Section 2: Installation Planning
Introduction
DANGER
Electrical backfeed. Use only approved switchgear to
isolate generator from the normal power source.
Failure to do so will result in death, serious injury,
and equipment damage.
IMPORTANT NOTE: Connecting this generator to an
electrical system normally supplied by an electric
utility shall be by means of a transfer switch, so as to
isolate the electric system from the utility distribu-
tion system when the generator is operating. Failure
to isolate the electric system by these means will
result in damage to generator and may also result in
injury or death to utility workers due to backfeed of
electrical energy.
NOTE: Only an IASD or qualified, competent installation
contractors, or electricians thoroughly familiar with appli-
cable codes, standards, and regulations should install
this standby electric power system. The installation must
strictly comply with all codes, standards, and regulations
pertaining to installation.
Unit Drawings
Installation Drawings
See
Installation
Drawings. Installation drawings show
weights, dimensions, clearances, exhaust details, con-
nection locations, wiring stub-ups, lifting locations, and
other information. Use the unit specific installation draw-
ings when designing a site installation plan. Thoroughly
read NOTES section of each drawing for important
details.
Wiring Diagrams
Wiring and schematic diagrams show connection points
for control wiring, load wiring, and any service power sup-
ply required for battery chargers, block heaters, etc.
Always use the unit specific wiring diagrams during plan-
ning and installation.
Receiving
Receiving and Unpacking
When applicable, handle shipping cartons and crates
with care to avoid damage. Store and unpack cartons
with correct side up, as noted by label on shipping carton.
Installation Guidelines For Spark-Ignited Stationary Generators
Inspection
Carefully inspect generator and all contents of cartons for
any damage that may have occurred during shipment.
See shipping documentation for any provisions or guid-
ance when damage is incurred. Correct all damage or
deficiencies before installing generator.
Storage Before Installation
(000237)
Long Term Storage
If unit will be stored (or installed and not started) for six
months or more, preserve in accordance with the manu-
facturer's instructions. Contact an IASD to obtain the
Long Term Preservation and Storage Manual (Part No.
0G4018) and the Preservation Checklist (Part No.
0G4018A).
Short Term Storage
Proceed as follows if unit will be stored (or installed and
not started) for less than six months:
•
All units are provided with an enclosure.
•
Place unit on a smooth flat surface. Do not leave
unit on shipping pallet, as it leaves the bottom open
for entry of dirt, debris, insects, rodents, etc.
•
If applicable, cover any exhaust system openings.
•
Leave plastic plugs in fuel connection points.
•
Use anti-rodent plugs and other enclosure features
to prevent entry of birds, small animals, and foreign
objects.
Lifting
Risk of electrocution. Avoid touching overhead
power lines when lifting or hoisting generator.
Failure to do so will result in death or serious
injury.
Personal injury. Excessive weight. Use only
appropriate lifting eyes and lifting equipment to
lift unit. Improper lifting techniques could result in
equipment damage, death or serious injury.
Generators weighing more than 900 lbs (408 kg) require
the correct tools, equipment, and qualified personnel to
be used in all phases of handling and unpacking.
To verify personal safety and prevent damage to the unit,
use only correctly sized equipment intended for safe rig-
ging, lifting, and moving of heavy machinery.
Installation Planning
DANGER
(000245)
WARNING
(000224)
7
