How to connect my Jabra GN9350e with Siemens OpenStage
30, 40, 60, 80
Jabra GN9350e MS
Prerequisite:
Jabra GN9350 + Jabra LINK 14201-10
In combination with one of the following phones:
OpenStage 30/ 40 / 60 / 80
Full function from software version 1.40 (multiple dial tone signal
transfer)
Connection:
1. Plug the 1-sided end of the DHSG cable marked blue into the socket of
your OpenStage phone marked with the "headset" symbol.
2. Plug the RJ10 plug into the socket marked with a "phone" and the RJ45
plug into the base socket of the Jabra GN9350 marked with "AUX".
Software setup:
In the LCD Display, set the Jabra GN9350 to "DHSG" and press the OK
button to confirm the software setting.
Base setup:
Set the phone setup switch to "A".
/supportpages/jabra-gn9350e/9356-607-501/faq/9c87ed04-1a34-4175-8eb5-
2d9c86fc39c4
11/05/2021 15:31
Side 1 av 3
Advertisement
Related Manuals for Jabra GN9350e
Summary of Contents for Jabra GN9350e
- Page 1 2. Plug the RJ10 plug into the socket marked with a “phone” and the RJ45 plug into the base socket of the Jabra GN9350 marked with "AUX". Software setup: In the LCD Display, set the Jabra GN9350 to "DHSG" and press the OK button to confirm the software setting. Base setup: Set the phone setup switch to "A".
- Page 2 "answer/end” button" on the headset; by pressing again the call is ended. Phone setup: Important: For equipment software 3.18, the headset operation must be set up additionally at the phone. /supportpages/jabra-gn9350e/9356-607-501/faq/9c87ed04-1a34-4175-8eb5- Side 2 av 3 2d9c86fc39c4...
- Page 3 OpenStage 40: Menu> Audio Accessories> Headset> Cordless OpenStage 60/80: Menu> User> Audio> Settings> Headset> Cordless Important: The dial tone signal in the headset is transmitted only if the standard ringtones are used. No ringtone is transmitted for mp3 ringtones. /supportpages/jabra-gn9350e/9356-607-501/faq/9c87ed04-1a34-4175-8eb5- Side 3 av 3 2d9c86fc39c4...
