P-334WT 802.11g Wireless Broadband Router with Firewall Quick Start Guide Version 3.60 7/2005 Table of Contents ENGLISH DEUTSCH ESPAÑOL FRANÇAIS ITALIANO 中文...
Page 2
ENGLISH DEUTSCH ESPAÑOL FRANÇAIS ITALIANO 中文 P-334WT Quick Start Guide...
Overview The Prestige is a broadband router with a built-in four-port 10/100 Mbps switch. The Prestige makes it easy to set up a small home or office network and share Internet access via a broadband (cable/DSL) modem. You should have an Internet account already set up and have been given most of the following information. Table 1 Internet Account Information Your device’s WAN IP Address (if given): ______________ DNS Server IP Address (if given): Primary _____________, Secondary ______________...
1 Hardware Connections Do the following to make hardware connections for initial setup. WAN Connection Connect your modem to the “WAN” port using the cable that came with your modem. LAN Connection Connect your computer to a "LAN" port using the included Ethernet cable POWER Connection Use the included power adaptor to connect the POWER socket to an appropriate power source (see the User’s Guide for power adaptor specifications by region).
2 Accessing the Web Configurator 1 Launch your web browser. Enter “192.168.1.1” as the web site address. Note: If you do not see the next screen, then please go to section 2 The Password window displays. Enter the password (“1234” is the default) and click Login. 3 Change the password in the screen that follows and click Apply.
3 Internet Access Setup Note: Enter the Internet access information exactly as given to you by your ISP in each wizard screen and then click Next to continue or click Back to return to the previous screen. Current screen information will be lost if you click Back. STEP 1: System Information 1 This screen is optional.
Page 7
OTIST • OTIST (One-Touch Intelligent Security Technology) allows your Prestige to assign wireless clients the Pres- tige’s SSID and static WEP or WPA-PSK encryption settings. The wireless client must also support OTIST and have OTIST enabled. Auto or No Wireless Security A Enter a unique name to identify the Prestige in the wireless LAN.
Page 8
Basic(WEP) Security A Enter a unique name to identify the Prestige in the wireless LAN. B Leave the default setting. The Prestige and wireless client must use the same channel ID. C Select Basic(WEP) security. D You can generate or manually enter a WEP key by either: Entering a Passphrase (up to 32 printable characters) and clicking Generate.
Page 9
Extend(WPA-PSK) or (WPA2-PSK) Security A Enter a unique name to identify the Prestige in the wireless LAN. B Leave the default setting. The Prestige and wireless client must use the same channel ID. C Select WPA-PSK or WPA2-PSK security. D Type a pre-shared key to have a more secure wireless connection than WEP encryption. Type from 8 to 63 case-sensitive ASCII characters.You can set up the most secure wireless connection by configuring WPA in the advanced wireless screen.
Page 10
STEP 3: The wizard attempts to detect which WAN connection type you are using. If the wizard does not detect a connection type, you must select ONE from the drop-down list box. Check with your ISP to make sure you use the correct type: 1 Ethernet 2 PPPoE 3 PPTP.
Page 11
Ethernet Connection A Select Ethernet as your WAN connection type. B Select Get automatically from your ISP if your ISP did not assign you a fixed IP address. Skip to D. Select Use fixed IP address provided by your ISP to give the Prestige a fixed, unique IP address. C Enter a WAN IP address and WAN IP Subnet Mask of the neighboring device, if you know it.
Page 12
PPPoE Connection A Select PPPoE as your WAN connection type. BType a Service Name (Optional), User Name and Password. C Select Get automatically from your ISP if your ISP did not assign you a fixed IP address. Skip to E. Or select Use fixed IP address provided by your ISP to give the Prestige a fixed, unique IP address.
Page 13
PPTP Connection A Select PPTP as your WAN connection type. BType a User Name and Password C Select Get automatically from ISP if your ISP did not assign you a fixed PPTP IP address. Or select Use fixed IP address to give the Prestige a fixed, unique PPTP IP address and subnet mask. D Type a PPTP Server IP Address E Type a Connection ID/Name (if provided) F Select Get automatically from your ISP if your ISP did not assign you a fixed IP address.
Internet Access Setup Complete If you have any Internet access problems, follow the on-screen instructions. Click the Go to Bandwidth Management Wizard (optional) hyperlink to start the bandwidth management wizard; otherwise click Finish. 4 Bandwidth Management Wizard Click the Go to Bandwidth Management Wizard (optional) hyperlink or click the Bandwidth Management wizard option in the Welcome to the ZyXEL Wizard Setup screen.
