YP-55 Quick Guide

Location of Controls

MENU/Loop Repeating Button
MODE
Volume Button
VOL
Display
Play/Stop/Pause Button
USB Cable
Connection Port
Battery Cover

Playing Music

When you press the button, the yepp logo appears and a music/voice file is played.
Stopping Music
When you press the button while playing, the music stops. If no buttons are pressed within 10
seconds (changes depending on settings), the yepp automatically powers off.
You can also turn off the power by pressing and holding the
1
Page 2
Voice Recording Button
REC / ENC
Neck strap Hook
Microphone
Move to Track/
Speed Search Lever
WOW Button
Earphone Jack
ENC Jack
Hold Switch
button.

Connecting the USB cable

Before connecting yepp to PC, make sure to install USB driver.
1
Plug one end of the USB cable into the USB port
on the back of the PC.
2
Connect the opposite end of the USB cable to the
USB cable port on the bottom of the yepp.
If you disconnect the USB cable from your PC while
implementing a command or initializing during USB driver
installation, your PC may not function correctly.
The yepp will automatically turn on.
3
USB driver is installed with a message saying that
it is searching for a new device. You may not see
the display screen during installation. Go to the
device manager to check that installation
has been successfully completed.
.
4
Upon installation of the USB driver
"SAMSUNG YP-55"
will appear in the
[System Properties] [Device Manager].
2
