Summary of Contents for Audio Technica ES945O
- Page 1 ES945O/XLR ES945WO/XLR Omnidirectional Condenser Boundary Microphone User Manual English...
-
Page 2: Safety Precautions
Safety precautions Although this product was designed to be used safely, failing to use it correctly may result in an accident. To ensure safety, observe all warnings and cautions while using the product. Cautions for the product • Do not subject the product to strong impact to avoid malfunction. •... -
Page 3: Notes On Use
Notes on use • Do not swing or pull with the cable connected to the microphone to prevent the microphone from becoming disconnected or damaged. • Do not wind the cable around the rack or allow the cable to become pinched. •... - Page 4 About splash-proof performance • The splash-proof specification of this product applies only to the head of the microphone. • Although the product has splash-proof capabilities equivalent to IPX4, the screw part and the connector part of the product are not splash-proof. •...
-
Page 5: Using The Product
Using the product Included accessories Rubber isolators... - Page 6 Using the product How to mount the product Table/ceiling hole size (when using isolators) φ23.5 (Unit: mm) Table/ceiling hole size (when not using isolators) φ20.5 (Unit: mm) Example: Mounting on a table Rubber isolators Table...
-
Page 7: Connection Procedure
Using the product Connection procedure The output connector is an XLR-M type with polarity as shown in the figure below. PIN1 (ground) PIN2 (hot) PIN3 (cold) - Page 8 Dimensions φ28 M20P=1 (Unit: mm)
-
Page 9: Specifications
Specifications Element Fixed-charge back plate, permanently polarized condenser Polar pattern Omnidirectional Frequency response 60 to 15,000 Hz Open circuit sensitivity -33 dB (0 dB = 1 V/Pa, 1 kHz) Impedance 100 ohms Maximum input sound level 130 dB SPL (1 kHz at 1% THD) Dynamic range 109 dB (1 kHz at Max SPL) Signal-to-noise ratio... -
Page 10: Polar Pattern/Frequency Response
Polar pattern/Frequency response Polar pattern 0˚ 330˚ 30˚ 60˚ 300˚ 270˚ 90˚ 120˚ 240˚ 150˚ 210˚ 180˚ LEGEND 200 Hz SCALE IS 5 DECIBELS 1 kHz PER DIVISION 5 kHz 8 kHz Frequency response 60 - 15,000 Hz 10 dB Frequency in Hertz LEGEND 0°, 50 cm... - Page 11 株式会社オーディオテクニカ 〒194-8666 東京都町田市西成瀬2-46-1 www.audio-technica.co.jp Audio-Technica Corporation 2-46-1 Nishi-naruse, Machida, Tokyo 194-8666, Japan www.audio-technica.com ©2021 Audio-Technica Corporation Global Support Contact: www.at-globalsupport.com 142316981-02-01 ver.1 2021.02.01...