ENGLISH STEP 1: General Information Select the Active check box. The Prestige does not control the bandwidth allocated to traffic that comes into an interface. Enter the amount of Managed Bandwidth in kbps (2 to 100,000) that you want to allocate for traffic. The recommendation is to set this speed to be equal to or less than the upstream speed of the cable/DSL modem connected to the WAN port of the Prestige.
STEP 3: Priority Setup Select High, Mid or Low priority to control the distribution of bandwidth to selected services. A service with High priority is given as much bandwidth as it needs. If you select services as having the same priority, then bandwidth is divided equally amongst those services.
Page 18
PROBLEM Cannot access the Prestige from my computer (continued). Cannot access the Internet. 5.1 Set Up Your Computer’s IP Address This section shows you how to set your Windows NT/2000/XP computer to automatically get an IP address. This ensures that your computer can communicate with your Prestige. Refer to your User’s Guide for detailed IP address configuration for other Windows and Macintosh computer operating systems.
Übersicht Der Prestige ist ein Breitband-Router mit einem integrierten 10/100 Mbps Schalter mit vier Anschlüssen. Mit dem Prestige können Sie ganz einfach ein kleines Heim- oder Büronetzwerk aufbauen und einen Internetzugang von mehreren Rechnern aus über ein Breitbandmodem (Kabel/DSL) nutzen. Voraussetzung sind ein bestehendes Internetkonto und die folgenden Informationen.
Page 20
1 Anschließen der Hardware Bei der Erstinstallation müssen die folgenden Hardwareverbindungen hergestellt werden. Herstellen der WAN-Verbindung Schließen Sie Ihr Modem mit dem mitgelieferten Kabel an den WAN-Anschluss an. Herstellen der LAN-Verbindung Schließen Sie Ihren Computer mit dem mitgelieferten Ethernet-Kabel an einen "LAN"-Anschluss an. Anschließen an das Stromnetz DEUTSCH...
Page 21
Verbinden Sie den Netzanschluss des Geräts (POWER) mit dem mitgelieferten Netzadapter mit einer geeigneten Stromquelle (eine nach Regionen geordnete Liste der Netzadapter-Spezifikationen finden Sie im Benutzerhandbuch). Die LED-Anzeigen Die LED-Anzeigen befinden sich an der Gerätevorderseite. Sobald das Gerät mit Strom versorgt wird, beginnen die LED-Anzeigen PWR und WLAN zu leuchten.
Page 22
Hinweis: Wenn das folgende Fenster nicht angezeigt werden sollte, gehen Sie zu Abschnitt 2 Auf dem Bildschirm erscheint das Fenster Passwort. Geben Sie das Passwort ein ("1234" ist das Standardpasswort) und klicken Sie auf Login (Anmelden). 3 Ändern Sie im nachfolgenden Fenster das Passwort und klicken Sie auf Apply (Übernehmen).
Wenn Sie auf Back (Zurück) klicken, gehen alle aktuell auf dem Bildschirm vorhandenen Daten verloren. SCHRITT 1: 1 Dieses Fenster ist optional. Sie können einfach auf Next (Weiter) klicken. Der System Name (Systemname) wird für die Identifikation des Prestige benötigt. Geben Sie den Namen des Computers "Computernme"...
Page 24
OTIST Mit der OTIST-Technologie (One-Touch Intelligent Security Technology) kann der Prestige den Wireless-Clients die eigenen Einstellungen für SSID und statische WEP oder WPA-PSK-Verschlüsselung zuweisen. Der Wire- less-Client muss ebenfalls OTIST unterstützen, und die OTIST-Funktion muss aktiviert sein. Automatisch oder Keine Wireless-Sicherheit A Geben Sie einen Namen ein, mit dem der Prestige im Wireless-Lan eindeutig identifiziert wird.
Page 25
Basis-Sicherheit (WEP) A Geben Sie einen Namen ein, mit dem der Prestige im Wireless-Lan eindeutig identifiziert wird. B Belassen Sie die Standardeinstellung. Der Prestige und der Wireless-Client müssen dieselbe Kanal-ID verwenden. C Wählen Sie die Sicherheitsstufe Basic (WEP) (Basis (WEP)). D So können Sie einen WEP-Schlüssel erzeugen oder manuell eingeben: Geben Sie eine Passphrase (mit maximal 32 druckbaren Zeichen) ein und klicken Sie auf Generate (Erzeugen).
