- Page 1 VERT-I-PAK A-Series ® Single Package Vertical Air Conditioning System Large Chassis NOTE: This manual only applies to VEA 24000 and VHA 18000-24000 BTU/hr models. For all other A-series models please refer to manual 95991001_05 VPAK LARGE IOM / 95991002_04...
-
Page 2: Service And Warranty
Service & Warranty Servicing / Chassis Quick Change Outs To Remove the Chassis from the Closet: The chassis is designed for quick disconnect 1. Switch the unit off at the thermostat. and change out. For minor electrical service, the 2. Disconnect the power coming into the unit from control box cover lifts straight up after the screws the main breaker panel or the closet mounted and disconnect pull-out are removed. -
Page 3: Thermostat Controls
T6 Pro Programmable Thermostat User Guide Package Includes: • T6 Pro Thermostat • UWP Mounting System • Honeywell Standard Installation Adapter (J-box adapter) • Honeywell Decorative Cover Plate – Small; size 4-49/64 in x 4-49/64 in x 11/32 in (121 mm x 121 mm x 9 mm) •... -
Page 4: Set The Time And Date
System operation settings 1 Press the Mode button to cycle to the next available System mode. 2 Cycle through the modes until the required System mode is displayed and leave it to activate. NOTE: Available System modes vary by model and system settings. -
Page 5: Program Schedule
Program Schedule You can program four time periods each day, with different settings for weekdays and weekends. We recommend the pre-sets (shown in the table below), since they can reduce your heating/cooling expenses. Heat Cool Wake - Set to the time you wake up and the °... - Page 6 Program schedule override (temporary) 1 Press to adjust the temperature. 2 Once at the desired setpoint temperature, no further action is needed. The new setpoint temperature will be held until the next scheduled time period begins. For more information on schedule time periods, see “Program Schedule”...
-
Page 7: Adaptive Intelligent Recovery
Adjusting keypad lockout 1 Press Menu on the thermostat. to go to LOCK. Press Select. 2 Press to go to OFF, PART, or ON, and then press Select. 3 Press OFF: Unlocked, and full access allowed. PART: Partial lockout, allowing only the temperature to be changed. ON: No access allowed. -
Page 8: Battery Replacement
Battery replacement Batteries are optional (to provide backup power) if your thermostat was wired to run on When the low battery AC power when installed. If your thermostat warning appears, press was not wired to run on AC power, then gently to loosen the batteries are required. - Page 9 Air Filter Reminder 1 The alert icon appears on the Home screen. 2 Press Menu, and then press until display shows ALRT. 3 Press Select to display which alert(s) are Back Select present. Home 4 The message REPL (REPLACE AIR FILTER) appears.
-
Page 10: Troubleshooting
Troubleshooting If you have difficulty with your thermostat, please try the following suggestions. Most problems can be corrected quickly and easily. Display is • Check circuit breaker and reset if necessary. blank • Make sure power switch for heating & cooling system is on. •... - Page 11 5-year limited warranty Honeywell warrants this product, excluding battery, to be free from defects in the workmanship or materials, under normal use and service, for a period of five (5) years from the date of purchase by the consumer. If at any time during the warranty period the product is determined to be defective or malfunctions, Honeywell shall repair or replace it (at Honeywell’s option).
- Page 12 CAUTION: ELECTRICAL HAZARD Can cause electrical shock or equipment damage. Disconnect power before beginning installation. CAUTION: EQUIPMENT DAMAGE HAZARD Compressor protection is bypassed during testing. To prevent equipment damage, avoid cycling the compressor quickly. CAUTION: MERCURY NOTICE If this product is replacing a control that contains mercury in a sealed tube, do not place the old control in the trash.
