Emerson F02/EPI2 Quick Start Manual

Quick Start Guide
VCIOM-08536-US Rev. 0
Base Card
F02/EPI2 Quarter-Turn Electric Actuator
Configurations
CLOSE LIMIT by position
Drive the actuator to
the CLOSE position
using the handwheel
OPEN LIMIT by position
Drive the actuator to
the OPEN position
using the handwheel
CLOSE LIMIT by torque
OPEN LIMIT by torque
CLOSING speed
OPENING speed
% CLOSING torque
% OPENING torque
CW/CCW
BLINKER/local selector
Note:
(*) Factory
PRE-INSTALLATION: See VCIOM-2881 INSTALLATION AND MAINTENANCE INSTRUCTIONS. Not performing the following procedures will invalidate the product warranty.
INSTALLATION: To assemble the actuator onto the valve proceed as follows:
a. Verify proper mounting hardware.
b. Verify proper electrical service to the actuator
c. Lubricate the valve stem with oil or grease to make the assembly easier: pay attention not to contaminate with lubricant the flange surfaces which transmit the actuator torque.
d. Clean the valve flange and remove anything that might prevent a perfect adherence to the actuator flange and especially all traces of grease.
e. Install the actuator onto the valve so that the shaft out put drive enters the groove of the stem extension. This coupling must take place without forcing and only with the weight of the
actuator.
f. Ensure actuator and valve are in same orientation when bolting together.
g. With the handwheel, operate the actuator to verify it moves the valve smoothly.
WARNING
The configuration must be done while the actuator is powered on. As a consequence, all configuration operations must be carried out by specifically qualified personnel for operations on
powered electronic cards. Hazardous voltages may be present. Before connecting power to the actuator, check that the voltages are correct and according to the nameplate data. Improper power
supply will cause permanent damage to the electrical components. Actuator configuration programming requires removal of the actuator cover. Refer to VCIOM-2881 IOM for instructions.
Rotary Switch Settings
Move switch SW4 to position Move switch SW6 to position
indicated in each row indicated in each row
2 1 (*)
0 0
3 1 (*)
1 0
2 0 (*)
3 0 (*)
4 4
6 (*)
5 8
6
2 = 50%
5 = 75%
7 9 = 100% (*)
0 = CW (*)
8
1 = CCW
0 = off (*)
4 1 = Blinker
2 = Loc. Sel.
Quick Start Guide
VCIOM-08536-US Rev. 0
F02/EPI2 Quarter-Turn
Electric Actuator
Base and OM1 Card
Confirm by
SW3 SW3
SW5
Red LED
LED lights up once
LED lights up once
Operate the
actuator to direction
bylocal/remote
control and wait
until it stops by
torque
LED lights up once
F02/EPI2 Base and OM1 Card
F02/EPI2 Base and OM1 Card
Figure 1 Model 063-125
Dip switch Push button
SW3 SW5
Green LED
Power ON
Rotary switch Rotary switch
SW4 SW6
Figure 2 Model 250-500-1000-2000
Dip switch Push button
SW3 SW5
Green LED
Power ON
Rotary switch Rotary switch
SW6 SW4
Table 1.
Operating Times
Operating time (secs 90
Nominal torque
Model
(Nm/lb.in.)
8 6
063 63/600 15 28
125 125/1300 15 28
250 250/2500 15 28
500 500/5100 15 28
1000 1000/9100 24 45
2000 2000/17700 53 100
April 2018
April 2018
Red LED
Enter configuration
Red LED
Enter configuration
) at selected step
o
4
48
48
48
48
80
180