Page 26
Erweitern (WPA-PSK) oder WPA2-PSK-Sicherheit. A Geben Sie einen Namen ein, mit dem der Prestige im Wireless-Lan eindeutig identifiziert wird. B Belassen Sie die Standardeinstellung. Der Prestige und der Wireless-Client müssen dieselbe Kanal-ID verwenden. C Wählen Sie die Sicherheit WPA-PSK oder WPA2-PSK. D Geben Sie einen Pre-Shared-Key ein, wenn die Wireless-Verbindung sicherer sein soll als mit einer WEP- Verschlüsselung.
Page 27
SCHRITT 3: Der Assistent versucht zu ermitteln, welche Art von WAN-Verbindung Sie verwenden. Wenn der Assistent keinen Verbindungstyp erkennen kann, müssen Sie aus dem Listenfeld EINEN auswählen. Prüfen Sie bei Ihrem Internetdienstanbieter, ob Sie den richtigen Typ verwenden: 1 Ethernet DEUTSCH...
Page 28
2 PPPoE 3 PPTP Hinweis: Wenn Ihnen Zugangseinstellungen für das Internet vorgegeben wurden, geben Sie diese in die folgenden Felder ein. Anderenfalls werden die Standardeinstellungen belassen. Klicken Sie auf Next (Weiter). Ethernet-Verbindung A Wählen Sie als Ihren WAN-Verbindungstyp Ethernet. B Wählen Sie Get automatically from your ISP (Automatisch vom Internetdienstanbieter laden), wenn Sie von Ihrem Internetdienstanbieter keine feste IP-Adresse zugewiesen bekommen haben.
Page 30
PPPoE-Verbindung A Wählen Sie als Ihren WAN-Verbindungstyp PPPoE. BGeben Sie Service Name (Servicename) (optional), User Name (Benutzername) und Password (Passwort) ein. C Wählen Sie Get automatically from your ISP (Automatisch vom Internetdienstanbieter laden), wenn Sie von Ihrem Internetdienstanbieter keine feste IP-Adresse zugewiesen bekommen haben. Weiter mit E. Wählen Sie Use fixed IP address provided by your ISP (Vom Internetdienstanbieter vorgegebene feste IP- Adresse verwenden), um dem Prestige eine feste und eindeutige IP-Adresse zu geben.
Page 32
PPTP-Verbindung A Wählen Sie als Ihren WAN-Verbindungstyp PPTP. BGeben Sie User Name (Benutzername) und Password (Passwort) ein. C Wählen Sie Get automatically from your ISP (Automatisch vom Internetdienstanbieter laden), wenn Sie von Ihrem Internetdienstanbieter keine feste PPTP IP-Adresse zugewiesen bekommen haben. Oder wählen Sie Use fixed IP address (Feste IP-Adresse verwenden), um dem Prestige eine feste und eideutige PPTP IP-Adresse sowie Subnet-Mask zuzuweisen.
Page 34
Einrichten des Internetzugangs fertig stellen Wenn beim Zugriff auf das Internet Probleme auftreten sollten, befolgen Sie die Anweisungen auf dem Bildschirm. Klicken Sie auf den Hyperlink Go to Bandwidth Management Wizard (optional) (Zum Bandbreitenmanagement-Assistenten), um den Bandbreitenmanagement-Assistenten zu starten oder klicken Sie auf Finish (Fertig stellen).
Page 35
DEUTSCH SCHRITT 1: Allgemeine Informationen Wählen Sie das Kontrollfeld Active (Aktiv). Der Prestige steuert nicht die dem Datenverkehr, der an einer Schnittstelle eingeht, zugewiesene Bandbreite. Geben Sie bei Managed Bandwidth (Verwaltete Bandbreite) einen Wert in kbps (2 bis 100.000) ein, der dem Datenverkehr zugewiesen werden soll.
Page 36
SCHRITT 3: Wählen Sie als Priorität High (Hoch), Mid (Mittel) oder Low (Niedrig), mit der die Verteilung der Bandbreite auf die gewählten Dienste gesteuert werden soll. Alle Dienste mit der Priorität High (Hoch) erhalten soviel Bandbreite wie erforderlich. Wenn mehrere Dienste dieselbe Priorität haben, wird die Bandbreite zu gleichen Teilen geteilt.
