Modification or manipulation of the tool other than
described in these operating instructions is not per-
missible.
To avoid the risk of injury, use only original Hilti acces-
sories and additional equipment.
Observe the information printed in the operating instruc-
tions concerning operation, care and maintenance.
The tool and its ancillary equipment may present ha-
zards when used incorrectly by untrained personnel
or when used not as directed.

5. Technical data

Tool
Rated voltage
Weight of tool including battery
Dimensions (LxHxW)
Speed under no load
Speed
Hammering speed
Single impact energy
Chuck
Hammer drilling dia. range in concrete and masonry
Drilling using keyless chuck adaptor for
cylindrical drill bits
- Drilling dia. range in wood
- Drilling dia. range in metal
Screwdriving using bit adaptor
- Wood screws
- HUD screws
Speed control
Forward / reverse
Gearing section sealed to prevent entry of dust and with permanent lubrication (maintenance-free)
Battery
Rated voltage
Battery capacity
Weight
Temperature monitoring
Type of cell
No. of cells
Right of technical changes reserved!
4.2 Important features of the tool
– Vibration-absorbing grip (rubber-padded)
– Smooth speed control
– Gearing and clutch with permanent lubrication
(grease)
– Automatic cut-out carbon brushes
– Forward / reverse rotation
– Function selector switch for rotary drilling/hammer
drilling
24 V –––
- - -
3.8 kg (8.3 lb)
325 x 260 x 92 mm (12.8 x 10.2 x 3.6 in)
980 r.p.m.
900 r.p.m.
0 ... 74 Hz (0 ... 4410 blows per min.)
1.5 joules
TE-C
" to ")
4 to 16 mm ( 1 / 2 /
6 3
" to ")
3 to 13 mm ( 1 / 1 /
8 2
" to ")
3 to 10 mm ( 1 / 2 /
8 5
")
Up to 6 mm ( 1 /
4
")
Up to 6 mm ( 1 /
4
Electronic control switch
Electrical switch with interlock to prevent activation
when running
B24/2.0 NiCd B24/2.4 NiCd
24 V ––– 24 V –––
- - - - - -
24 V × 2.0 Ah 24 V × 2.4 Ah
= 48 Wh = 58 Wh
1.38 kg (3 lb) 1.45 kg (3.2 lb) 1.43 kg (3.1 lb)
yes yes
Nickel-cadmium Nickel-cadmium Nickel-metal hydride
SUB C type SUB C type
20 20
en
B24/3.0 NiMH
24 V –––
- - -
24 V × 3.0 Ah
= 72 Wh
yes
SUB C type
20
