Jabra GN9350e Quick Start Manual

How to connect my Jabra GN9350e with Aastra Open Phone
6771, 6773, 6775, 71, 73, 75, Aastra 6739i, Aastra 7434 and
7444
Jabra Link 14201-10
Prerequisite:
Jabra GN9350 + Jabra LINK 14201-10
In combination with one of the following phones:
Open Phone 6771 / 6773 / 6775 including IP (previous name: Open
Phone 71 /73 / 75 including IP)
Aastra 6739i
Aastra 7434 / 7444 IP
Connection:
1. Plug the 1-sided end of the DHSG cable marked "blue" into the socket
of your phone marked with the "headset" symbol.
2. Insert the RJ9 plug into the socket marked with a complete "phone"
symbol and the RJ45 plug into the base socket of the Jabra GN9350
marked with "AUX".
Software setup:
In the LCD Display, set the Jabra GN9350 to "DHSG" and press the OK
button.
