Sealey SA791.V3 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Keep People
instructions
away
1. SAfeTY
WARNING! DO NOT use the nail gun if damaged, has missing parts or is thought to be faulty. Contact your Service Agent.
‰
WARNING! disconnect from the air supply before loading or servicing.
‰
WARNING! Always wear approved eye, face and hand protection when operating the nail gun.
‰
WARNING! Check correct air pressure is maintained and not exceeded. We recommend 60 to 100psi.
‰
DO NOT use the nail gun for a task it is not designed to perform.
8
DO NOT operate the nail gun near flammable substances or flammable containers.
8
DO NOT use the nail gun unless you have been instructed in its use by a qualified person.
8
DO NOT carry the nail gun by the air hose, or yank the hose from the air supply.
8
DO NOT operate the nail gun if you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
DO NOT carry the nail gun with your hand on the power trigger in order to avoid unintentional firing.
8
DO NOT direct the nail gun or the air from the air hose at yourself or others.
8
DO NOT load bent or damaged nails into the magazine.
8
▲ DANGeR! When putting the nail gun down, ensure that the trigger safety slide is not fouled, risking accidental firing.
maintain the nail gun in good condition and replace any damaged or worn parts. Use genuine parts only. Unauthorised
9
parts may be dangerous and will invalidate the warranty.
Keep the air hose away from heat, oil and sharp edges. Check the air hose for wear before each use and ensure that all
9
connections are secure.
only use supplied 18SWG x 15-50mm Brad nails. Ask your Sealey dealer for further supplies.
9
Wear approved safety eye/face shield, ear defenders and hand protection.
9
Follow all workshop safety rules, regulations, and conditions when using the nail gun.
9
maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
9
Keep children and non essential persons away from the working area.
9
When not in use, disconnect from the air supply, remove the strip nails from the magazine and store cased in a safe, dry, childproof
9
location.
WARNING! The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that
‰
may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into
this product, but must be applied by the operator.
2. INTRODUCTION
Professional air nailer with lightweight aluminium body and rubber grip handle. Safety trigger device to prevent accidental firing of nails.
Supplied in storage case with oiler and starter pack of nails.
3. SPeCIfICATION
Model No: ..............................................................SA791.V3
nail Capacity:. ..............................................10-50mm 18SWG
maximum Pressure:.. ..................................................... 100psi
operating Pressure ...................................................60-100psi
Air Inlet Size:. .............................................................. 1/4"BSP
noise Power: ............................................................... 99dB(A)
noise Pressure: ........................................................... 92dB(A)
Vibration: .................................................................... 2.8m/s²
Uncertainty: ................................................................ 1.5m/s²
© Jack Sealey limited
10-50MM CAPACITY AIR NAIL GUN
model no:
Wear protective Wear safety
gloves footwear
Original Language Version
SA791.V3
Wear eye
Wear ear
protection
protection
SA791.V3 Issue 1 29/10/19
