SERVICE MANUAL
Ver. 1.0 2008.12
• The tuner and CD sections have no adjustments.
CD Player section
Signal-to-noise ratio: 120 dB
Frequency response: 10 – 20,000 Hz
Wow and fl utter: Below measurable limit
Tuner section
FM
Tuning range:
CDX-GT930UI: US model:
87.5 – 107.9 MHz
CDX-GT930UI: AEP, UK model:
87.5 – 108.0 MHz
CDX-GT980UI:
87.5 – 108.0 MHz (at 50 kHz step)
87.5 – 107.9 MHz (at 200 kHz step)
CDX-GT937UI:
FM1/FM2: 87.5 – 108.0 MHz (at 50 kHz step)
FM3: 65 – 74 MHz (at 30 kHz step)
FM tuning interval:
CDX-GT980UI:
50 kHz/200 kHz switchable
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 150 kHz
Usable sensitivity: 10 dBf
Selectivity: 75 dB at 400 kHz
Signal-to-noise ratio: 70 dB (mono)
Separation: 40 dB at 1 kHz
Frequency response: 20 – 15,000 Hz
Sony Corporation
9-889-373-01
2008L04-1
Audio&Video Business Group
©
2008.12
Published by Sony Techno Create Corporation
CDX-GT930UI/GT937UI/
(Photo: CDX-GT930UI)
Model Name Using Similar Mechanism
CD Drive Mechanism Type
Optical Pick-up Name
SPECIFICATIONS
AM
CDX-GT930UI: US model/GT980UI:
Tuning range:
CDX-GT930UI: US model:
530 – 1,710 kHz
CDX-GT980UI:
531 – 1,602 kHz (at 9 kHz step)
530 – 1,710 kHz (at 10 kHz step)
AM tuning interval:
CDX-GT980UI:
9 kHz/10 kHz switchable
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 25 kHz
Sensitivity: 26 μV
MW/LW
CDX-GT930UI: AEP, UK model/GT937UI:
Tuning range:
MW: 531 – 1,602 kHz
LW: 153 – 279 kHz
Antenna (aerial) terminal:
External antenna (aerial) connector
FM/AM COMPACT DISC PLAYER
FM/MW/LW COMPACT DISC PLAYER
GT980UI
US Model
AEP Model
UK Model
CDX-GT930UI
E Model
CDX-GT980UI
Russian Model
CDX-GT937UI
NEW
MG-101Z-188//Q
DAX-25A
Intermediate frequency: 25 kHz
Sensitivity: MW: 26 μV, LW: 45 μV
USB Player section
Interface: USB (Full-speed)
Maximum current: 500mA
Power amplifi er section
Outputs: Speaker outputs (sure seal connectors)
Speaker impedance: 4 – 8 ohms
Maximum power output:
52 W × 4 (at 4 ohms)
General
Outputs:
Audio outputs terminal (front/rear)
Subwoofer output terminal (mono)
Power antenna (aerial) relay control terminal
Power amplifi er control terminal
– Continued on next page –
CDX-GT930UI: US model/GT980UI
CDX-GT930UI: AEP, UK model/GT937UI
Advertisement
Table of Contents
Related Manuals for Sony CDX-GT930UI
Summary of Contents for Sony CDX-GT930UI
- Page 1 CDX-GT930UI: US model/GT980UI Separation: 40 dB at 1 kHz Frequency response: 20 – 15,000 Hz FM/AM COMPACT DISC PLAYER CDX-GT930UI: AEP, UK model/GT937UI FM/MW/LW COMPACT DISC PLAYER Sony Corporation 9-889-373-01 2008L04-1 Audio&Video Business Group © 2008.12 Published by Sony Techno Create Corporation...
