- Page 1 BKZ4500DL BKZ5000DL BKZ4500DL / BKZ5000DL 848KH093A3 (704) OWNER’S MANUAL BRUSHCUTTERS GB-1...
- Page 2 BKZ4500DL / BKZ5000DL EXPLANATION OF SYMBOLS AND SAFETY WARNINGS BKZ4500DL BKZ5000DL MODEL BKZ4500DL 45.2 cm BKZ5000DL 50.6 cm APPROVAL NUMBER OF CE EXHAUST EMISSION REGULATION BKZ4500DL : e13*97/68SH2G3*2002/88*0097*02 BKZ5000DL : e13*97/68SH3G3*2002/88*0099*03 GB-2 ZENOAH CO., LTD. 1st April 2007 Masahiko GOUDA...
-
Page 3: Table Of Contents
5. For safe operation ... 5 6. Set up ... 8 7. Fuel ... 9 8. Operation ... 10 9. Maintenance ... 13 10. Storage ... 15 11. Disposal ... 15 12. Troubleshooting guide ... 16 BKZ4500DL / BKZ5000DL GB-3... -
Page 4: Specifications
The port to refuel the “MIX GASOLINE” GB-4 BKZ4500DL Zenoah GZ45N 45.2 Mixture (Gasoline 50 : Oil 1) when using Zenoah genuine oil Diaphragm type Flywheel magneto (C.D.I.) Counter-clockwise (Operator view) Never modify your machine. We won’t warrant the machine, if you use the remodeled brushcutter or if you don’t observe... -
Page 5: For Safe Operation
2. Never use the product, a. when the ground is slippery or when you can’t maintain a steady posture. BKZ4500DL / BKZ5000DL b. At night, at times of heavy fog, or at any other times when your field of vision might be... - Page 6 BKZ4500DL / BKZ5000DL 5. For safe operation BEFORE STARTING THE ENGINE 1. The area within a perimeter of 15 m (50 ft) of the person using the product should be considered a haz- ardous area into which no one should enter.
- Page 7 BKZ4500DL / BKZ5000DL HANDLING FUEL 1. The engine of the ZENOAH prod- uct is designed to run on a mixed fuel, which contains highly flam- mable gasoline. Never store cans...
-
Page 8: Set Up
BKZ4500DL / BKZ5000DL 6. Set up INSTALLING HANDLE • Mount the handle to the shaft tube and clamp it at a location that the edge of CE label is matched with the handle. WARNING • Stop tightening the screws when the gap A be- comes zero. -
Page 9: Fuel
3 m (10 ft) away from the fueling point before starting the engine. • The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant... -
Page 10: Operation
BKZ4500DL / BKZ5000DL 8. Operation STARTING ENGINE WARNING • The cutting head will start rotating upon the en- gine starts. 1. Feed fuel into the fuel tank and tighten the cap se- curely. 2. Rest the unit on a flat, firm place. Keep the cutting head off the ground and clear of surrounding objects, as it will start rotating upon starting of the engine. - Page 11 If not, it is vary dangerous when you slip or lose your balance. • Be sure to use genuine parts made of Zenoah for blades. In particular, never use special blades such as shredder blades. If you use a special blade, the unit may fail.
- Page 12 BKZ4500DL / BKZ5000DL 8. Operation CUTTING METHOD (a)Use the front left side cutting. (b) Guide the blade from your right to left with it tilted slightly to your left. (c) When mowing a wide area, start working from your left end to avoid interference of cut grass.
-
Page 13: Maintenance
• Make the right and left lines the same length when using the nylon line head. (Be sure to install the genuine Zenoah cutting attach- ment guard when using the nylon line head.) 9. Maintenance... - Page 14 BKZ4500DL / BKZ5000DL 9. Maintenance REFILLING TRIMMING LINE 1. For replacement line, use a diameter of 2.4mm(.095in). The spool is capable for a line upto 6m(20ft) on the 10cm(4”) head. Avoid using a larger line as it may cut down the trimming performance.
-
Page 15: Storage
1. Pull out the flexible liner while pulling the stopper up- ward. 2. Pull out the inner shaft from the clutch housing side hole, apply Zenoah Guine Power Grease (Z3180- 91250) or lithium-based heat-resistant grease (#2) to the shaft, and insert the shaft back into the liner. -
Page 16: Troubleshooting Guide
(exhaust port) → carbon is built-up air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
