90 K (in case of room temperature 30°C) Dimensions (W) 80 x (D) 170 x (H) 260 mm Cord length L = 1.7 m Weight Approx. 350 g ( Without cord and Without Nozzle ) Supplied accessory EH-ND63 Set nozzle...
3 TROUBLESHOOTING GUIDE Refer to WIRING CONNECTION DIAGRAM. < TROUBLE > < REMEDY > < CHECK > Main Body does not <CHECK POWER CORD> Replace the MOTOR operate Check the conductivity of POWER CORD. HEATER ASSEMBLY Replace the MAIN SWITCH <CHECK MAIN SWITCH>...
4. Disassembly and Assembly Instructions 4.1. Disassembly Instructions (1) Take off NOZZLE as same direction as below. (4). Take off HANDLE AB then take out CLICK RING and SWIVEL RING method as below. (2). Remove 2 TAPPING SCREWS at HOUSING A (5).
4.2 Assembly Instructions (1) Install MOTOR HEATER ASSEMBLY (4) Insert an AIR OUTLET GRILL into HOUSING A as below drawing. into an AIR OUTLET RING by fix position as below. Small rib Large rib (2) Install HOUSING A method as below. (5) Insert an AIR OUTLET RING into Main Body by fix position as below.
6. Schematic Diagram EH-ND63 Option for Code Main Sw. Off "0" Cool "1" Heat Protection "2" Turbo "3" Symbol Part name Specification Code : Code : 605/655/685/695/865 L/415/615/645/62B 0.22 mF, 275V CAPACITOR NOT USE 0.1 mF, 50VDC CAPACITOR (FOR MOTOR)
7.2 Parts List for EH-ND63 Ref. Safety Part No. Part Name & Description Q'ty Remarks EHND63HSPW HOUSING AB (ROUGE PINK) FOR OTHER EHND63HS41PW HOUSING AB (ROUGE PINK) FOR -P415 : INDONESIA EHND63HS64PW HOUSING AB (ROUGE PINK) FOR -P645 : VIETNAM...