Page 37
PROBLEM Ich kann von meinem Computer aus nicht auf den Prestige zugreifen. Ich kann von meinem Computer aus nicht auf den Prestige zugreifen (Fortsetzung). Ich kann nicht auf das Internet zugreifen. 5.1 Einrichten der IP-Adresse des Computers In diesem Abschnitt wird beschrieben, wie Sie Ihren Computer einrichten müssen, damit er bei Windows 2000, Windows NT und Windows XP eine IP-Adresse empfangen kann.
Page 38
5 Wählen Sie Internetprotokoll (TCP/IP) (bei Windows XP auf der Registerkarte Allgemein) und klicken Sie auf Eigenschaften. 6 Das Fenster Eigenschaften von Internetprotokoll (TCP/IP) erscheint (bei Windows XP auf der Registerkarte Allgemein).Wählen Sie IP-Adresse automatisch beziehen und DNS-Serveradresse automatisch beziehen. 7 Klicken Sie auf OK, um das Fenster Eigenschaften von Internetprotokolle (TCP/IP) zu schließen.
Vista previa El Prestige es un router de banda ancha con un switch incorporado de 10/100 Mbps con cuatro puertos. El Prestige hace fácil la configuración de una red doméstica o de oficina y el acceso compartido a Internet a través de módem de banda ancha (cable/DSL).
Page 40
1 Conexiones del hardware Realice lo siguiente para crear conexiones de hardware para la configuración inicial. Conexión WAN Conecte su módem al puerto “WAN” usando el cable que venía con su módem. Conexión LAN Conecte su ordenador a un puerto "LAN" usando el cable Ethernet incluido Conexión de ALIMENTACIÓN ESPAÑOL...
Page 41
Utilice el adaptador de corriente incluido para conectar el zócalo POWER (ALIMENTACIÓN) a una fuente de alimentación apropiada (consulte la Guía del usuario para especificaciones sobre el adaptador de corriente por regiones). Los LEDs Mire a los LEDs del panel frontal. Cuando conecte la alimentación, los LEDs PWR y WLAN se encenderán.
Page 42
Nota: El botón Next (Siguiente) está situado en la parte inferior derecha de cada pantalla. 5 Elija su idioma en el cuadro de la lista desplegable. Haga clic en go (ir). 3 Configuración del acceso a Internet Nota: Introduzca la información de acceso a Internet facilitada por su ISP en cada pantalla del asistente y luego haga clic en Next (Siguiente) para continuar o haga clic en Back (Atrás) para regresar a la pantalla anterior.
Page 43
• None (Ninguna): No tiene seguridad LAN inalámbrica configurada. Si no activa ninguna seguridad inalámbrica en su Prestige, su red es accesible desde cualquier dispositivo de red inalámbrico dentro del alcance. • Seguridad Basic (Básica): WEP (Wired Equivalent Privacy) cifra los cuadros de datos antes de transmitir por la red inalámbrica.
Page 44
Seleccione seguridad Básica (WEP) A Introduzca un nombre único para identificar al Prestige en la LAN inalámbrica. B Deje la configuración predeterminada. El Prestige y el cliente inalámbrico deben usar el mismo ID de canal. C Seleccione seguridad Básica (WEP). D Puede generar o introducir manualmente una clave WEP de los siguientes modos: Introduciendo una Passphrase (Frase secreta) (hasta 32 caracteres imprimibles) y haciendo clic en Generate (Generar).
Page 45
Extienda la seguridad (WPA-PSK) o (WPA2-PSK). A Introduzca un nombre único para identificar al Prestige en la LAN inalámbrica. B Deje la configuración predeterminada. El Prestige y el cliente inalámbrico deben usar el mismo ID de canal. C Seleccione seguridad WPA-PSK o WPA2-PSK. D Escriba una clave pre-compartida para tener una conexión inalámbrica más segura que el cifrado WEP.
Page 46
PASO 3: El asistente intentará detectar qué tipo de conexión WAN está utilizando. Si el asistente no detecta un tipo de conexión, deberá seleccionar UNO en el cuadro de la lista desplegable. Consulte a su ISP para comprobar que utiliza el tipo correcto: 1 Ethernet 2 PPPoE ESPAÑOL...