- Page 2 WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
-
Page 3: Table Of Contents
This compact disc player is classifi ed as a CLASS 1 LASER TABLE OF CONTENTS product. The CLASS 1 LASER PRODUCT label is located on the exterior. SERVICING NOTES ..........CDX-GT930UI: AEP, UK model/GT937UI/GT980UI: GENERAL Location of Controls ............Connections ..............DISASSEMBLY 3-1. Base Panel Assy ............. 12 This label is located on the bottom of the chassis. -
Page 4: Servicing Notes
CDX-GT930UI/GT937UI/GT980UI SECTION 1 SERVICING NOTES EXTENSION CABLE AND SERVICE POSITION NOTE FOR REPLACEMENT OF THE SERVO BOARD When repairing or servicing this set, connect the jig (extension When repairing, the complete SERVO board (Part No. A-1554- cable) as shown below. -
Page 5: General
CDX-GT930UI/GT937UI/GT980UI SECTION 2 GENERAL This section is extracted from instruction manual. • LOCATION OF CONTROLS • CDX-GT930UI: US model Location of controls and basic operations Main unit Disc slot page 14 To insert the disc. Display window Receptor for the card remote... - Page 6 CDX-GT930UI/GT937UI/GT980UI • CDX-GT930UI: AEP, UK model/GT937UI Location of controls and basic operations Main unit Disc slot page 16 To insert the disc. Display window Receptor for the card remote commander SHUF/ PUSH ENTER /SOUND/MENU (front panel release) button page 6...
- Page 7 CDX-GT930UI/GT937UI/GT980UI • CDX-GT980UI Location of controls and basic operations Main unit Disc slot page 14 To insert the disc. Display window Receptor for the card remote commander PUSH ENTER /SOUND/MENU (front panel release) button page 6 SOURCE MODE button page 13, 17, 18...
-
Page 8: Connections
CDX-GT930UI/GT937UI/GT980UI • CONNECTIONS • CDX-GT930UI: US model Source selector (not supplied) Supplied with the CD changer Sélecteur de source Fourni avec le changeur de CD (non fourni) XA-C40 BUS AUDIO IN AUX IN AUDIO OUT REMOTE FRONT RCA pin cord (not supplied) Supplied with XA-C40 Insert with the cord upwards. - Page 9 CDX-GT930UI/GT937UI/GT980UI • CDX-GT930UI: AEP, UK model/GT937UI Note for the antenna (aerial) connecting Remarque sur le raccordement de Opmerking bij de antenne-aansluiting If your car antenna (aerial) is an l’antenne Indien uw auto is uitgerust met een ISO (International Organization for...
- Page 10 CDX-GT930UI/GT937UI/GT980UI • CDX-GT980UI RCA pin cord (not supplied) Supplied with the CD changer Insert with the cord upwards. To auxiliary audio equipment Whether in use or not, route the AUX IN cord such that it does not interfere with driving. Secure with a cord clamp, etc., if the cords...
-
Page 11: Disassembly
CDX-GT930UI/GT937UI/GT980UI SECTION 3 DISASSEMBLY • This set can be disassembled in the order shown below. 3-1. BASE PANEL ASSY (Page 12) 3-2. SUB PANEL ASSY (Page 12) 3-3. CD MECHANISM BLOCK (Page 13) 3-4. DRIVING SECTION (DB-F07) 3-6. SERVO BOARD... -
Page 12: Base Panel Assy
CDX-GT930UI/GT937UI/GT980UI Note: Follow the disassembly procedure in the numerical order given. 3-1. BASE PANEL ASSY two screws (panel F) bracket (PWB) base panel assy two screws (panel F) FLEXIBLE board (36 core) (CN905) (Take care not to pull the two screws (T) -
