- Page 1 MP3 & WMA Playback Encoding Function Support High Speed Transfer Via USB 2.0 FM Reception Function Mass Storage Hard Disk 9 Languages Support AH68-01296F (Rev 0.0) Built-in 20GB HDD...
-
Page 2: Table Of Contents
Contents Preparations Safety Instructions ...4 Battery Charger Safety ...6 Charging the Battery ...7 Features ...8 Components...11 Location of Controls (yepp) ...12 Location of Controls (Remote Control) ...13 Connection to Computer Connecting yepp to PC ...14 Manual Installation of USB Driver ...18 Disconnecting the USB cable ...22 Using yepp station ...23 Transferring Music to Your yepp ...28... -
Page 3: Safety Instructions
Safety Instructions Please read and understand all the instructions to avoid injury to yourself and damage to the device Do not expose to extreme Do not apply excessive pressure temperatures (above 95°F or to the device. Do not drop the below 23°F). -
Page 4: Battery Charger Safety
Battery Charger Safety CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN The uninsulated parts inside the charger could cause electric shock. For your safety, do not open the case of the charger. Read this User Manual to prevent any problems that may occur while using the charger. - Page 5 Mass Storage Hard Disk You can use the built-in hard drive to store your entire music library, plus use it as an external drive on your PC to store other data files. Encoding Function Support You can convert music from CDs, cassettes, and radio into MP3 files without a PC.
-
Page 6: Components
High-Fidelity Sound The player has a built-in equalizer to adjust sound to your preference. Built-in Rechargeable Li-Polymer Battery The built-in rechargeable lithium battery provides up to 10 hours of play time. Components Remote Control Earphones Player User Manual Charger Installation CD Model YP-900 GS Built-in memory... -
Page 7: Location Of Controls (Yepp)
Location of Controls USB port socket/ Charger terminal LINE IN jack HOLD switch Reset hole MODE/REC button Location of Controls (yepp) Earphone jack/ Remote control jack Display panel Power On/Off Play/Pause/Skip/Fast Search button MENU button Volume control/Search wheel Reset the player by pressing the reset hole using a pointed object such as a safety clip. -
Page 8: Connecting Yepp To Pc
Connecting yepp to PC Be sure to install yepp station before you connect the yepp player to your PC. If the "Add New Hardware Wizard" appears, click [Cancel] and then install yepp station. System Requirements. Installing software Your PC system must meet the following requirements: Insert the Installation CD into CD-ROM drive. -
Page 9: Manual Installation Of Usb Driver
If the USB driver does not install automatically, restart your PC and try again. Once the USB driver is installed, "SAMSUNG YP-900" or "USB Mass Storage Device" appears in Device Manager. How to check USB driver How to check USB driver... -
Page 10: Manual Installation Of Usb Driver
Manual Installation of USB Driver If the USB driver has been installed successfully, skip to page 23 on "Using yepp station". Refer to the following procedure only if the USB driver is not installed automatically. Check the device manager. Windows 98,ME: Control Panel System Device Manager... - Page 11 In Windows 98 SE Click [Next] button in the series of windows that appear. Insert the Installation CD-ROM into the CD-ROM drive, and then click [Browse]. Select the "Drivers" folder on the CD-ROM, and then click [Next]. You must reboot your computer to complete the installation.
-
Page 12: Disconnecting The Usb Cable
Disconnecting the USB cable After completing the file transmission, you must disconnect the cable in the following way: Double-click on the green arrow Select the USB device, and then in the taskbar on the bottom press the [Stop] button. right of the window. Disconnect the USB cable. - Page 13 Click on the HELP button to select the desired item. yepp station Help: Provides detailed help information. SAMSUNG Web Site: Takes you to the Samsung website. Gracenote Web Site: Takes you to the Gracenote website. Option: You can set the yepp station as your default media player.
- Page 14 Run yepp station. Click on the Option button to select the desired item. General When AUTO CD PLAY is selected, standard CDs will be played by yepp station. File Types Select the checkbox to make yepp station the default player for MP3, WMA, CDA, and WAV files. For detailed operation instructions, refer to Help in yepp station.