Page 47
3 PPTP. Nota: Si se le ha facilitado una configuración de acceso a Internet, introdúzcala en los campos siguientes. De lo contrario, deje los valores predeterminados y haga clic en Next (Siguiente) Conexión Ethernet A Seleccione Ethernet como tipo de conexión WAN. B Seleccione Get automatically from your ISP (Obtener automáticamente de su ISP) si su ISP no le asignó...
Page 49
Conexión PPPoE A Seleccione PPPoE como tipo de conexión WAN. BEscriba el Service Name (Nombre de servicio) (Opcional), User Name (Nombre de usuario) y Password (Contraseña). C Seleccione Get automatically from your ISP (Obtener automáticamente de su ISP) si su ISP no le asignó una dirección IP fija.
Page 51
Conexión PPTP A Seleccione PPTP como tipo de conexión WAN. BEscriba un User Name (Nombre de usuario) y Password (Contraseña) C Seleccione Get automatically from your ISP (Obtener automáticamente de su ISP) si su ISP no le asignó una dirección IP PPTP fija. O seleccione Use fixed IP address (Utilizar dirección IP fija) para dar al Prestige una dirección IP PPTP única y fija y una máscara de subred.
Page 53
Configuración del acceso a Internet completada Si tiene algún problema de acceso a Internet, siga las instrucciones en pantalla. Haga clic en el hipervínculo Go to Bandwidth Management Wizard (optional) (Ir al asistente para la administración del ancho de banda (opcional) para abrir el asistente para la administración del ancho de banda;...
Page 54
ESPAÑOL PASO 1: Información general Seleccione la casilla de verificación Active (activa). El Prestige no controla el ancho de banda asignado al tráfico que viene a una interfaz. Introduzca la cantidad de Managed Bandwidth (Ancho de banda administrado) en kbps (2 a 100.000) que desea asignar para el tráfico.
Page 55
PASO 3: Configuración de prioridad Seleccione la prioridad High (Alta), Mid (Media) o Low (Baja) para controlar la distribución del ancho de banda para los servicios seleccionados. A un servicio con la prioridad High (Alta) se le da todo el ancho de banda que necesite. Si selecciona servicios con la misma prioridad, entonces el ancho de banda se divide por igual entre todos esos servicios.
Page 56
PROBLEMA No se puede acceder al Prestige desde mi ordenador. No se puede acceder al Prestige desde mi ordenador (continuación). No puedo acceder a Internet. 5.1 Configurar la dirección IP de su ordenador Esta sección le explica cómo configurar su ordenador para recibir una dirección IP en Windows 2000, Windows NT y Windows XP.
Page 57
4 Seleccione Protocolo Internet (TCP/IP) (en la ficha General en Windows XP) y haga clic en Propiedades. 5 Se abrirá la pantalla Propiedades de Protocolo Internet TCP/IP (la ficha General en Windows XP). Seleccione las opciones Obtener una dirección IP automáticamente y Obtener la dirección del servidor DNS automáticamente.
Présentation Le Prestige est un routeur à large bande avec un commutateur 10/100 Mbps à quatre ports intégré. Le Prestige facilite l'installation d'un petit réseau domestique ou d'entreprise et permet de partager l'accès à Internet via un modem large bande (câble/DSL). Vous devez déjà...
Page 59
1 Connexions matérielles Procédez comme suit pour effectuer les connexions matérielles pour l'installation initiale. Connexion WAN Connectez votre modem au port “WAN” à l'aide du câble fourni avec votre modem. Connexion par réseau local Connectez votre ordinateur à un port "LAN" à l'aide du câble Ethernet fourni Connexion de l'alimentation Utilisez l'adaptateur d'alimentation fourni pour connecter le socket POWER à...
Page 60
2 Accéder au configurateur Web 1 Lancez votre navigateur web. Entrez “192.168.1.1” comme adresse de site Web. Remarque : Si vous ne voyez pas l'écran suivant, allez à la section 2 La fenêtre Password (Mot de passe) s'affiche. Entrez le mot de passe ("1234" est la valeur par défaut) et cliquez sur Login (Connexion).
Page 61
3 Installation de l'accès à Internet Remarque : Saisissez les informations d'accès à Internet exactement telles qu'elles sont fournies par votre fournisseur d'accès à Internet (ISP) dans chaque écran de l'assistant et cliquez ensuite sur Next (Suivant) pour continuer ou cliquez sur Back (Retour) pour retourner à l'écran précédent. Les informations d'écran actuelles seront perdues si vous cliquez sur Back (Retour).
