- Page 1 INSTRUCTION MANUAL Cordless Blower DUB361 Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model DUB361 Capacities Air volume (HIGH) 4.4 m /min Air volume (LOW) 2.6 m /min No load speed (min HIGH 17,000 10,000 Overall length (without long nozzle) 420 mm (with long nozzle) 905 mm Net weight 3.1 - 3.2 kg... - Page 3 A charger that is suitable for one causing fires, personal injury and damage. It will also type of battery pack may create a risk of fire when void the Makita warranty for the Makita tool and charger. used with another battery pack. 29. Use the blower only with specifically designated Tips for maintaining maximum battery packs.
-
Page 4: Functional Description
Tool / battery protection system FUNCTIONAL DESCRIPTION The tool is equipped with a tool/battery protection sys- tem. This system automatically cuts off power to the motor to extend tool and battery life. CAUTION: The tool will automatically stop during operation if the tool or battery are placed under one of the following • Always be sure that the tool is switched off and conditions. In some conditions, the indicators light up. the battery cartridge is removed before adjust- ing or checking function on the tool. Overload protection Installing or removing battery When the tool is operated in a manner that causes it to... - Page 5 Indicating the remaining battery Switch action capacity Only for battery cartridges with the indicator ► 1 . HIGH/LOW button 2. OFF button To start the tool, simply press the "HIGH/LOW" button. ► 1 . Indicator lamps 2. Check button To switch off, press the "OFF" button. To change the tool speed, press the "HIGH/LOW" button. The first Press the check button on the battery cartridge to indi- press on this button is for high speed and the second cate the remaining battery capacity. The indicator lamps press for low speed and then each press on this button...
-
Page 6: Maintenance
Hold the blower firmly with a hand and perform the blowing operation by moving it around slowly. When blowing around a building, a big stone or a vehi- cle, direct the nozzle away from them. When performing an operation in corner, start from the corner and then move to wide area. MAINTENANCE CAUTION: •... -
Page 7: Optional Accessories
► 1 . Screwdriver 2. Brush holder cap Use a screwdriver to remove the brush holder caps. Take out the worn carbon brushes, insert the new ones and secure the brush holder caps. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be per- formed by Makita Authorized Service Centers, always using Makita replacement parts. OPTIONAL ACCESSORIES CAUTION: • These accessories or attachments are recom- mended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 8 Makita Corporation 885330A8 20170106 www.makita.com...
