Sealey SA791.V2 Instructions

thank you for purchasing a Sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to
Keep People
instructions
away
1. Safety
Warning! DO nOt use the nail gun if damaged, has missing parts or is thought to be faulty. contact your service Agent.
‰
Warning! disconnect from the air supply before loading or servicing.
‰
Warning! Always wear approved eye, face and hand protection when operating the nail gun.
‰
Warning! check correct air pressure is maintained and not exceeded. We recommend 60 to 100psi.
‰
DO nOt use the nail gun for a task it is not designed to perform.
8
DO nOt operate the nail gun near flammable substances or flammable containers.
8
DO nOt use the nail gun unless you have been instructed in its use by a qualified person.
8
DO nOt carry the nail gun by the air hose, or yank the hose from the air supply.
8
DO nOt operate the nail gun if you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
DO nOt carry the nail gun with your hand on the power trigger in order to avoid unintentional firing.
8
DO nOt direct the nail gun or the air from the air hose at yourself or others.
8
DO nOt load bent or damaged nails into the magazine.
8
▲ Danger! When putting the nail gun down, ensure that the trigger safety slide is not fouled, risking accidental firing.
maintain the nail gun in good condition and replace any damaged or worn parts. use genuine parts only. unauthorised
9
parts may be dangerous and will invalidate the warranty.
Keep the air hose away from heat, oil and sharp edges. check the air hose for wear before each use and ensure that all
9
connections are secure.
only use supplied 18sWG x 15-50mm Brad nails. Ask your sealey dealer for further supplies.
9
Wear approved safety eye/face shield, ear defenders and hand protection.
9
follow all workshop safety rules, regulations, and conditions when using the nail gun.
9
maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
9
Keep children and non essential persons away from the working area.
9
When not in use, disconnect from the air supply, remove the strip nails from the magazine and store cased in a safe, dry, childproof
9
location.
Warning! the warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that
‰
may occur. it must be understood by the operator that common sense and caution are factors which cannot be built into
this product, but must be applied by the operator.
‰ Warning! – risk of Hand arm Vibration injury.
this tool may cause Hand Arm Vibration syndrome if its use is not managed adequately.
this tool is subject to the vibration testing section of the machinery directive 2006/42/ec.
this tool is to be operated in accordance with these instructions.
measured vibration emission value (a): . . . . . . . . . . . . . 2.2m/s²
uncertainty value (k): . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1m/s²
Please note that the application of the tool to a sole specialist task may produce a different average vibration emission. We recommend that a
specific evaluation of the vibration emission is conducted prior to commencing with a specialist task.
A health and safety assessment by the user (or employer) will need to be carried out to determine the suitable duration of use for each tool.
nB: stated Vibration emission values are type-test values and are intended to be typical.
Whilst in use, the actual value will vary considerably from and depend on many factors.
such factors include; the operator, the task and the inserted tool or consumable.
nB: ensure that the length of leader hoses is sufficient to allow unrestricted use, as this also helps to reduce vibration.
the state of maintenance of the tool itself is also an important factor, a poorly maintained tool will also increase the risk of Hand Arm Vibration
syndrome.
Health surveillance.
We recommend a programme of health surveillance to detect early symptoms of vibration injury so that management procedures can be
modified accordingly.
© Jack sealey limited
instructions for
air nail gun 15-50mm capacity
model no:
Wear protective Wear safety
gloves footwear
Original Language Version
Sa791.V2
Wear ear Wear eye
protection protection
sA791.V2 | issue 4 06/04/17
