Reference manual
DOC.RM.BQC54.E Rev: 1
February, 2016
Bettis Q-Series Valve Actuator
QC54, Foundation Fieldbus Control Module
www.emerson.com/bettis

Advertisement

Table of Contents
loading

Related Manuals for Emerson Bettis Q Series

Summary of Contents for Emerson Bettis Q Series

  • Page 1 Reference manual DOC.RM.BQC54.E Rev: 1 February, 2016 Bettis Q-Series Valve Actuator QC54, Foundation Fieldbus Control Module www.emerson.com/bettis...

  • Page 2: Table Of Contents

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 CONTENTS A ESSENTIAL INSTRUCTIONS 2 Installation Before you start .......... 3 Introduction ..........8 A.2 Orientation (see fig. A1) ......3 Applicable control modules ......8 Applicable control modules ......3 Before starting ..........

  • Page 3: Aessential Instructions

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 ESSENTIAL INSTRUCTIONS READ THIS SECTION BEFORE Applicable control modules PROCEEDING! QC54 - F Fieldbus™ Weather proof oundation QC54 - F Fieldbus™ Non-Incendive oundation Before you start or Non Sparking QC54 - F Fieldbus™...

  • Page 4: Product Integrity

    Therefore: formed by companies or personnel, authorized by Emerson Process Management . • Try not to mount the actuator with the conduit openings or the air entries, pointing Hazardous areas upward.

  • Page 5: Module Description

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Module Description FieldQ™ F Fieldbus™ QC54 Control Module OUNDATION This manual contains installation, operating, and can set input and output configuration parameters. maintenance information for the FieldQ Using the F Fieldbus™ protocol, informa- ™ OUNDATION Fieldbus QC54 control module (Fig. 1).

  • Page 6: F Oundation Fieldbus ™ Communication

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Fieldbus Communication For field bus devices, in addition to providing param- ™ oundation eter definitions and other information required by the The Bettis Q-Series QC54 module uses the F ounda control system to communicate with the device, the Fieldbus™ protocol to communicate with other tion DD may also include methods.

  • Page 7: Related Information

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 1.5.1 Resource Block 1.6.2 Other Related Information The Resource Block contains hardware and elec- Other documents containing information related to tronics information. There are no linkable inputs or the Bettis Q-Series Control module include: outputs to the Resource Block.

  • Page 8: Installation

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Installation Introduction 2.4 Mechanical alignment and mounting of the control module The Bettis Q-Series F Fieldbus™ Control oundation module is a two-wire device powered by the bus. The control module is equipped with an alignment- edge on top of the module.

  • Page 9: Pneumatic Connections

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 2.5 Pneumatic connections 2.6 Electric Connections IMPORTANT 2.6.1 Electrical Input, Fieldbus Interface 1 The actuator/valve combination can move after connecting Voltage range * 9 to 32 volts the air supply. Maximum current 18 mA Reverse polarity pro- 2 Ensure that the QC54 control modules are mounted Unit is not polarity sensitive. tection properly to the actuator to achieve good functioning and Required external...
  • Page 10 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 WARNING: Terminal Control Module compartment Type Label * Do not put the Control module in direct contact with mag- Lockable netic material. This can cause damage or malfunction of the position feedback. Module cover * If the Control Module is used in a manner not specified by the manufacturer, the protection provided by the equip- ment may be impaired. * If required, mount earth wire (1) between top (2) and bot- tom (3) ring of earth wire connection (see figure 2.6). Electrical Button board 2.6.5 Procedure entries: 3/4”NPT...

  • Page 11: Commissioning

    Two versions of the DD-driver files are available for the QC54 module: - QC54 Standard DD Rev 4 - DD files for use with other Foundation FieldBus host systems and tools - QC54 PlantWeb DD Rev 4 - DD files tailored spe- cifically for use with Emerson PlantWeb Systems (DeltaV). These DD drivers are available for download from www.emersonprocess.com/bettis. Please, see the documentation of your host system, "Close"...
  • Page 12 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 3.2.1 Initialization (calibration) using local buttons For "Initialization (calibration) using the local buttons" Closed digital communication is not required but power sup- reassignment ply is necessary (9V to 32V DC). button 1 Press and confirm press the “Status/Auto-Initializa- Status LED tion” button 2 Status LED will blink. Press and 3 Actuator will cycle 2 or 3 times.

