- Page 1 Halton Vita VSN - Installation and maintenance guide Enabling Wellbeing All rights reserved © Halton...
-
Page 2: Table Of Contents
3.2 Step by step instructions ......................10 3.2.1 Preparing Halton Vita VSN for installation ................10 3.2.2 Installing Halton Vita VSN for Halton Vita OR Space 5............12 3.2.3 Installing Halton Vita VSN for Halton Vita OR Space 7............15 3.2.4 Installing the ceiling system .................... -
Page 3: Introduction
Halton disclaims any and all liability related to this document. Halton gives no explicit or implied warranties in terms of this document. Any permitted use of the information included herein is at your own risk. Halton may amend or replace the information included in this document at its sole discretion without further notice and liability. -
Page 4: Summary Of Changes
2019-10-08 Update in chapter Installing the HEPA filters 2019-12-06 chapters added Safety notes Contact information Installing Halton Vita VSN for Halton Vita OR Space 7 chapter added Updates in Dimensions and weight • Dimension pictures updated • Weight information added... - Page 5 Halton Vita VSN - Installation and maintenance guide 5(31) DANGER OF ROTATING UNIT PARTS! This symbol indicates a hazardous location with a risk of personal injury including death and material damage. DANGER OF OVERHEAD LOADS! This symbol indicates a hazardous location with a risk of personal injury including death and material damage.
-
Page 6: Contact Information
Halton Vita VSN - Installation and maintenance guide 6(31) CAUTION! Risk of personal injury or material damage. Notes NOTE: Notes are statements to which you should pay special attention. 1.5 Contact information You can find the contact details from www.halton.com/contact. -
Page 7: Product Description
Halton Vita VSN - Installation and maintenance guide 7(31) 2 Product description 2.1 Overview Halton Vita VSN is a supply air unit for the Halton Vita OR Space 5 and Space 7 solutions. Applications • Operating rooms in hospitals o Halton Vita OR Space 5 solution... -
Page 8: Function
The fine-tuning of the throw pattern is carried out by Halton. The supply unit size and airflow pattern adjustment are optimised by Halton based on the end-user requirements and specifications. -
Page 9: Structure And Materials
Gasket Cellular polyethylene foam Fixing brackets Galvanised steel 2.4 Further technical details For Halton Vita VSN dimensions and weight see the Dimensions and weight chapter in the technical reference data section. For filter technical data see the chapter in the technical reference data section. -
Page 10: Installation
3 Installation 3.1 Before you start 3.1.1 Installation process The installation of the Halton Vita VSN unit is carried out in the following order: 3.2 Step by step instructions 3.2.1 Preparing Halton Vita VSN for installation This procedure shows how to prepare the Halton Vita VSN supply air units for installation. - Page 11 The choice of the method depends on which way is the easiest on site. NOTE: See step 6 in or step 3 in Installing Halton Vita VSN for Halton Vita OR Space 5 Installing Halton Vita VSN for Halton Vita OR Space 7 6. Determine the correct location in the ceiling of: a.
-
Page 12: Installing Halton Vita Vsn For Halton Vita Or Space 5
Halton Vita VSN - Installation and maintenance guide 12(31) 3.2.2 Installing Halton Vita VSN for Halton Vita OR Space 5 This procedure shows how to install the Halton Vita VSN supply air units on the ceiling. Procedure 1. Install the first module. - Page 13 Halton Vita VSN - Installation and maintenance guide 13(31) 3. Fasten two modules together with M6 type hexagon bolts. 4. Install the third module in the same manner as previous ones. 5. Fasten the modules with M6 type hexagon bolts.
- Page 14 Halton Vita VSN - Installation and maintenance guide 14(31) 6. Install the fourth module and fasten the modules with M6 type hexagon bolts. 7. Install duct connections. NOTE: This step can be omitted, if you have installed duct connections beforehand, on the ground.
-
Page 15: Installing Halton Vita Vsn For Halton Vita Or Space 7
NOTE: See Installing Halton Vita VSN front panels 3.2.3 Installing Halton Vita VSN for Halton Vita OR Space 7 This procedure shows how to install the Halton Vita VSN air supply units on the ceiling. Procedure 1. Install the first module. - Page 16 Halton Vita VSN - Installation and maintenance guide 16(31) 2. Install the second module in the same manner as the first one. The distance between the modules should be 1200...2400 mm. 3. Install duct connections with M6 x 16mm bolts.