-
Page 15: Transferring Music To Your Yepp
Transferring Music to Your yepp To play back music files (mp3, wma) stored in your PC using your yepp, transfer those music files to your yepp, using the yepp station, by following these steps: 1. “Adding Music Files” 2. “Transferring Music Files” 3. -
Page 16: Creating A Playlist
2. Transferring Music Files 1. Select the music files to be transferred in your Playlist or My Library. 2. Click DEVICE CONTROL ( A Transfer window will appear. 3. Click TRANSFER. The music files you have selected will be transferred to the yepp player. Transferred music files are found in the folder System\MUSIC\ under the YEPP(E:) or YEPP(F:) drive in Windows Explorer. -
Page 17: Listening To Music With Yepp
Listening to Music with yepp Be sure that your yepp is charged, and properly connect the earphones. After the transfer from yepp station, be sure that the playlist exists before listening to the music files. Turning Power On and Off Power On: Press and hold the √»... -
Page 18: Changing Modes
Changing Modes √ While in Stop mode, briefly press the MODE/REC button. Each time the button is pressed, the mode toggles between "Music" and "FM". Music Mode Music 0001 FLAT christmas miracle NoArtist : NoAlbum 128 K 00:01 44.1 Loop Repeating FM Mode During playback, briefly press the MODE/REC button on the main unit at the start point of the... -
Page 19: Encoding Mp3S
Encoding MP3s While in Music mode, use the Line-In cable to Before you begin encoding, verify connect the main unit's LINE IN jack and the that the battery is fully charged, otherwise your encoding may not LINE OUT jack of your external audio device. complete successfully. -
Page 20: Searching Within Music Files
Searching Within Music Files Searching for Specfic Parts During Playback When playing a VBR file, even if During playback, pull and hold the œœ / √√ button to you press œœ within 5 seconds forward or reverse search the currently playing file. after the start of playback, the previous song may not be played. -
Page 21: Listening To Fm Radio
Listening to FM Radio Switching to FM Mode Music Press the MODE/REC button in stop mode. 0002 FLAT christmas miracle NoArtist : NoAlbum 00:25 Tuning into a Station Automatically Pull and hold the œœ / √√ button. You can locate a station automatically. 89.10 Searching Down Tuning into a Station Manually... -
Page 22: Encoding Fm
Encoding FM Press the MODE/REC button during FM reception. The current FM broadcast will be encoded into an MP3 file. Press the MODE/REC button again. Encoding stops and the file is created. Files are stored in the order of M001, M002, M003, etc., and will stop when memory becomes "Full". -
Page 23: Managing Files
Managing Files Changing Playlist In the MENU, use the Search wheel to select Set Playlist, and then press the MENU button. In the Set Playlist, use the Search wheel to select Change Playlist, and then press the MENU button. Use the Search wheel to select the file you want to change, and then press the MENU button once. - Page 24 Searching for and Selecting Music Files In the MENU, use the Search wheel to select the music file search and add method you want. The Search function is not supported for files having no ID3 Tag Information. Search Title: Shows the song title from the ID3 tag 2.
-
Page 25: To Playback Repeatedly
To Playback Repeatedly In the MENU, use the Search wheel to select yepp Setup, and then press the MENU button. In yepp Setup, use the Search wheel to select Repeat, and then press the MENU button. In Repeat, use the Search wheel to select the desired mode, and then press the MENU button to confirm the selection. -
Page 26: Setting Recording
Setting Recording In the MENU, use the Search wheel to select yepp Setup, and then press the MENU button. Use the Search wheel to select Record option, and then press the MENU button. Use the Search wheel to select Sampling Rate, Bit Rate, and Monitor Volume, and then briefly press the MENU button to make the desired recording setting. -
Page 27: Setting My Options (Screen Setting)
Setting My Options (Screen Setting) Setting Configuration In the MENU, use the Search wheel to select yepp Setup, and then press the MENU button. Use the Search wheel to select Configure, and then press the MENU button. Use the Search wheel to move to the option you want, and then press the MENU button to select it. -
Page 28: Restoring Default Settings
Scroll Speed Use the Search wheel to set Scroll speed. The setting range of the scroll speed, which adjusts the speed of the track title flow, is 0 to 9. Contrast Use the Search wheel to set Contrast. The setting range of the contrast, which adjusts the brightness of the screen, is 0 is 9. -
Page 29: Menu Table
MENU Table Set Playlist Search Title Search Artist Search Genre Search Album Change Playlist Edit Playlist Go up Press the MENU button to enter MENU mode. Use the MENU button to select and use the Search wheel to navigate. MENU Press the MODE/REC button to go to the upper menu. -
Page 30: Troubleshooting
Troubleshooting The player doesn't work. There is nothing showing on the display panel. Check the battery's power level. There is no sound even if I press the Play button in Music mode. Check if there are MP3 or WMA files on the yepp player. Non-playable file format (e.g. -
Page 31: Specifications
Specifications Model YP-900 Processor 90Mips RISC Internal Memory Capacity 20GB(YP-900 GS) Built-in Rechargeable Battery charging time 4 hours Built-in Rechargeable Battery Capacity 1300mAh Voltage 3.7V (Li-Polymer Rechargeable Battery) Playing time Maximum Operating Time: 10 hours Dimensions/Weight 64.6 106.5 19.8 mm/165g Case Aluminum/Plastic File Transfer Speed...