Page 62
OTIST • OTIST (One-Touch Intelligent Security Technology) permet à votre Prestige d'attribuer la SSID du Prestige aux clients sans fil et les paramètres de cryptage WEP statique ou WPA-PSK. Le client sans fil doit aussi supporter OTIST et avoir OTIST activé. Sécurité...
Page 63
Sécurité de base (WEP) A Saisissez un nom unique pour identifier le Prestige dans le LAN sans fil. B Laisser le paramètre par défaut. Le Prestige et le client sans fil doivent utiliser la même ID de canal. C Sélectionnez la sécurité de base (WEP). D Vous pouvez générer ou entrer manuellement une clé...
Page 64
Sécurité (WPA-PSK) ou (WPA2-PSK) étendue A Saisissez un nom unique pour identifier le Prestige dans le LAN sans fil. B Laisser le paramètre par défaut. Le Prestige et le client sans fil doivent utiliser la même ID de canal. C Sélectionnez la sécurité WPA-PSK ou WPA2-PSK. D Tapez une clé...
Page 65
ETAPE 3: L'assistant essaie de détecter le type de connexion WAN que vous utilisez. Si l'assistant ne détecte pas de type de connexion, vous devez en sélectionner UN dans la liste déroulante. Voyez auprès de votre ISP pour être sûr d'utiliser le type correct : 1 Ethernet 2 PPPoE FRANÇAIS...
Page 66
3 PPTP. Remarque : Si vous avez obtenu les paramètres d'accès Internet, saisissez-les dans les champs suivants. Sinon laissez les paramètres par défaut et cliquez simplement sur Next (Suivant) Connexion Ethernet A Sélectionnez Ethernet comme type de connexion WAN. B Sélectionnez Get automatically from your ISP (Obtenir automatiquement de l'ISP) si votre ISP ne vous a pas attribué...
Page 68
Connexion PPPoE A Sélectionnez PPPoE comme étant votre type de connexion WAN. BTapez un Service Name (nom de service) (optionnel), User Name (nom d'utilisateur) et Password (mot de passe). C Sélectionnez Get automatically from your ISP (Obtenir automatiquement de l'ISP) si votre ISP ne vous a pas attribué...
Page 70
Connexion PPTP A Sélectionnez PPTP comme type de connexion WAN. BTapez un User Name (nom d'utilisateur) et Password (un mot de passe) C Sélectionnez Get automatically from ISP (Obtenir automatiquement de l'ISP) si votre ISP ne vous a pas attribué une adresse PPTP IP fixe. Ou sélectionnez Use fixed IP address (Utiliser une adresse IP fixe) pour donne au Prestige une adresse IP PPTP fixe et unique et un masque de sous-réseau.
Page 72
Installation de l'accès à Internet terminée Si vous rencontrez des problèmes pour accéder à Internet, suivez les instructions à l'écran. Cliquez sur le lien hypertexte Go to Bandwidth Management Wizard (Aller à l'assistant de gestion de bande passante)(optionnel) pour lancer l'assistant de gestion de bande passante;...
Page 73
FRANÇAIS ETAPE 1: Informations générales Sélectionnez la case à cocher Active. Le Prestige ne contrôle pas la bande passante allouée au trafic entrant dans une interface. Entrez la quantité de Managed Bandwidth (bande passante gérée) en kbps (2 à 100 000) que vous désirez allouer au trafic.
Page 74
ETAPE 3: Installation des priorités Sélectionnez priorité High (Haute),Mid (Moyenne) ou Low (Faible) pour contrôler la distribution de la bande passante des services sélectionnés. Un service avec une priorité High (Haute) reçoit toute la bande passante dont il a besoin. Si vous sélectionnez des services comme ayant la même priorité, alors la bande passante est répartie également entre ces services.
Page 75
PROBLÈME Impossible d'accéder au Prestige à partir de mon ordinateur. Impossible d'accéder au Prestige à partir de mon ordinateur (suite). Impossible d'accéder à Internet. Vérifiez les paramètres de connexion Internet dans l'assistant. Vérifiez que vous 5.1 Paramétrez l'adresse IP de votre ordinateur Cette section vous indique comment paramétrer votre ordinateur pour recevoir une adresse IP dans Windows 2000, Windows NT et Windows XP.