  • Page 13: Function Block Assignments

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 3.2.2 Calibration (Initialization) using Bus 3.3.1 Check functioning Command Before function test: 1 Select "Calibration" in Configure tab. - Check or set “Resource Block” to “Auto”. 2 Press the Calibrate button and the transducer - The unit must be connected to a host system and block will be set to "Out of Service"...

  • Page 14: Troubleshooting

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 3.4 Troubleshooting To solve this: 1 Check table 3.4 and try the suggested solution to 3.4.1 “Factory default settings”, using the solve the problem. button board. 2 Check Actuator assembly code (see Installation & To set the control module to its factory default set- Operation Manual Bettis Q-Series Valve Actuator, tings, do the following;...
  • Page 15 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 3.4.4 If the "Open" or "Closed" feedback is 3.4.6 If the device is in Shutdown lost. When the device is in Shutdown, an internal failure 1 Check if the actuator/valve unit is working correctly. has occurred. 2 If it is safe to cycle the actuator, perform the initial- If the internal failure is re-solved, the actuator shut- ization procedure (see §3.2).

  • Page 16: Detailed Configuration

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Detailed Configuration The Bettis Q-Series QC54 Module contains the fol- 4.1.1 General Resource Block parameters according F Fieldbus lowing function blocks: ™ oundation Block Index Protocol Resource 1000 The resource block parameters with index number 1 Transducer 1100 to 41, are setup according to F...
  • Page 17 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 4.1.4 Alerts 2 Maintenance Alerts The Bettis Q-Series QC54 Control module with A Maintenance Alert indicates a condition within ™ Foundation Fieldbus communication features diag- a device that, if not attended to in the near future ™...
  • Page 18 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 4.1.5 NAMUR NE- 107 Alarms 4.1.4.2 Alert parameter describtion. 1 Alerts - Enabled This section describes the parameter interaction to implement a Bettis Q-Series™ QC54 Control module These parameters are used to enable the indica- to the NAMUR NE-107 requirements as a parameter tion and reporting of each corresponding alert.
  • Page 19 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Then using the EXTENDED parameters in the re- Additional Common Practice Parameters named source block, more detailed information can be made FD_EXTENDED_MAP_n may be used to map available about the conditions for a maintenance multiple sensors or conditions into a single condition person to get to the root of the problem.
  • Page 20 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.1 Bettis Q-Series™ Resource Block Index Name Description Valid Range Initial Value Permission ST_REV Static data revision. Updated when static data is changed 0 to 65535 Read only TAG_DESC Unique description for the resource block within a system, writable by Spaces...
  • Page 21 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.1 Bettis Q-Series™ Resource Block (Continued) Index Name Description Valid Range Initial Value Permission FEATURES Shows the supported resource block options 1 to 6 Read only 0: Unicode strings Description 1: Reports 2: Fault state 3: Soft W Lock 4: Out read back 5. Multi-bit Alarm (Bit-Alarm) Support...
  • Page 22 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.1 Bettis Q-Series™ Resource Block (Continued) Index Name Description Valid Range Initial Value Permission BLOCK_ALM The block alarm is used for all configurations, hardware connection failures and system problems in the block. The cause of the alert is entered in the sub-code. UNACKNOWLEDGED: 0 to 2 Read / Write...
  • Page 23 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.1 Bettis Q-Series™ Resource Block (Continued) Index Name Description Valid Range Initial Value Permission FD_FAIL_ALM This parameter is used primarily to broadcast a change in the FD_OFFSPEC_ALM associated active conditions, which are not masked, for this alarm FD_MAINT_ALM category to a Host System.
  • Page 24 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.1 Bettis Q-Series™ Resource Block (Continued) Index Name Description Valid Range Initial Value Permission PlantWeb Alert parameters FAILED_PRI Designates the alarming priority of the FAILED_ALM. Handling defined 0 to 15 Read / Write by FF. 0: All FAILED alerts disabled 1: All failed alerts suppressed 2: Higher process failed alerts RECOMMENDED_ACTION Enumerated list of recommended actions of the device, displayed with a...

