- Page 1 MADE IN User’ s Guide Shop online at omega.com e-mail: info@omega.com or latest product manuals: omegamanual.info EWS-BP- Barometric Pressure Transmitter...
- Page 2 Online Service Internet e-mail ® omega.com info@omega.com Servicing North merica: U.S.A.: Omega Engineering, Inc., One Omega Drive, P.O. Box 4047 ISO 9001 Certified Stamford, CT 06907-0047 USA Toll Free: 1-800-826-6342 TEL: (203) 359-1660 FAX: (203) 359-7700 e-mail: info@omega.com Canada: 976 Bergar...
-
Page 3: Table Of Contents
Table of Contents Section ................Page Section 1 - General Description ................ 1 Section 2 - Unpacking ..................1 Section 3 - Theory of Operation ............... 2 Section 4 - Specifications ................... 2 Section 5 - Mounting ..................3 Section 6 - Transmitter Wiring Examples ............3 Section 7 - Barometric Pressure to Analog Output Calculations .... - Page 4 Table of Figures Figure Description ............Page 1. Model No. EWS-BP-A with EWS-MB ............3 2. Transmitter Wiring Examples ..............3...
-
Page 5: Section 1 - General Description
Section 1 - General Description The OMEGA Model EWS-BP-A is a low cost, wall mounted barometer/transmitter. A ® temperature compensated, solid state pressure sensor measures atmospheric pressure. The measurement is then converted to an industry standard, user selectable 4-20 mA or 1-5 Vdc output signal scaled across the measurement range. -
Page 6: Section 3 - Theory Of Operation
A 4-20 mA loop is a series loop in which a transmitter will vary the current flow depending on the input to the transmitter. In the EWS-BP-A the amount of current allowed to flow in the loop will vary depending on the atmospheric pressure being measured by the sensor. -
Page 7: Section 5 - Mounting
A conduit box mounting bracket/wall plate adapter kit is available that will allow the transmitter to be mounted to a standard electrical conduit box. CONDUIT BOX (NOT INCLUDED) IS SHOWN FOR Order OMEGA Model No.: EWS-MB. ® REFERENCE ONLY. -
Page 8: Section 7 - Barometric Pressure To Analog Output Calculations
Equipment Required: 1. Regulated Power Supply, 12-24 Vdc @ 30 mA (OMEGA Model: PSU-93) 2. Digital DC Volt Meter (OMEGA Model: HHM29) 3. Handheld Differential Pressure Calibration Kit, (OMEGA Model: PCL-200-KIT-D) 4. - Page 9 W RR NTY/DISCL IMER OMEG ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of 13 months from date of purchase. OMEG ’s W RR NTY adds an additional one (1) month grace period to the normal one (1) year product warranty to cover handling and shipping time.
