Bradford White 216-B Specification Sheet

Energy Saver Electric Water Heater
Photo is of
M-1-WH6U6SS
Copper Screw Type Immersion Element
(Incoloy type immersion element available upon request)
Bradford White received the highest numerical score among water heater/boiler manufacturers in the proprietary J.D. Power and Associates/ McGraw-Hill Construction 2006 HVAC and Water Heater/Boiler Subcontractor Satisfaction Study
Study based on 882 responses measuring 3 water heater/boiler manufacturers and measures opinions of subcontractors. Proprietary study results are based on experiences and perceptions of subcontractors surveyed in May through July 2006. Your
experiences may vary. Visit jdpower.com
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 5,954,492; 5,761,379; 5,943,984; 5,081,696; 5,988,117; 6,142,216; 5,199,385; 5,574,822; 5,372,185; 5,485,879; 5,277,171;
(B1)5,341,770; 5,660,165; 5,596,952; 5,682,666; 4,904,428; 5,023,031; 5,000,893; 4,669,448; 4,829,983; 4,808,356; 5,115,767; 5,092,519; 5,052,346; 4,416,222; 4,628,184; 4,861,968; 4,672,919; Re. 34,534;
7,270,087 B2. OTHER U.S. AND FOREIGN PATENT APPLICATIONS PENDING. CURRENT CANADIAN PATENTS: 1,272,914; 1,280,043; 1,289,832; 2,045,862; 2,112,515; 2,108,186; 2,107,012; 2,092,105; 2,409,271.
Vitraglas ® is a registered trademark of Bradford White
"Highest in Subcontractor Satisfaction among Water Heater/Boiler Manufacturers"
Residential Wall Hung
The Wall Hung Electric Models Feature:
DOE—All residential storage models above 20 gallon capacity meet or
exceed efficiency requirements of the Department of Energy. ASHRAE
Standard 90.1 b (current standard) and the National Appliance Energy
Conservation Act of 1987 recent amendment effective January 20, 2004
which supercedes all state and local efficiency requirements.
Fully Automatic Controls—Fast acting surface-mount thermostat for
automatic temperature control. Factory installed sensitive manual reset
energy cut-off for safety to prevent overheating.
Direct Heat Transfer With a Single Immersed Element—Transfers heat
directly and efficiently to the water. Screw-in style element.
Vitraglas ® Lining—Bradford White water heater tanks are protected from
the corrosive effects of hot water by an exclusive ceramic porcelain-like
coating. The Bradford White high silica Vitraglas
interior surface for our hot water tanks.
1" Non-CFC Foam Insulation—Surrounds the tank surface, saving energy
by retarding loss of heat (30 gallon model has 2").
Factory Installed Heavy Duty Wall Mounting Bracket—no additional
brackets or modifications required.
Water Connections—3/4" NPT factory installed true dielectric fittings
extend water heater life and eases installation. Located on the bottom for
easier installation.
Protective Magnesium Anode Rod—Provides added protection against
corrosion for long trouble-free service.
Steel Tank—Heavy gauge steel automatically formed, rolled, and welded.
Voltages Available—120V, 208V, 240V, 277V, 480V.
Single Phase Operation Only.
T&P Relief Valve Opening—All models have special tapping on side
of tank.
6 or 10-Year Limited Tank Warranties / 6-Year Limited Warranty on Component Parts.
For more information on warranty, please visit www.bradfordwhite.com
For products installed in USA, Canada and Puerto Rico. Some states do not allow limitations on warranties.
See complete copy of the warranty included with the heater.
® Corporation.
® lining provides a tough
SM .
216-B-0108-A