- Page 17 Halton Vita VSN - Installation and maintenance guide 17(31) 7. Install the HEPA filters for each module and test them for leaks. NOTE: See Installing the HEPA filters NOTE: If filters will be installed later, attach front panels and protect the unit from dust by using, for example, a plastic sheet.
-
Page 18: Installing The Ceiling System
The T-bar runners are installed below the device. The unit is designed to fit in the standard size of the false ceiling grid. NOTE: For the design of Halton Vita VSN units that are compatible with a different false ceiling system, contact Halton Sales. - Page 19 Halton Vita VSN - Installation and maintenance guide 19(31) Make sure that the upstream challenge injection port is located far enough. The position has to allow mixing of test particles within the air duct. When injecting the test aerosol, ensure that the concentration of the test aerosol is even across the back of the whole filter.
- Page 20 Halton Vita VSN - Installation and maintenance guide 20(31) 4. Fit the filter inside the module. 5. Fit the rest of the filters in the same manner as the first one. 6. Secure the filters with the filter brackets. CAUTION! While tightening the filter brackets, take care no to damage the threads.
-
Page 21: Installing Halton Vita Vsn Front Panels
Halton Vita VSN - Installation and maintenance guide 21(31) What to do next • After installing the HEPA filters, do not switch off the fan to protect the filter underside from dirt and dust accumulation. • Perform an installed filter system leakage test according to the ISO 14644-3 Cleanrooms and associated controlled environments standard. -
Page 22: Maintenance
(filter is damaged) 4.2 Step by step instructions 4.2.1 Removing the Halton Vita VSN front panels Procedure 1. Starting from the outside corner of the unit, open the front panel. There are two openings on the side of the front panel. -
Page 23: Cleaning Halton Vita Vsn
Halton Vita VSN - Installation and maintenance guide 23(31) 3. Remove the rest of the front panels, in the same manner as the first one. 4.2.2 Cleaning Halton Vita VSN Clean the unit with alcohol based disinfectants. CAUTION! Do not wet the filters. Dampening the filter media will permanently decrease the filter efficiency. -
Page 24: Changing The Hepa Filters
Halton Vita VSN - Installation and maintenance guide 24(31) 4.2.3 Changing the HEPA filters Before you start • Switch off the air conditioning system, or close the shut-off damper (if any). • Wear protective equipment. Procedure 1. Remove the front panel. -
Page 25: Technical Reference Data
5 Technical reference data 5.1 Dimensions and weight Halton Vita VSN/A (Halton Vita OR Space 5) Halton Vita VSN/A for Halton Vita OR Space 5 consists of 4-8 modules forming a square or rectangular ring. Halton Vita VSN/A, 3000x3000 Version 4.0... - Page 26 Halton Vita VSN - Installation and maintenance guide 26(31) Halton Vita VSN/A, 3600x3000 Halton Vita VSN/A, 3600x3600 Version 4.0 All rights reserved © Halton...
- Page 27 Halton Vita VSN - Installation and maintenance guide 27(31) Halton Vita VSN/A, 4200x3600 Halton Vita VSN/A, 4200x4200 Weight (kg) 3000x3000 165 3600x3000 204 3600x3600 221 4200x3600 237 4200x4200 271 Version 4.0 All rights reserved © Halton...
- Page 28 Halton Vita VSN/B (Halton Vita OR Space 7) Halton Vita VSN/B for Halton Vita OR Space 7 consists of 2 parallel units. The parallel units consist of 1 or 2 modules. The distance (S=1200...2400) between the parallel units is specified separately for each project.
- Page 29 Halton Vita VSN/B, 3600x600 Weight (kg) 2400x600 84 3600x600 130 Halton Vita VSN/C The Halton Vita VSN supply air module is available as a spare part (VSN/C) for Halton Vita OR Space supply air units. Version 4.0 All rights reserved © Halton...
- Page 30 Halton Vita VSN - Installation and maintenance guide 30(31) Halton Vita VSN/C, 1800x600 Halton Vita VSN/C, 2400x600 Weight (kg) 1800x600 32.5 2400x600 42 Version 4.0 All rights reserved © Halton...
-
Page 31: Filters
High efficiency particulate air (HEPA) filters are widely applied in cleanrooms where high air quality standards are essential. Performance data of HEPA filters Filter compatible with Halton VSN is available in class H14 (European Standard EN 1822-1:2009) with gel gasket. Operating range: •...