Page 76
5 Sélectionnez Protocole Internet (TCP/IP) (dans l'onglet Général dans Windows XP) et cliquez sur Properties (Propriétés). 6 L'écran de Propriétés TCP/IP de protocole Internet s'ouvre (General tab (onglet Général) dans Windows XP). Sélectionnez les options Obtain an IP address automatically (Obtenir automatiquement une adresse IP) et Obtain DNS server adress automatically (Obtenir automatiquement une adresse de serveur DNS).
Cenni generali Prestige è un broadband router che incorpora uno switch a quattro porte 10/100 Mbps. Il Prestige semplifica la configurazione di una piccola rete domestica o per un piccolo ufficio e consente di condividere l'accesso a Internet attraverso un model a banda larga (via cavo/xDSL). È...
Page 78
1 Collegamenti hardware Di seguito sono illustrati i collegamenti hardware per l'installazione iniziale. Collegamento WAN Collegare il modem alla porta “WAN” utilizzando il cavo fornito a corredo con il modem. Collegamento LAN Collegare il computer alla porta "LAN" utilizzando un cavo Ethernet fornito a corredo. Collegamento POWER ITALIANO...
Utilizzare l'alimentatore incluso per collegare la presa POWER a una sorgente di alimentazione appropriata (vedere la Guida dell'utente per le specifiche terniche dell'alimentatore relative al proprio paese). Indicatori LED Sul pannello frontale sono presenti alcuni LED. Quando si collega l'alimentazione, i LED PWR e WLAN si accendono.
Page 80
Nota: In basso a destra di ogni schermata è presente il pulsante Next (avanti). 5 Selezionare la lingua desiderata dall'elenco a discesa. Fare clic su go. 3 Configurazione dell'accesso a Internet Nota: Immettere le informazioni e i parametri Internet esattamente come sono stati forniti dal proprio ISP nelle varie schermate e quindi fare clic su Next (avanti) per continuare oppure su Back (indietro) per tornare alla schermata precedente.
Page 81
• Nessuna: nessuna protezione LAN wireless configurata. Se non si ailita alcuna protezione wireless sul Pres- tige, la rete sarà accessibile a qualsiasi periferica wireless di rete che si trova nel campo della portata. • Protezione di Base: WEP (Wired Equivalent Privacy) esegue la crittografia dei frame di dati prima di trasmet- terli sulla rete wireless.
Page 82
Protezione Base (WEP). A Immettere un nome univoco per identificare il Prestige nella LAN wireless. B Lasciare l'impostazione predefinita. Il Prestige e il client wireless devono utilizzare lo stesso ID di canale. C Selezionare la protezione Base(WEP). D È possibile generare o immettere manualmente una chiave WEP mediante una delle seguenti opzioni: Immettendo una Passphrase (fino a 32 caratteri stampabili) e facendo clic su Generate (genera).
Page 83
Protezione Estesa (WPA-PSK) o (WPA2-PSK) A Immettere un nome univoco per identificare il Prestige nella LAN wireless. B Lasciare l'impostazione predefinita. Il Prestige e il client wireless devono utilizzare lo stesso ID di canale. C Scegliere la protezione WPA-PSK o WPA2-PSK. D Immettere una chiave condivisa in precedenza per avere una connessione wireless più...
Page 84
FASE 3: La procedura guidata tenta di rilevare quale tipo di connessione WAN si sta utilizzando. Se la procedura guidata non rileva un tipo di connessione, è necessario selezionarne UNA dall'elenco a discesa. Chiedere al proprio ISP il tipo di connessione corretta: 1 Ethernet ITALIANO...
Page 85
2 PPPoE 3 PPTP. Nota: Se sono state fornite le impostazioni di accesso Internet, immettere i campi seguenti. In caso contrario, lasciare le impostazioni predefinite e fare solo clic su Next (Avanti). Collegamento Ethernet A Scegliere Ethernet come tipo di connessione WAN. B Selezionare Ottieni automaticamente dall'ISP se l'ISP non ha assegnato un indirizzo IP statico.
Page 87
Collegamento PPPoE A Selezionare PPPoE utilizzando il tipo di connessione WAN. BImmettere Nome del servizio (opzionale), Nome utente e Password. C Selezionare Ottieni automaticamente dall'ISP se l'ISP non ha assegnato un indirizzo IP statico. Passare alla sezione E. Oppure selezionare Utilizza indirizzo IP fisso fornito dall'ISP per fornire al Prestige un indirizzo IP statico univoco.
