- Page 1 P52001_M2-System_OM 2/13/08 4:16 PM Page 1 w i r e l e s s w i r e l e s s w i r e l e s s Wireless In-Ear Monitor System w i r e l e s s w i r e l e s s 0168 Set-up and Operation Pages 2-13...
- Page 2 P52001_M2-System_OM 2/13/08 4:16 PM Page 2 WARNING! Notice to individuals with implanted cardiac pacemakers or AICD USE AS LOW A VOLUME AS POSSIBLE. PERMANENT HEARING DAMAGE devices: Any source of RF (radio frequency) energy may interfere with CAN RESULT FROM USING THIS SYSTEM AT EXCESSIVE VOLUMES. normal functioning of the implanted device.
- Page 3 P52001_M2-System_OM 2/13/08 4:16 PM Page 3 M2 System Components UHF Stereo Receiver UHF Stereo Transmitter with Dynamic Earphones AC adapter Quick-start guide 1. Plug in the included AC adapter and connect to transmitter’s DC input. 6. Connect audio source(s) to inputs on the rear panel of the transmitter.
-
Page 4: System Features
The M2 is a frequency-agile in-ear monitor system designed to make stage monitoring more effective, comfortable, portable, and intelligible. Note: M2 “L” Band receivers must be used only with “L” Band The M2R Stereo Receiver allows the user to create and control his/her transmitters;... - Page 5 P52001_M2-System_OM 2/13/08 4:16 PM Page 5 M2 Transmitter Controls (front panel) (rear panel) 11. Inputs. Combination input jacks offer both XLR and " jacks. 1. Power LED. Lights red when power is applied. 12. DC input. Plug the included power supply in here.
- Page 6 P52001_M2-System_OM 2/13/08 4:16 PM Page 6 M2 Receiver Controls 12 13 14 15 1. On/off volume knob. Turn inner knob to the right; turns on with 9. Belt clip. Attach the receiver to your belt or guitar strap with this click.
-
Page 7: Dip Switches
P52001_M2-System_OM 2/13/08 4:16 PM Page 7 DIP Switches DIP Switch 1–Limiter Stereo Mode & Mix Output. See image B on page 10. Limits output level to earphones. Up—ON (factory setting); Down— 2 in MIX Output (Up) OFF. IMPORTANT: Leave limiter ON. This setting protects your hearing 4 in STEREO Mode (Down) from unexpected signal peaks;... -
Page 8: System Operation
(optional Audio-Technica lavalier microphone, available separately). M2 “L” Band transmitters must be used only with “L” Band receivers; the same holds true for all the frequency bands (i.e., always use •... -
Page 9: System Applications
The nature of in-ear monitoring allows for endless experimentation; the Personal Mix Control. See image B on page 10. M2 Wireless In-Ear Monitor System can be easily configured to meet Typical two-channel operation using Personal Mix Control your individual needs. While there are countless ways to use the system, 1. - Page 10 P52001_M2-System_OM 2/13/08 4:16 PM Page 10 A. Basic Stereo Set-up Band Mix Right Band Mix Left (optional) Left Right MIXER RECORDING DEVICE AMBIENT MICROPHONE (optional) ( ( ( ) ) ) Band Mix Right Band Mix Left B. Typical 2 Channel Set-up (Personal Mix Control) Band Mix Vocals Left...
- Page 11 P52001_M2-System_OM 2/13/08 4:16 PM Page 11 C. Advanced 2 Channel Set-up (Personal Mix Control Using Direct Outputs) Band Mix Vocal 1 Vocal 2 Guitar Direct Outputs SYSTEM 1 SYSTEM 2 SYSTEM 3 M2T (SYSTEM 1) Left Right Left Right Left Right (More Vocal 1) (More Band Mix)
-
Page 12: Specifications
P52001_M2-System_OM 2/13/08 4:16 PM Page 12 Specifications † Overall System UHF Operating Frequencies Band Frequency Range Number of Frequencies Band E: 790.000 to 822.000 MHz 100 Band F: 832.000 to 865.000 MHz 100 Band L: 575.000 to 608.000 MHz 100 Band M: 614.000 to 647.000 MHz 100 Not all frequency bands available in all areas. - Page 13 P52001_M2-System_OM 2/13/08 4:16 PM Page 13 M2 Frequency Plans M-Band GroupA GroupB GroupC GroupD GroupE GroupF GroupG GroupH GroupI GroupJ CH-1 615.125 614.000 614.500 615.875 616.750 614.750 614.875 614.125 614.250 616.625 CH-2 619.625 619.500 619.500 619.625 617.750 618.750 615.625 621.125 617.625...