Page 13: Cd Mechanism Block
CDX-GT930UI/GT937UI/GT980UI 3-3. CD MECHANISM BLOCK CD mechanism block two screws (+PTT 2.6 × 4) CN802 (3P) bracket (CD) screw (+PTT 2.6 × 6) screw (+PTT 2.6 × 6) CNP301 3-4. DRIVING SECTION (DB-F07) screw (+PTT 2.6 × 6) driving section... -
Page 14: Main Board
CDX-GT930UI/GT937UI/GT980UI 3-5. MAIN BOARD screw cord (AUX IN) (+PTT 2.6 × 8) screw (+PTT 2.6 × 10) screw two screws (+PTT 2.6 × 8) cord (USB) (+P 2.6 × 8) two screws (+PTT 2.6 × 12) screw two screws (+PTT 2.6 × 8) CN803 (5P) (+P 2.6 ×... -
Page 15: Chassis (T) Sub Assy
CDX-GT930UI/GT937UI/GT980UI 3-7. CHASSIS (T) SUB ASSY two screws two screws (M 1.7 × 2.5) (M 1.7 × 2.5) chassis (T) sub assy claw 3-8. ROLLER ARM ASSY roller arm assy gear (RA1) spring (RAL) washer spring (RAR) -
Page 16: Chassis (Op) Assy
CDX-GT930UI/GT937UI/GT980UI 3-9. CHASSIS (OP) ASSY chassis (OP) assy tension spring (KF) two coil springs (damper) (natural) coil spring (damper) (green) slider (R) lever (D) gear (LE1) 3-10. CHUCKING ARM SUB ASSY chucking arm sub assy spring Note: Have this portion receive the chassis. -
Page 17: Sled Motor Assy
CDX-GT930UI/GT937UI/GT980UI 3-11. SLED MOTOR ASSY three serration screws (M 2 × 3) sled motor assy spring turn table spring stand Note: Never remove these parts since they were adjusted. stand Note: Place the stand with care not to touch the turn table. -
Page 18: Optical Pick-Up Section
CDX-GT930UI/GT937UI/GT980UI 3-12. OPTICAL PICK-UP SECTION optical pick-up section Note: Be careful not to touch the lens and hologram terminal when removing the optical pick-up section. 3-13. OPTICAL PICK-UP tapping screw (P 1.4) leaf spring (OPS) rack optical pick-up lead screw assy... -
Page 19: Diagrams
CDX-GT930UI/GT937UI/GT980UI SECTION 4 DIAGRAMS 4-1. BLOCK DIAGRAM – MAIN Section – INPUT SELECT/ BOOST AMP ELECTRONIC VOLUME PJ401 (1/2) IC402 PJ401 (2/2) IC401 OUTR2 17 RL+ OUT(RL) AUDIO OUT AUDIO OUTR1 R-CH BUS-RCH REAR MUTE 2 A2 R-CH (REAR) Q181... -
Page 20: Block Diagram -Display Section
CDX-GT930UI/GT937UI/GT980UI 4-2. BLOCK DIAGRAM – DISPLAY Section – DISPLAY CONTROL IC901 FL900 FLUORESCENT INDICTOR TUBE 85 KEY_1 KEY_2 KEY_PUSH MATRIX SYSTEM CONTROL FL_VDD1(+3.3V) S911–916, • LAT TA2 OUT IC303 (2/2) ENC901(2/2), S918–920 DISP_CE • FL_VDD2(+52V) FL_DAT1 DISP CE SYS_CE KEY_IN0... - Page 21 CDX-GT930UI/GT937UI/GT980UI THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. • Waveforms (In addition to this, the necessary note is printed in each block.) – MAIN Board – – DISPLAY Board – For Printed Wiring Boards. For Schematic Diagrams.
-
Page 22: Printed Wiring Boards -Main Section (1/2)
CDX-GT930UI/GT937UI/GT980UI 4-3. PRINTED WIRING BOARDS – MAIN Section (1/2) – • : Uses unleaded solder. • Semiconductor Location Ref. No. Location Ref. No. Location Ref. No. Location MAIN BOARD (SIDE A) D101 (D703) E-10 LED790 H-13 D102 D791 H-13 D103... -
Page 23: Printed Wiring Board -Main Section (2/2)
CDX-GT930UI/GT937UI/GT980UI 4-4. PRINTED WIRING BOARD – MAIN Section (2/2) – • : Uses unleaded solder. PJ401 AUDIO AUDIO AUDIO REAR FRONT MAIN BOARD (SIDE B) (ANTENNA) CNJ101 US,E,MX MODEL (REMOTE IN) CNP102 (BUS CONTROL IN) CNP102 CNJ101 CNP101 PJ401 C227... -