Page 89
Collegamento PPTP A Selezionare PPTP utilizzando il tipo di connessione WAN. BImmettere Nome utente e Password C Selezionare Ottieni automaticamente dall'ISP se l'ISP non ha assegnato un indirizzo IP PPTP statico. Oppure selezionare Utilizza indirizzo IP fisso per fornire al Prestige un indirizzo IP statico univoco. D Immettere un indirizzo IP del server PPTP E Immettere ID connessione/Nome (se forniti) F Selezionare Ottieni automaticamente dall'ISP se l'ISP non ha assegnato un indirizzo IP statico.
Page 91
La configurazione dell'accesso a Internet viene completata Se si verificano problemi con l'accesso a Internet, seguire le istruzioni visualizzate a shermo. Fare clic sul collegamento Passare a Gestione guidata banda (opzionale) per avviare la procedura guidata, altrimenti fare clic su Fine. 4 Gestione guidata banda Fare clic sul collegamento Passare a Gestione guidata banda (opzionale) oppure fare clic sull'opzione Gestione guidata banda nella schermata iniziale della configurazione ZyXEL.
Page 92
ITALIANO FASE 1: Informazioni generali Selezionare la casella di controllo Active (attiva). Il Prestige non controlla la banda allocata al traffico che passa in un'interfaccia. Inserire la quantità di banda gestita espressa in kbps (da 2 a 100.000) che si desidera allocare per il traffico. È...
FASE 3: Configurazione priorità Selezionare la priorità Alta, Media o Bassa per controllare la distribuzione della banda ai servizi selezionati. A un servizio con priorità Alta viene data tutta la banda di cui necessita. Se si selezionano servizi di pari priorità, la banda viene divisa egualmente tra i servizi.
Page 94
PROBLEMA Impossibile accedere allo Prestige dal mio computer. Impossibile accedere allo Prestige dal mio computer (continua). Impossibile accedere a Internet. Verificare le impostazioni Internet nella procedura guidata. Assicurarsi di 5.1 Impostare l'indirizzo IP del computer Questa sezione spiega come configurare il computer per ricevere un indirizzo IP in Windows 2000, Windows NT e Windows XP.
Page 95
5 Selezionare Protocollo Internet (TCP/IP) (sotto la scheda Generale in Windows XP) e fare clic su Proprietà. 6 Si apre la schermata Protocollo Internet TCP/IP - Proprietà (la scheda Generale in Windows XP). Selezionare le opzioni Ottieni automaticamente un indirizzo IP e Ottieni automaticamente l'indirizzo del server DNS.
Page 106
PPTP 連接 A 選擇 PPTP 為廣域網路連線類型。 B 輸入一個 使用者名稱及密碼 C 如果您的 ISP 不配置固定的 PPTP IP 位址,選擇 自動由 ISP 取得 。 選擇 使用固定 IP 位址以給予 Prestige 一個固定的、唯一的 PPTP IP 位址及子網路遮罩。 D 輸入一個 PPTP 伺服器 IP 位址 E 輸入一個 連線識別碼 / 名稱 ( 如果有提供 ) F 如果您的...
Page 111
問題 無法由我的電腦接取 Prestige( 繼續 )。 無法接取網際網路。 5.1 設定電腦的 IP 位址 本節會說明如何在 Windows 2000、Windows NT 和 Windows XP 中,設定電腦接收 IP 位址。這項作業可以確保您的電腦能和 ZyWALL 裝置通訊。 1 在 Windows XP 中,按一下開始,然後按一下控制台。 在 Windows 2000/NT 中,依序按下開始、設定和控制台。 2 在 Windows XP 中,按一下網路連線。 在 Windows 2000/NT 中,按一下網路和撥號連線。 3 在區域連線上按一下滑鼠右鍵,然後按內容。...
Page 112
5 選取 Internet Protocol (TCP/IP) ( 在 Win XP 中位於一般索引標籤上 ),然後按一下內 容。 6 Internet Protocol TCP/IP 內容畫面會開啟 ( 在 Win XP 中位於一般索引標籤上 )。選取 自動取得 IP 位址和自動取得 DNS 伺服器位 址選項。 7 按一下確定,關閉 Internet Protocol (TCP/ IP) 內容視窗。 8 按一下關閉 ( 在 Windows 2000/NT 中為確定 ),關閉區域連線內容視窗。...
