Section 3
Operations
There are three methods to control your KVM Switch for
PC and Audio channel selection: using (1) the face-panel
push button, (2) the hotkey sequences, or (3) the KVM
Switcher Software.
Face-panel Push Button
The Switch Button let you directly change between
the computers. Simply press the button on the KVM
to select the computer.
Hotkey Sequence
The Hotkey Sequence consists of three specific
keystrokes pressed on the keyboard:
Ctrl + Alt + [Command key]
The factory default command key is:
Ctrl + Alt + 1 or 2 for PC 1 or 2
You can also use ScrLk + ScrLk + 1 or 2 to switch
between computers.
However, this special hotkey is not
available for Mac.
Note:
Each keystroke of the Hotkey Sequence should be
pressed within 2 seconds; otherwise, the Hotkey
Sequence will not be validated.
KVM Switcher Software
Right click the KVM Switcher icon to evoke the operation
menu, then select whichever PC that is available for
switching. Once you select a PC channel, it will
immediately switch to that PC. Note that the unconnected
port(s) or the active port will be grayed-out and hence non-
selectable.
Windows
Windows:
Operation Menu
Mac OS:
Operation Menu
Define Hotkey commands
The command key is user-definable via the configuration
dialog box. You can specify the command key as you like
by typing it in.
For example, you can specify the hotkey for switching to
PC 1 as CTRL + ALT + A by typing an A (not case-
sensitive) in the editable field.
Note:
If you intend to modify the command key, you have
Mac OS
to modify them on each and every of the connected
computers, since the hotkey setting is stored within each
connected computer.
Except those control keys such as Alt, Ctrl, Shift,
CAPS, Tab, Esc and those functions keys and edit keys,
all other keys on the keyboard, including those number
keys on the number pad, are all other keys qualified to be
used as hotkey command keys. In addition to the software
KVM Switching by the operation menu and the user-
defined hotkeys, you can always use the universal hotkey
for PC switching – ScrLk + ScrLk
Advanced Options
•
Fix Audio Port:
Check this option and then select the PC to fix the
Configuration Dialog Box
audio/mic channel to the selected PC. Once this option is
checked, the audio/mic channel will be fixed and become
non-switchable.
•
Auto Scan Period:
Select the Autoscan period from 10 ~ 60 seconds with an
increment of 5 seconds. The Autoscan period is the time
your KVM Switch will wait to switch to next PC.
Section 4
Configuration Dialog Box
Copyright © 2007 AirLink101®. All rights reserved. AirLink101®, the stylized
AirLink101 logo, specific product designations, and all other words and logos that
are identified as trademarks and/or service marks are, unless noted otherwise, the
trademarks and service marks of AirLink101. All other product or service names are
the property of their respective holders. AirLink101 products are protected under
numerous U.S. and foreign patents and pending applications, mask work rights, and
copyrights.
Technical Support
Email:
support@airlink101.com
Toll Free: 1-888-746-3238
Web Site: www.airlink101.com