  • Page 25: Transducer Block

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Transducer block 4.2.3 Device configuration. The following five parameter are available to config- The Transducer Block manages data that moves ure the QC54 module for normal operation: between a function block and the device input/out- put (I/O) such as sensors and position switches that Index No Name provide process data for automated process control.
  • Page 26 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 4.2.3.2 CFG_SWITCH_POINTS 2 "Open" and "Closed" end positions. There are two procedures to re-configure the end The Bettis Q-Series QC54 Control module will be ™ positions: shipped with the default feedback characteristic, as per figure 4.3. This feedback characteristic is opera- 1 If it is safe to cycle the actuator, perform the initial- tional after initialization (see chapter 3) and is suitable ization procedure (see §3.2).
  • Page 27 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 4.2.3.3 SHUTDOWN-CFG I/O Failure XD_ERROR = “I/O Failure” Shutdown configuration controls the behavior of the Bettis Q-Series actuator in case of an internal com- ™ munications failure in the QC54 module. This is inde- Delay time as set in SHUTDOWN_STATUS pendent of the FF communication on the bus line.
  • Page 28 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 4.2.3.4 ZERO_PWR_COND 4.2.4.2 Timers This parameter helps identifying whether the device There are 3 timers available in this device: setup matches the actual mechanical configuration of 1 Time in position (TIME_IN_POSITION) the actuator; - Records the time since the last movement. - Fail in Last Position for double acting actuators.
  • Page 29 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Page 29...
  • Page 30 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.2 Bettis Q-Series™ Transducer Block Index Name Description Valid Range Initial Value Permission General Transducer Block parameters ST_REV Static data revision. Updated when static data is changed 0 to 65535 Read only TAG_DESC...
  • Page 31 0: undefined (DA), 1 Self-closing(SA), 2 Self opening(SA) ACT_MAN_ID Actuator manufacturer ID in Foundation Mfg id units. 0x564144 0x564144 Read only Is: Emerson Process Management Valve Automation Division ACT_MODEL_NUM Actuator model number. Depends where it is mounted. All spaces Read / Write Can be set by customer.
  • Page 32 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.2 Bettis Q-Series™ Transducer Block (continued) Index Name Description Valid Range Initial Value Permission Device configuration AUTO_INITIALIZATION Controls the procedure for finding the end positions AUTO_INIT_COMMAND - 0 to 2 Read / Write 0: no action, 1: start auto init 2: start Zero point adjustment, 3: stop auto init Status of the initialization procedure Read only...
  • Page 33 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.2 Bettis Q-Series™ Transducer Block (continued) Index Name Description Valid Range Initial Value Permission Diagnostic configuration FUNCTION_MODULE_ Counts the end position cycles performed by the control module. COUNTER FM_CNT_VALUE (read only) Read only 4294967295 FM_CNT_LIMIT [2] 0 - 1,000,000 Read / Write 4294967295...
  • Page 34 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.2 Bettis Q-Series™ Transducer Block (continued) Index Name Description Valid Range Initial Value Permission Alerts RECOMMENDED_ACTION Enumerated list of recommended actions of the device, displayed with a Read only device alert (can be multiple, see table 4.3) FAILED_PRI Designates the alarming priority of the FAILED_ALM. Handling defined 0 to 15 Read / Write by FF.
  • Page 35 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.3 Bettis Q-Series™ Alerts & recommended actions Alerts Alert default setting Advisory Maintenance Fail Parameter name DeltaV text Recommended actions Internal alerts bad_position_sensor Position Sensor Error Feedback problem, replace Control module when possible bad_temperature_sensor Temperature Sensor Temperature sensor problem, replace Control Error module when possible...
  • Page 36 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.3 Bettis Q-Series™ Alerts & recommended actions (continued) Alerts Alert default setting Advisory Maintenance Fail Parameter name DeltaV text Recommended actions Internal IO failure alert io_failure Internal Io Failure Internal communications are lost, device will act according to shutdown configuration.
  • Page 37 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Table 4.4 Bettis Q-Series™ NAMUR NE- 107 Alarms Parameter Data Type/ Use/Model Store Size Valid Initial Permission Other Range Mnemonic Type Structure Range Value Check FD_CHECK_ACTIVE Bit String C/FD Active Read only FD_CHECK_ALM...

  • Page 38: Operations And Maintenance

    Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Operations and Maintenance Fault state 5.3.1 Software restart There are several Restart options as described The fault state parameter, when active, indicates bellow. This can be done via parameter RESTART a loss of communication to an output block, a fault (index 16) in the Resource block. The following is a promoted to an output block, or loss of a physical...
  • Page 39 Reference manual F Fieldbus Control module OUNDATION DOC.RM.BQC54.E Rev: 1 February, 2016 Page 39...
  • Page 40 The Emerson logo is a trademark and service mark of Emerson P.R.China Berenyi u. 72-100 Electric Co. Bettis is a mark of the Emerson family of companies. T +86 22 8212 3300 Videoton Industry Park All other marks are property of their respective owners.
