- Page 1 SRTZ2601F 848F4293A1 (705) OWNER’S MANUAL SHORT REACH TRIMMER SRTZ2601F GB-1...
- Page 2 1-9, Minamidai, Kawagoe, Saitama, Japan DIRECTIVE 89/336/EEC, 98/37/EC, 2000/14/EC, 97/68/EC, 2002/88/EC, 2002/44/EC, prEN774[2001] The products referred are : DESIGNATION : SHORT REACH TRIMMERS MODELS : SRTZ2601F SERIAL NUMBERS : 70300001 and up : Specification sheet : Inspection standard 1st April 2007...
-
Page 3: Table Of Contents
5. For safe operation ... 5 6. Set up ... 8 7. Fuel ... 9 8. Operation ... 10 9. Maintenance ... 12 10. Storage ... 14 11. Disposal ... 14 12. Troubleshooting guide ... 15 Replace the worn-out blades. SRTZ2601F GB-3... -
Page 4: Specifications
1734 x 338 x 254 Air-cooled 2-stroke gasoline Zenoah GZ25N 1.2Hp (0.9kW) at 7500min 3000± 200min Mixture (Gasoline 50 : Oil 1) (when using ZENOAH genuine oil) Walbro Diaphragm type Centrifugal clutch, Spiral bevel gear, Cam crank 4. Symbols on the machine For safe operation and maintenance, symbols are carved in relief on the machine. -
Page 5: For Safe Operation
2. Never use the product, a. when the ground is slippery or when you can’t maintain a steady posture. SRTZ2601F b. At night, at times of heavy fog, or at any other times when your field of vision might be... - Page 6 If it continues to move even after the throttle has been moved fully back, turn off the engine and take the unit to your authorized ZENOAH servic- ing dealer for repair. USING THE PRODUCT IMPORTANT Cut only materials recommended by the manufacturer.
- Page 7 SRTZ2601F HANDLING FUEL 1. The engine of the ZENOAH prod- uct is designed to run on a mixed fuel, which contains highly flam- mable gasoline. Never store cans of fuel or refill the tank of the unit...
-
Page 8: Set Up
SRTZ2601F 6. Set up MOUNTING ENGINE 1. Push the drive shaft housing toward the clutch hous- ing and move it by hand to check that the drive shaft is engaged with the gears. 2. Insert the drive shaft housing into the clutch housing until it bottoms, and align the positioning holes on the clutch housing and the shaft tube and install the screw. -
Page 9: Fuel
• The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle engine use (JASO FC GRADE OIL or ISO EGC GRADE). -
Page 10: Operation
SRTZ2601F 8. Operation STARTING ENGINE 1. Feed fuel into the fuel tank and tighten the cap se- curely. 2. Rest the unit on a flat, firm place. Keep the cutting head off the ground and clear of surrounding objects as it will start moving upon starting of the engine. - Page 11 NOTE • The thickness of branches which may be cut using this trimmer is limited to up to approximately 4.8mm. Never try to cut branches thicker than this, as doing so may result in damage to the trimmer. SRTZ2601F GB-11...
-
Page 12: Throttle Lever
• If the blades become so worn down that it is no longer possible to eliminate the gap between them, you should contact the authorized ZENOAH servicing dealer from which you purchased your ZENOAH trim- mer to have the blades resharpened or replaced. GEAR CASE •... - Page 13 • Do not modify the trimming mechanism or dismantle the engine. • When replacing parts please use Zenoah original parts or designated parts. ■ Air cleaner • After every 25 hours of operation, please remove the air cleaner cover and inspect the element.
-
Page 14: Storage
SRTZ2601F 9. Maintenance MUFFLER WARNING • Inspect periodically, the muffler for loose fasten- ers, any damage or corrosion. If any sign of ex- haust leakage is found, stop using the machine and have it repaired immediately. • Note that failing to do so may result in the engine catching on fire. -
Page 15: Troubleshooting Guide
(exhaust port) → carbon is built-up air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