Page 24: Schematic Diagram -Main Section (1/4)
CDX-GT930UI/GT937UI/GT980UI 4-5. SCHEMATIC DIAGRAM – MAIN Section (1/4) – • See page 21 for waveforms. • See page 32 for IC Block Diagrams. MAIN BOARD (1/4) R425 CN804 D837-839 SURGE PROTECTOR FB839 C429 R427 AUX-LCH 4700p FB838 AUX-GND C430 R400... -
Page 25: Schematic Diagram -Main Section (2/4)
CDX-GT930UI/GT937UI/GT980UI 4-6. SCHEMATIC DIAGRAM – MAIN Section (2/4) – • See page 34 for IC Block Diagram. US,E,MX MODEL MAIN BOARD (2/4) FRONT L-CH REAR PJ401 L-CH CN401 FB402 AUDIO AUDIO CL049 AUDIO REAR SUB_OUT REAR FRONT R-CH SUB OUT... -
Page 26: Schematic Diagram -Main Section (3/4)
CDX-GT930UI/GT937UI/GT980UI 4-7. SCHEMATIC DIAGRAM – MAIN Section (3/4) – • See page 21 for waveforms. • See page 34 for IC Block Diagrams. • See page 37 for IC Pin Function Description of IC303. (Page 25) MAIN BOARD (1/4) 35 36 37... -
Page 27: Schematic Diagram -Main Section (4/4)
CDX-GT930UI/GT937UI/GT980UI 4-8. SCHEMATIC DIAGRAM – MAIN Section (4/4) – • See page 35 for IC Block Diagrams. (Page 25) MAIN BOARD (2/4) MAIN BOARD (4/4) 42 43 IC B/D IC602 Q601,602 IC602 USB +5V REG. BD9781HFP HIGH VOLTAGE DETECT/PROTECT L601... -
Page 28: Printed Wiring Board -Base Panel Section
CDX-GT930UI/GT937UI/GT980UI 4-9. PRINTED WIRING BOARD – BASE PANEL Section – • : Uses unleaded solder. S901 S902 CN904 (NOSE DET) RESET 1-879-109- (11) DISPLAY BOARD CN901 (Page 30) CN905 1-879-109- (11) MAIN BOARD CN801 (Page 22) CDX-GT930UI/GT937UI/GT980UI... -
Page 29: Schematic Diagram -Base Panel Section
CDX-GT930UI/GT937UI/GT980UI 4-10. SCHEMATIC DIAGRAM – BASE PANEL Section – BASE PANEL BOARD CN904 CN905 ILL_GND ILL_GND KEY_GND FL_VSS ILL_GND FL_VDD CNVSS FL_VDD2 BUSY(M) FL_F2(-) BUSY(D) FL_F2(-) RESET(M) FL_F1(+) KEY0 FL_F1(+) DISP_RESET ILL+B DISP_CE ILL+B DISPLAY DISP_SO BOARD DISP_SI CN901 (Page 31) -
Page 30: Printed Wiring Board -Display Section
CDX-GT930UI/GT937UI/GT980UI 4-11. PRINTED WIRING BOARD – DISPLAY Section – • : Uses unleaded solder. DISPLAY BOARD (SIDE A) LED906,S911 LED906 (US,E) SHUF/ZAP (AEP,UK,RU) LED905,S918 S919 LED905 LED911 LED902,S919 SOURCE LED915 IC903 LED917 LED902 LED903,S912 /CAT (US) LED904 LED903 (AEP,UK,E,RU) S913... -
Page 31: Schematic Diagram -Display Section
CDX-GT930UI/GT937UI/GT980UI 4-12. SCHEMATIC DIAGRAM – DISPLAY Section – • See page 21 for waveform. • See page 39 for IC Pin Function Description of IC901. DISPLAY BOARD Q924 LED910-917 ISA1235AC1TP-1EF (RING ILLUMINATION) R922 R931 R932 R933 R934 R941 R942 R943... - Page 32 CDX-GT930UI/GT937UI/GT980UI • IC Block Diagrams IC1 TEF6607T/V4/S470,518 (MAIN Board (1/4)) IC401 BD3447AFV-E2 (MAIN Board (1/4)) AMRFIN 1 AMSELOUT2 AMSELOUT1 AMRFDEC 2 TUNER AMIFAGC1 FMIN2 3 AMSELIN2 TUNER FMIN1 4 AMSELIN1 GNDRF 5 VCC2 6 TEST I2C BUS LOGIC, PLLREF AMRFAGC 7...
- Page 33 CDX-GT930UI/GT937UI/GT980UI IC470 NJM4558V-TE2 (MAIN Board (1/4)) A OUT B OUT A –IN A +IN B –IN V– B +IN IC402 NJM2792V(TE2) (MAIN Board (1/4)) GND (L) LIFT AMP CIN (L) COUT (L) OUT (RL) OUT (FL) SIGNAL AMP SIGNAL AMP...
