Page 1
110 to 240 volts, 50 to 60 Hz Weight: 4.2 Kg/9.3 lb. Dimensions (W x H x D): 432 x 72 x 336 mm 17.01” x 2.84” x 13.23” Serial. NO. THE ROTEL CO., LTD. Beginning SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU, Y-400A-0705/pdf TOKYO 150-0045, JAPAN...
Page 2
Appearance RVE-1060 VIDEO ENHANCER RVE-1060 STANDBY 480p/576p 720p 1080 i INPUT OUTPUT COMPOSITE S-VIDEO 12V TRIG EXT REM COMPUTER SERIAL MON OUT MON OUT MON OUT VIDEO VIDEO 1 VIDEO 2 VIDEO 3 VIDEO 4 HDMI HDMI COMPONENT IN...
Page 9
Addendum List for Black and Silver RVE-1060 SYMBOL PARTS DESCRIPTION 011 FP-620-B BLACK PANEL ASSY 011 FP-620-S SILVER PANEL ASSY 011 VA3-01A00 H/S PANEL H80 012 RV4-09A00 PUSH BUTTON 14F (BLK) 012 RV4-09A01 PUSH BUTTON 14F (SLV) 012 TB3-18A00 TACT BUTTON 16 KEY (BLK)
Page 10
RVE1060 Upgrade procedure 1. Extract the program zip file in a temporary folder. And save "Fsw.exe" and "SELF100.ini" 2. Power ON the RVE1060 and set the menu of " Upgrade" in "Others Setup" menu to "Yes". 2. Execute "FSW.exe". It is appeared blow screen in the PC. 3.
Page 11
8. Click "Write" button placed next to "Connect" button and push "y" button when message window shows. 9. "Write" to execute from Block 1 to Block 11 automatically. 10. After finshing "Write", then the total writing time will be displayed in the window. 11.
