FCP-NA-701, FCP-PA-701
Table 5: User preference settings
Menu item Description
01 Temperature scale
02 User temperature calibration
03 Temperature calibration – remote
sensor
04 Temperature calibration – pipe
sensor
05 Backlight on duration
06 Backlight brightness level
07 Display content
08 Clock format
(available only on FCP-PA-701)
09 Auto Daylight Savings
(available only on FCP-PA-701)
10 Programming mode
(available only on FCP-PA-701)
11 Periods per day
(available only on FCP-PA-701)
12 Use default temperatures after
mode change
13 Default heat mode set temperature
14 Default cool mode set temperature
Table 6: System configuration settings (part 1 of 2)
Menu item Description
21 System type
22 2-pipe FCU with aux heat available
(available only if system type = 2FCU)
23 Available modes
24 HP valve type
(unavailable if system type = HP)
25 Remote sensor location
26 Remote sensor type
27 Pipe sensor type
Setting options
F: Fahrenheit
C: Celsius
Temperature with calibration value. Offset: +/- 5.4°F (+/-
3.0°C)
Temperature with calibration value. Offset: +/- 5.4°F (+/-
3.0°C)
Temperature with calibration value. Offset: +/- 5.4°F (+/-
3.0°C)
10 seconds, 30 seconds, always ON
20, 40, 60, 80, 100
0: ambient temperature + set temperature
1: set temperature only
2: ambient temperature only
12: 12 hour
24: 24 hour
ON: Auto DST on
OFF: Auto DST off
ON: programmable
OFF: manual
1, 2, 3, 4, 5, 6
ON: uses default temperatures
OFF: uses last temperature for each mode
60°F (15.5°C) - Max Heat Set Temp
Min Cool Set Temp - 80°F (27°C)
Setting options
2FCU: 2-pipe fan coil unit
4FCU: 4-pipe fan coil unit
HP: heat pump
H-C: conventional (furnace elect)
Yes
No
2FCU without aux heat:
04: heat and cool without auto
2FCU with aux heat:
03: heat and cool with auto
04: heat and cool without auto
4FCU, HP, or H-C:
01: heat only
02: cool only
03: heat and cool with auto
04 : heat and cool without auto
B: B valve
O: O valve
0: in room
1: in duct
0: type II
1: type III
0: type II
1: type III
7
Default
F
0.0°F (0.0°C)
0.0°F (0.0°C)
0.0°F (0.0°C)
10 seconds
80
0
12
ON
OFF
2
ON
70°F (21°C)
74°F (23.5°C)
Default
4FCU
No
2FCU without aux: 04
2FCU with aux: 03
4FCU, HP, or H-C: 03
B
0
0
0