- Page 34 CDX-GT930UI/GT937UI/GT980UI IC201 TDA8588AJ/N2/R1 (MAIN Board (2/4)) OUT–FL– C BUS OUT–FL+ OUT–RL– PGND3 OUT–RL+ IN–RL IN–FL S–GND PROTECTION/ DIAGNOSTIC IN–FR IN–RR AC-GND OUT–RR+ PGND2 OUT–RR– OUT–FR+ STANDBY/ MUTE OUT–FR– CHIP DETECT/ DIAGNOSTIC PGND1 BATTERY TEMPERATURE DIAG DETECTION PROTECTION ENABLE LOGIC SWITCH...
- Page 35 CDX-GT930UI/GT937UI/GT980UI IC703 BA09CC0WFP-E2 (MAIN Board (3/4)) VREF DRIVER IC602 BD9781HFP (MAIN Board (4/4)) SOFT VREF START ERROR LATCH COMPARATOR CURRENT LIMIT DRIVER THERMAL SYNC SHUT DOWN IC621 NJM2903M-TE2 (MAIN Board (4/4)) AOUT AIN– BOUT AIN+ BIN– BIN+...
- Page 36 CDX-GT930UI/GT937UI/GT980UI IC601 TPS2051BDRG4 (MAIN Board (4/4)) CHARGE PUMP CURRENT DRIVER LIMIT UVLO THERMAL SENCE IC620 NJM2377M(TE2) (MAIN Board (4/4)) VREF U.VLO S.C.P ER.AMP 0.52V IC110 BA8271F-E2 (MAIN Board (4/4)) BUS ON BUS.ON SWITCH RESET SWITCH BUS.IN CLK-IN BATTERY BATT B/U-C...
- Page 37 DST SEL0 Destination setting pin 0 FSW IN D/D converter oscillator frequency count control signal input UNI SO SONY bus serial data signal output UNI SI SONY bus serial data signal input UNI CKO SONY bus serial clock signal output BYTE Connect to ground.
- Page 38 CDX-GT930UI/GT937UI/GT980UI Pin No. Pin Name Description TEL ATT Telephone mute detect signal input TEST IN Test mode detect signal input RC IN1 Rotary commander shift key signal input SYSRESET System reset signal output BUS ON Bus on signal output FSW OUT...
- Page 39 CDX-GT930UI/GT937UI/GT980UI DISPLAY BOARD IC901 R5F64116DA01FB (DISPLAY CONTROL) Pin No. Pin Name Description SYS CE Main chip enable signal input Not used. (Open) VDC0 — Connect to capacitor Not used. (Fixed to “L” for external pull-down resistor.) VDC1 — Connect to capacitor...
- Page 40 CDX-GT930UI/GT937UI/GT980UI Pin No. Pin Name Description AVSS — Ground pin Not used. (Open) VREF — Reference voltage power supply pin (+3.3 V) AVCC — Power supply pin (+3.3 V) BLINK Ring LED blink control signal output Normally: “H” FL DAT2...
-
Page 41: Exploded Views
CDX-GT930UI/GT937UI/GT980UI SECTION 5 EXPLODED VIEWS Note: • -XX and -X mean standardized parts, so • Color Indication of Appearance Parts Ex- The components identifi ed by mark 0 they may have some difference from the ample: or dotted line with mark 0 are critical for original one. -
Page 42: Main Board Section
CDX-GT930UI/GT937UI/GT980UI 5-2. MAIN BOARD SECTION not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-1599-523-A MAIN BOARD, COMPLETE (US) 1-835-954-11 CONNECTION CORD FOR AUTOMOBILE A-1599-525-A MAIN BOARD, COMPLETE (E,MX) (AUX IN) -
Page 43: Front Section
CDX-GT930UI/GT937UI/GT980UI 5-3. FRONT SECTION not supplied (DISPLAY board) ENC901 not supplied not supplied not supplied not supplied FL901 not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark X-2342-162-1 BUTTON ASSY (S) (US) -
Page 44: Cd Mechanism Section (Mg-101Z-188//Q)
CDX-GT930UI/GT937UI/GT980UI 5-4. CD MECHANISM SECTION (MG-101Z-188//Q) not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. -
Page 45: Electrical Parts List
CDX-GT930UI/GT937UI/GT980UI SECTION 6 BASE PANEL DISPLAY ELECTRICAL PARTS LIST Note: • Due to standardization, replacements in • RESISTORS When indicating parts by reference num- the parts list may be different from the All resistors are in ohms. ber, please include the board name. - Page 46 CDX-GT930UI/GT937UI/GT980UI DISPLAY Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark LED907 6-502-237-02 LED CL-321YF-D-T (AF/TA) (EXCEPT US,E) R950 1-216-825-11 METAL CHIP 2.2K 1/10W LED908 6-502-237-02 LED CL-321YF-D-T (DSPL/SCRL) (US,E) R951 1-216-845-11 METAL CHIP 100K 1/10W LED908...
