American Dynamics ADTT32E Installation Instructions Manual

AD32 Enhanced T
1
T ® 1 ADTT32E
RACKER
With Video Matrix Switcher

About this Guide

This installation guide explains the procedures for
installing Enhanced T
OUCH
with the Video Matrix Switcher. Other related
documents are:
Installation and Service Manual, 8000-1702-02
Operator's Manual, 8000-2655-02
Note: Because customer requirements dictate the
placement of T T
OUCH RACKER
Sensormatic representative will supply this
information separately.
If you need assistance...
Call Sensormatic Customer Support at:
1-800-543-9740
1
T T , Sensormatic, and the Sensormatic logo are
OUCH RACKER
registered trademarks of Sensormatic Electronics Corporation. Other
product names (if any) mentioned herein may be trademarks or
registered trademarks of Sensormatic or other companies.
No part of this document may be reproduced in any form without
written permission from Sensormatic Electronics Corporation.
© Copyright 1999. All rights reserved.
(CSD) 07/99
8000-2671-02, Rev. A (7 pages)
OUCH
T controllers
RACKER
components, your

Installation Instructions

Parts Required
T T Installation Kit:
OUCH RACKER
Part Number 0351-0474-07
INSTL KIT, TOUCH TRKR, W/RJ45
Description
CABLE ASSY,MDLR,14FT,8 COND,CROSS-P
SCR,THD CUT,M2.9X9.5,PHP,ST,Z,T1
ANCHOR,PLASTIC,W/O SCREW,8-10
SCR,TYP AB,PHP,CAD,#8X1"
CONN,PLUG,TUBLR,.200CTR,26-12AWG,1X
LUG,SPADE,CRIMP,INSUL,22-16AWG
CABLE,3COND,18AWG,CM
INTERCONNECT BOX,TOUCHTRACKER
CABLE ASSY,TOUCH TRACKER,INTFC TO Q
HOOD,D-SUB,9POS,EMI/RFI,.25 DIA CAB
CONN,D-SUB,PLUG,HSG,9POS,SSI
FERRITE CORE
QUICK REFERENCE GUID
TOUCH TRACHER STRAIN RELIEF INSTR
WARNING Shock Hazard!
CAUTION static sensitive
Follow proper handling procedures to
prevent component failure.
Installation Procedures
See Remote Switcher Location for procedures
when the Video Matrix Switcher will be more than 4m
(14 ft) from the EIMs.
1. Attach each EIM to a wall or other surface within
T
3m (10 ft) of its
2. Terminate the EIM that is at the end of the
SensorNet network.
See Figure 1 for the wiring diagram for a typical
2-controller AD32 system installation. For more
information on the SensorNet network, see the
SensorNet Network Guide (PN 8000-0970-01).
3. Attach the 3 spade lugs to one end of the 3-
conductor cable, then attach the lugs to the EIM
power transformer.
AMERICAN DYNAMICS PRODUCTS
1
Qty Part No.
1 6003-0047-01
1 5899-0004-102
2 2880-0083-01
2 2816-7634-44
1 2109-0254-04
3 2141-0002
16.5 6002-0024-01
1 0300-1000-01
1 0650-0932-01
1 2125-0007-02
1 2130-0021-01
1 2700-0023-01
1 8000-2656-02
1 8000-1370-01
Disconnect AC Power.
components!
T
controller.
OUCH RACKER
