Page 1: Quick Start Guide
ZyXEL G-200 (Hardware Revision v2) 802.11g Wireless USB Adapter Quick Start Guide Version 2.0 2/2006... - Page 2 ZyXEL G-200 Quick Start Guide Important Information Federal Communications Commission (FCC) Interference Statement The 802.11g Wireless LAN Adapter has been tested to the FCC exposure requirements (Specific Absorption Rate). The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment, under 47 CFR 2.1093 paragraph (d) (2).
-
Page 3: Installation Requirements
ZyXEL G-200 Quick Start Guide About Your ZyXEL G-200 The ZyXEL G-200 is an IEEE 802.11g compliant wireless USB Adapter that connects to USB ports on desktop or notebook computers. With the ZyXEL G-200, you can enjoy the wireless mobility within the coverage area. The IEEE 802.11g technology provides greater range and offers transmission rate at up to 54 Mbps. - Page 4 ZyXEL G-200 Quick Start Guide the Z icon in the system tray) Install the driver only. In this case, you must connect the ZyXEL G-200 first. 2. ZyXEL Utility and Hardware Installation The installation procedures are similar for all supported Windows versions. Windows XP screen shots are shown unless otherwise specified.
- Page 5 ZyXEL G-200 Quick Start Guide 3. A Welcome screen displays. Click Next. 4. To install ZyXEL Utility, select Utility and Driver checkbox. Click Next to accept the default file location or click Browse to select an alternate folder.
- Page 6 ZyXEL G-200 Quick Start Guide 5. Click the Install button to begin the installation. 6. Click Finish to restart the computer. 7. Insert your ZyXEL G-200 into an available USB port on the computer by using the provided USB cable. 8.
-
Page 7: Driver Installation For Windows Xp
ZyXEL G-200 Quick Start Guide Never bend, force or twist the ZyXEL G-200 USB cable into the slot. 9. After you install the ZyXEL Utility and insert the ZyXEL G-200, an ZyXEL icon appears in the system tray. 10. Double click the Z icon to configure your wireless adapter. 3. - Page 8 ZyXEL G-200 Quick Start Guide 3. Insert the included CD into your CD-ROM drive, select Search removable media (floppy, CD- ROM…) and then click Next. 4. After the driver has been installed successfully, click Finish to complete the installation. Refer to the User’s Guide to configure the ZyXEL G-200.
-
Page 9: Led Display
ZyXEL G-200 Quick Start Guide 4. LED Display Power LED Link LED The following table describes the LEDs on the ZyXEL G-200. COLOR STATUS Green Blinking LINK Green LEDS BEHAVIOR The ZyXEL G-200 is receiving power. The ZyXEL G-200 is not receiving power The ZyXEL G-200 is connected The ZyXEL G-200 is sending or receiving data The ZyXEL G-200 is not sending or receiving... -
Page 10: Troubleshooting
ZyXEL G-200 Quick Start Guide 5. Troubleshooting PROBLEM Windows does not Make sure the ZyXEL G-200 is properly connected via the USB auto-detect the slot and then restart your computer. Once the computer has ZyXEL G-200. restarted, check the status of the LEDs on the ZyXEL G-200. Perform a hardware scan by clicking Start, Settings, Control Panel and then double-click Add/Remove Hardware. -
Page 11: Customer Support
ZyXEL G-200 Quick Start Guide 6. Customer Support Please have the following information ready when you contact customer support. • Serial number for your specific product • Warranty Information • Date that you received or purchased your device • Brief description of the problem including any steps that you have taken before contacting the ZyXEL Customer Support Representative SUPPORT E-MAIL support@zyxel.com...