- Page 47 CDX-GT930UI/GT937UI/GT980UI DISPLAY MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < VIBRATOR > C215 1-115-340-11 CERAMIC CHIP 0.22uF C219 1-115-340-11 CERAMIC CHIP 0.22uF X901 1-795-313-21 VIBRATOR, CERAMIC (8MHz) C221 1-126-934-11 ELECT 220uF ************************************************************* C223 1-126-964-11...
- Page 48 CDX-GT930UI/GT937UI/GT980UI MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C440 1-126-934-11 ELECT 220uF C622 1-125-972-61 ELECT 100uF C441 1-124-673-85 ELECT 100uF C623 1-124-233-11 ELECT 10uF C442 1-162-927-11 CERAMIC CHIP 100PF C624 1-164-315-11 CERAMIC CHIP 470PF...
- Page 49 CDX-GT930UI/GT937UI/GT980UI MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark D125 6-501-817-01 DIODE MA2J1110GLS0 FB839 1-500-329-21 INDUCTOR, FERRITE BEAD D138 6-501-782-01 DIODE MAZ8180GMLS0 D139 6-501-782-01 DIODE MAZ8180GMLS0 < IC > D301 6-501-656-01 DIODE LBAT54ALT1G D303 6-501-817-01...
- Page 50 CDX-GT930UI/GT937UI/GT980UI MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark Q181 6-551-856-01 TRANSISTOR LTC614TKFP8T146 R117 1-216-821-11 METAL CHIP 1/10W Q271 6-551-856-01 TRANSISTOR LTC614TKFP8T146 R118 1-216-821-11 METAL CHIP 1/10W Q281 6-551-856-01 TRANSISTOR LTC614TKFP8T146 R120 1-216-073-00 METAL CHIP...
- Page 51 CDX-GT930UI/GT937UI/GT980UI MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R360 1-216-845-11 METAL CHIP 100K 1/10W R486 1-216-833-11 METAL CHIP 1/10W (US,RU) R487 1-216-821-11 METAL CHIP 1/10W R361 1-216-845-11 METAL CHIP 100K 1/10W R491 1-216-864-11 SHORT CHIP...
- Page 52 CDX-GT930UI/GT937UI/GT980UI MAIN SERVO SUB PANEL Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R706 1-216-829-11 METAL CHIP 4.7K 1/10W MISCELLANEOUS R707 1-216-829-11 METAL CHIP 4.7K 1/10W ************** R708 1-218-899-11 METAL CHIP 150K 0.5% 1/16W R709 1-218-873-11 METAL CHIP 0.5%...
- Page 53 CDX-GT930UI/GT937UI/GT980UI Ref. No. Part No. Description Remark PARTS FOR INSTALLATION AND CONNECTIONS ************************************** X-2179-431-2 FRAME ASSY, FITTING 2-698-362-01 COLLAR 3-876-675-01 KEY (FRAME) X-3381-154-1 SCREW ASSY (BS4), FITTING (E,MX) X-3382-926-1 SCREW ASSY (BS), FITTING (AEP,UK,IT,RU) 3-349-410-11 BUSHING (EXCEPT US) 3-934-325-01 SCREW, +K (5X8) TAPPING (US,E,MX)
- Page 54 CDX-GT930UI/GT937UI/GT980UI REVISION HISTORY Checking the version allows you to jump to the revised page. Also, clicking the version at the top of the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 2008.12...
