- Page 1 T4539-93111 (804) OWNER’S MANUAL HEDGE-TRIMMERS eHT751S eHT601D...
-
Page 2: Table Of Contents
English SAFETY FIRST Instructions contained in warnings within this manual marked with a symbol concern critical points which must taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail. -
Page 4: Parts Location
English 1. PARTS LOCATION 1. Plate receive 2. Right handle 3. Starter 4. Fuel cap 5. Left handle 6. Engine Stop switch 7. Throttle lever 8. Fuel tank 9. Muffler 10. Blade 11. Air cleaner 12. Spark plug 13. Gear case 14. -
Page 6: Symbols On The Machine
English 2. SYMBOLS ON THE MACHINE For safe operation and maintenance, symbols are carved in relief on the machine. According these indications, please be careful not to take a mistake. (a).The port to refuel the "MIX GASOLINE" POSITION: FUEL TANK CAP (b).The direction to close the choke POSITION: AIR CLEANER COVER (c).The direction to open the choke... -
Page 8: Safety Precautions
English 3. SAFETY PRECAUTIONS ■ BEFORE USING THE MACHINE a. Read this owner's manual carefully to understand how to operate this unit properly. b. This product has been designed for use in trimming leaves and branches from trees and hedges, and it should never be used for any other purpose since doing so could result in unforeseen... - Page 10 English 3. SAFETY PRECAUTIONS g. Lack of sleep, tiredness, or physical exhaustion results in lower attention spans, and this in turn leads to accidents and injury. Limit the amount of time over which the hedge-trimmer is to be used continuously to somewhere around 30~40 minutes per session, and take 10~20 minutes of rest between work sessions.
- Page 12 English 3. SAFETY PRECAUTIONS ■ WARNING CONSIDERING HANDLING OF FUEL a. The engine of this product is designed to run on a mixed fuel which contains highly flammable gasoline. You should never store cans of fuel or refill the fuel tank in any place where there is a boiler, stove, wood fire, electrical sparks, welding sparks, or any other...
- Page 14 English 3. SAFETY PRECAUTIONS persons, always check the presence and locations of others so as to maintain a distance each person sufficient to ensure safety. c. Make sure that there are no loose screws or bolts, fuel leaks, ruptures, dents, or any other problems which might interfere with safe operation.
- Page 16 English 3. SAFETY PRECAUTIONS ■ KICKBACK SAFETY PRECAUTIONS • A dangerous reaction may occur when the spinning blade contacts a solid object in the critical area. It is called Kick back. As a result, the operator can lose control of the unit which can cause serious or fatal injury.
- Page 18 ZENOAH authorized servicing dealer for assistance. b. Under no circumstances should you ever take apart the hedge- trimmer or alter it in any way.
- Page 20 When replacing blade or any other parts or when replacing the oil or any lubricants, always be sure to use only ZENOAH products or products which have been certified by ZENOAH for use with the hedge-trimmer.
-
Page 22: Fuel
2-cycle engine oil into a mixing container in accordance with the following ratios and then shaking to mix well. Mixing ratios: When using Zenoah genuine 2-cycle oil (FC grade): 50:1 (100 ml of oil for every 5 liters of gasoline) When using commercially available... -
Page 24: Operation
[eHT601D] Release the throttle lever and make sure it is fully back. (F1) 2. [eHT601D] Set the engine switch to the “I (RUN)” position. (F1) 3. Push the primer pump until overflown fuel flows out in the clear tube. - Page 26 ■ HOW TO USE HANDLE [eHT601D only] (F5) To reduce fatigue when trimming hedges, the handle can be swivelled through 90° to the left or right. Do not press the throttle during this operation! Proceed as follows: 1.
- Page 27 F5 (eHT601D)
-
Page 28: Maintenance
English 6. MAINTENANCE WARNING Before cleaning, inspecting, or repairing the unit, make sure that the engine has stopped and is cool. ■ BLADE (F8) • Check the blade and the fasteners for looseness, cracking, or bending. • Check the cutting edges and reform with a flat file. - Page 30 • [eHT751S] Check periodically if the rubber cushions are not deformed or damaged. • [eHT601D] Check periodically if the springs are not deformed or damaged. ■ AIR CLEANER (F12) Release the air cleaner cover and remove dusts.
- Page 32 English 6. MAINTENANCE ■ FUEL FILTER (F13) When the engine runs short of fuel supply, check the fuel strainer for blockage. ■ WAY OF THE COOLING AIR (F14) This engine is air-cooled. Dust clogging between the inlet port of the cooling air and cylinder fins will cause overheating of the engine.
- Page 34 English 6. MAINTENANCE ■ GEARCASE (F16) Supply multi-purpose grease at every 20 hours of use. 1. Use a grease pump. 2. Feed grease until it comes out of the base of blades.(F16-a) ■ ADJUSTING CARBURETOR (F17) The carburetor has been adjusted at the factory.
- Page 36 English 6. MAINTENANCE ■ MUFFLER AFTER 100 HOURS OF USE 1. Remove the muffler, insert a screwdriver into the vent, and wipe away any carbon buildup. Wipe away any carbon buildup on the muffler exhaust vent at the same time. (F19) (1) screw driver (2) muffler 2.
-
Page 38: Specifications
... Diaphragm type Ignition system ... C.D.I Spark plug ... Champion RCJ6Y Fuel ... Mixture when using ZENOAH genuine oil (FC grade) ... 50:1 when using market oil (FB grade) ... 25:1 Fuel tank capacity ... 0.4 litres Starter ... Recoil starter Clutch ... - Page 40 Head Office: 1-9, Minamidai, Kawagoe-city, Saitama, 350-1165 Japan Telephone: (+81)49-243-1117 Telecopier: (+81)49-243-7197 PRINTED IN JAPAN...
