- Page 1 SeQual Workhorse-8 ® PSA Oxygen Concentrator System INSTRUCTION MANUAL WORKHORSE SERIES...
-
Page 2: Table Of Contents
Tables of Contents 1.0 Introduction GENERAL CAUTIONS, WARNINGS AND HAZARDS PATENTS, TRADEMARKS AND COPYRIGHT 2.0 Installation OXYGEN HOOK-UP COMPRESSOR INLET FILTER 3.0 Operation GENERAL 4.0 Maintenance GENERAL 5.0 Troubleshooting GENERAL 6.0 Technical Data SPECIFICATIONS DRAWINGS AND SCHEMATICS 7.0 Service Parts SERVICE PARTS REPLACEMENT TUBING TECHNICAL SUPPORT... - Page 3 List of Figures and Tables Table 6.1: Workhorse-8 Specifications Figure 6.1: Mechanical Outline Drawing - Workhorse-8 Table 7.1: Workhorse-8 Service Parts Table 7.2: Replacement Tubing...
-
Page 5: Introduction
Optionally, an oxygen monitor may be installed to continuously monitor the system’s output. Typical applications for the Workhorse Oxygen Concentrator include aquaculture and ozone generation for water treatment. AirSep can supply oxygen systems ranging in capacity from 8 SCFH to 5,500 SCFH). CAUTIONS, WARNINGS AND HAZARDS Oxygen is a powerful oxidizing agent. -
Page 6: Patents, Trademarks And Copyright
AirSep Corporation PATENTS, TRADEMARKS AND COPYRIGHT The Workhorse Oxygen Concentrator is protected by the following US Patents: ■ 4,925,464 ■ 5,112,367 ■ 5,114,441 ■ 5,268,021 ■ 5,366,541 ■ 5,593,478 ■ Re. 35,099 ■ Other patents pending Workhorse-8 Instruction Manual... -
Page 7: Installation
AirSep Corporation 2.0 Installation A wall bracket has been supplied with the system. Install the bracket on a sturdy vertical surface using a level. Attach the bracket with bolts or screws capable of supporting the unit. The backplate of the unit has large through holes for sighting in the wall bracket’s hanger screws. -
Page 8: Compressor Inlet Filter
AirSep Corporation Oxygen is a powerful oxidizing agent. Material that burns in air and even some material that will not burn in air are easily ignited and burn rapidly in high concentrations of oxygen. For safety concerns, all possible sources of ignition must be kept away from the oxygen concentrator and preferably out of the room in which it is being used. -
Page 9: Operation
100% and zero volts relating to 0%. Audible and visual alarms, automatic phone dialers and digital oxygen purity displays that directly interface with the nine pin connector are available as accessories. Contact AirSep for additional information.] [ ] Applies to models with optional oxygen monitor. -
Page 11: Maintenance
AirSep Corporation 4.0 Maintenance GENERAL The Compressor Inlet Filter should be changed approximately every 4,000 hours of operation. Filter change frequency is dependent on environmental conditions and may vary. Compressors require a rebuild after 5,000 to 12,000 hours of operation depending on environmental conditions. -
Page 13: Troubleshooting
For the specific psig measurements, please compare to readings when the unit was new. Visit www.airsepcpd.com or contact AirSep. Generally, if the pressures are low and the concentration is low, the order of checking 1. Does the intake filter on the compressor need to be changed? 2. - Page 14 2-4 RPM, so it can be timed for 15 or 30 seconds, or a full rotation can be timed. Compare to the time marking (in seconds) on the side of the gear motor or contact AirSep for the correct RPM. 3. Is the ATF contaminated with water or oil (if an oil-lubricated...
-
Page 15: Technical Data
AirSep Corporation 6.0 Technical Data SPECIFICATIONS Workhorse-8 Performance Data Product Flow 8 SCFH (.21 Nm /hr or 3.8 LPM) Oxygen Delivery Pressure 9 psig (62 kPa or 0.62 barg) Product Concentration 90% +3%/-5% Product Dew Point -100°F (-73°C) Dimensions (W x D x H) -
Page 16: Drawings And Schematics
AirSep Corporation DRAWINGS AND SCHEMATICS 14 [36] FILTER/SILENCER HEAT EXCHANGER FLOWMETER COMPRESSOR 14 [36] POWER CORD 17 [43] O2 MONITOR POWER SWITCH 18 [46] HOUR METER PRESSURE GAUGE SIDE VIEW FRONT VIEW Figure 6.1: Mechanical Outline Drawing - Workhorse-8 Workhorse-8 Instruction Manual... - Page 17 AirSep Corporation 7.0 Service Parts Service parts listed below can be obtained directly from AirSep. Tubing can generally be obtained locally; specifications are listed below. Always replace tubing with equal or better specifications. Other parts are not considered regular service items.
-
Page 18: Replacement Tubing
TECHNICAL SUPPORT For assistance in troubleshooting or repairing the unit, or to order replacement parts, contact the AirSep Commercial Products Service Department by telephone. In the USA or Canada, call 1-800-320-0303. Outside the USA or Canada, call (716) 691- 0202. Send fax inquiries anytime to (716) 564-2717. Address written inquiries to:... - Page 20 © 2019 AirSep Corporation. All Rights Reserved. AirSep reserves the right to discontinue its products, or change the prices, materials, equipment, quality, descriptions, specifications and/or processes to its products at any time without prior notice and with no further obligation or consequence.
