Battery pack RB18L15B RB18L25 not included OGS1820 Weight 0.43kg 0.46kg Rated Voltage 18 V DC Charger RC18115 RC18120 not included... - Page 28 RYOBI is a trade mark of Ryobi Limited, Imported by: and is used under license. Techtronic Industries Australia Pty Ltd WD-40 is a registered trade mark of WD-40 31 Gilby Road, Mount Waverley, VIC 3149 Manufacturing Company. Melbourne, Australia INOX is a registered trade mark of Candan Enterprises Pty Ltd.
