Safety precautions Although this product was designed to be used safely, failing to use it correctly may result in an accident. To ensure safety, observe all warnings and cautions while using the product. Cautions for the product • Do not subject the product to strong impact to avoid malfunction. •...
Notes on use • Do not swing or pull with the cable connected to the microphone to prevent the microphone from becoming disconnected or damaged. • Do not wind the cable around the rack or allow the cable to become pinched. •...
Using the product Included accessories Rubber isolator (1) Rubber isolator (2)
Page 5
Using the product How to mount the product Table/ceiling hole size (when using isolators) φ 23.5 (Unit: mm) Table/ceiling hole size (when not using isolators) φ20.5 (Unit: mm)
Page 6
Using the product Example: Mounting on a table Front-of-mic indicator Rubber isolator (1) Rubber isolator (2) Table...
Using the product Switch setting and functions Contact Closure 1. Action 2. Contact 3. Audio 4. LED color 5. LED status closure status status LED color GREEN YELLOW BLUE MAGENTA CYAN WHITE...
Using the product Connection procedure The output connector is an XLR-M type with polarity as shown in the figure below. PIN1 (ground) PIN2 (hot) PIN3 (cold) Contact closure LED control...
Specifications Element Fixed-charge back plate, permanently polarized condenser Polar pattern Cardioid Frequency response 70 to 15,000 Hz Open circuit sensitivity -37 dB (0 dB = 1 V/Pa, 1 kHz) Impedance 60 ohms Maximum input sound level 134 dB SPL (1 kHz at 1% THD) Dynamic range 110 dB (1 kHz at Max SPL) Signal-to-noise ratio...
